MGSP Programming Guide
32-Zone Wireless Security Systems
MG5075 v1.01
MG5050 & MG5000 v4.90
MG5050E v7.14
4 to 32-Zone Expandable Security Systems
SP5500, SP6000 & SP7000 v7.14
SP4000 v5.23
SP65 v5.24
Always Armed,
Never Disarmed

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP6000 and is the answer not in the manual?

Questions and answers

Related Manuals for Paradox SP6000

Summary of Contents for Paradox SP6000

  • Page 1 MGSP Programming Guide 32-Zone Wireless Security Systems MG5075 v1.01 MG5050 & MG5000 v4.90 MG5050E v7.14 4 to 32-Zone Expandable Security Systems SP5500, SP6000 & SP7000 v7.14 SP4000 v5.23 SP65 v5.24 Always Armed, Never Disarmed...
  • Page 2 Limitations of Alarm Systems It must be understood that while your Paradox alarm system is highly advanced and secure, it does not offer any guaranteed protection against burglary, fire or other emergency (fire and emergency options are only available on certain Paradox models). This is due to a number of reasons, including by not limited to inadequate or improper installation/positioning, sensor limitations, battery performance, wireless signal interruption, inadequate maintenance or the potential for the system or telephone lines to be compromised or circumvented.
  • Page 3 Things You Need to Know About this Programming Guide Use this programming guide to record programmed settings for your Magellan or Spectra SP control panel. This guide should be used along with the Magellan and Spectra SP Reference & Installation Manual (available online), whenever installing or programming your Magellan or Spectra SP system.
  • Page 4 Data Entry and Display To access the data display mode, access the desired section and press before entering any data. Depending on the keypad(s) ENTER configured to your system, specific LEDs or icons will flash, thus indicating that you are in data display mode. Each time ENTER pressed, the keypad will display the next digit in the current section, and will continue to do so through all the remaining sections, one digit at a time, without changing the programmed values;...

  • Page 5: Table Of Contents

    Contents Miscellaneous System Options ..................39 System Timers ................39 Installer Quick Menu ..............7 Keypad Lockout ................39 Communicator ........................8 Programming the Daylight Savings Feature ......39 Cancel Communication ..................... 8 Country Codes ........................40 Keypad Programming ......................8 Customized Daylight Savings Features ..............40 PGMs ............................
  • Page 6 SP4000 ...........................63 Worksheet 51: IP Account Numbers ................ 52 Worksheet 52: Software and PCS Connection Settings ........52 SP5500 ...........................64 SP6000 ...........................65 Worksheet 53: IP Receiver 1 Configuration ............53 SP65 ............................66 Worksheet 54: IP Receiver 2 Configuration ............53 SP7000 ...........................67...

  • Page 7: Installer Quick Menu

    Magellan & Spectra SP • Programming Guide Walk Test Mode Installer Quick Menu Step Action Details = flash; maintenance code may also be + installer code used Zones Activates or deactivates walk test mode Step Action Details Installer and Maintenance Codes = flash;...

  • Page 8: Communicator

    Magellan & Spectra SP • Programming Guide Communicator Press and hold ENTER = ON STAY for three seconds Step Action Details ON = output switches to ground following = flash; maintenance code may also be + installer code Option 1 system arming (blue wire, maximum150 mA) used OFF = input (keypad zone input)

  • Page 9: Bus Module Planning

    Magellan & Spectra SP • Programming Guide System Planning Bus Module Planning Worksheet 1: Planning Bus Modules Serial # Sticker Description Path Zone (Entry Point) Path Zone Path Zone Path Zone Bus Module 1 Bus Module 2 Bus Module 3 Bus Module 4 Bus Module 5 Bus Module 6...

  • Page 10: Wireless Keypad Planning

    Magellan & Spectra SP • Programming Guide Wireless Keypad Planning Worksheet 2: Planning Wireless Keypads Serial # Sticker Description Path Zone (Entry Point) Path Zone Path Zone Path Zone Wireless Keypad Wireless Keypad Wireless Keypad Wireless Keypad Wireless Keypad Wireless Keypad Wireless Keypad Wireless Keypad NOTE: When deleting a wireless keypad (K32RF/K37) from the system, the corresponding StayD path zones will also be deleted.

  • Page 11: Programmable Output (Pgm) Planning

    Magellan & Spectra SP • Programming Guide Programmable Output (PGM) Planning Worksheet 4: Planning Programmable Outputs Serial # Sticker Description Serial # Sticker Description PGM 1 PGM 9 PGM 2 PGM 10 PGM 3 PGM 11 PGM 4 PGM 12 PGM 5 PGM 13 PGM 6...
  • Page 12 Magellan & Spectra SP • Programming Guide Worksheet 6: Planning Zones (Continued) Arming Method Arming Method Serial # Sticker Zone # Zone Description Stay Sleep Full Serial # Sticker Zone # Zone Description Stay Sleep Full     ...

  • Page 13: Zone Recognition

    Magellan & Spectra SP • Programming Guide Zone Recognition NOTE: For keypad zone programming, see Keypad Programming on page 8. MG Series When expanding zones via ZX8/ZX82, up to three ZX8/ZX82 modules can be added to the system, and they are identified by the ZX8/ZX82 three-position jumpers: +1, +9, and +17.

  • Page 14: Sp Series

    When expanding zones via ZX8/ZX82, up to three ZX8/ZX82 modules can be added to the system, and they are identified by the ZX8/ZX82 three-position jumpers: +1, +9, and +17. Table 4 displays zone recognition information for SP control panels. Table 4: Zone recognition information for the SP series SP4000 (without ATZ) SP4000 (with ATZ) SP5500 (without ATZ) SP5500 (with ATZ) SP6000 (without ATZ) SP6000 (with ATZ) Type Zone Description Type Zone...
  • Page 15 Table 4: Zone recognition information for the SP series (Continued) SP65 (without ATZ) SP65 (with ATZ) SP7000 (without ATZ) SP7000 (with ATZ) Type Zone Description Type Zone Description Type Zone Description Type Zone Description Panel input 1 Panel input 1A Panel input 1 Panel input 1A Panel input 2...

  • Page 16: Zone Definitions

    Magellan & Spectra SP • Programming Guide Zone Definitions NOTE: If a device is assigned to a zone which is already programmed, a wireless zone will overwrite a keypad/hardwire zone and a keypad zone will overwrite a hardwire zone. To define zones on your MG/SP control panel: Press , and then enter your installer code (maintenance code may also be used).
  • Page 17 Table 9: Permitted zone definitions for MG/SP panels Arming Type Arming Type Input Input Description Description Stay Sleep Fully Stay Sleep Fully Value Value Disarm Disarm         Zone disabled 24 hr. burglary  ...

  • Page 18: Custom Zone Definitions

    [056] ____/____/____ (000 to 255) x 10 msec. Speed of hardwire zone 16 SP Series Worksheet 10: Zone Timers for the SP Series Section Zone SP4000 SP5500 SP6000 SP65* SP7000** Data Description (default: 060) [041] (Z1) (Z1) (Z1) (Z1) (Z1) ____/____/____ (000 to 255) x 10 msec.

  • Page 19: Wireless Zone Assignment

    Magellan & Spectra SP • Programming Guide Wireless Zone Assignment Use the following section to program the wireless zones on your MG/SP control panel. Use worksheet 11 to record your settings. Worksheet 11: Wireless Zones Section Zone Wireless Zone (Serial #) Section Zone Wireless Zone (Serial #)

  • Page 20: Zone Labels

    Use the following section to program programmable outputs (PGMs) on your MG/SP control panel. Programmable Output Recognition Table 11: Programmable outputs for MG/SP panels Control Panel PGM Output MG5000 MG5050 SP4000 SP5500 SP6000 SP65 SP7000      ...

  • Page 21: Description Of Mg/Sp Events

    Magellan & Spectra SP • Programming Guide Description of MG/SP Events Table 12: List of events for MG/SP control panels Event Group Event Group Description Sub-group Sub-group Description Zone OK 01 to 32 Zone number Zone open Any zone number 00 to 01 Silent alarm Buzzer alarm...
  • Page 22 Magellan & Spectra SP • Programming Guide Table 12: List of events for MG/SP control panels (Continued) Event Group Event Group Description Sub-group Sub-group Description IP registration status change GPRS registration status change Armed with trouble(s) Non-reportable event Supervision alert (Cont.) (Cont.) Supervision alert restore...
  • Page 23 Magellan & Spectra SP • Programming Guide Table 12: List of events for MG/SP control panels (Continued) Event Group Event Group Description Sub-group Sub-group Description Non-valid source ID BabyWare direct BabyWare through IP module BabyWare through GSM module BabyWare through modem Software access (VDMP3, IP Module, BabyWare) IP Module direct VDMP3 direct...
  • Page 24 Magellan & Spectra SP • Programming Guide Table 12: List of events for MG/SP control panels (Continued) Event Group Event Group Description Sub-group Sub-group Description 01 to 32 Zone number Zone alarm restore Any zone number 01 to 32 Zone number Fire alarm restore Any zone number Panic non-medical emergency...
  • Page 25 Magellan & Spectra SP • Programming Guide Table 12: List of events for MG/SP control panels (Continued) Event Group Event Group Description Sub-group Sub-group Description AC failure Battery failure Auxiliary current overload Bell current overload Bell disconnected Clock loss Fire loop trouble Fail to communicate with monitoring station telephone # 1 Fail to communicate with monitoring station telephone # 2 Fail to communicate with voice report...
  • Page 26 Magellan & Spectra SP • Programming Guide Table 12: List of events for MG/SP control panels (Continued) Event Group Event Group Description Sub-group Sub-group Description Bus/EBus/wireless module communication fault Tamper trouble Bus/EBus/wireless module new trouble (partition 1 only) Power fail Battery failure Any bus module new trouble event Bus/EBus/wireless module communication fault restore...

  • Page 27: Pgm Activation/Deactivation Events

    Magellan & Spectra SP • Programming Guide Table 12: List of events for MG/SP control panels (Continued) Event Group Event Group Description Sub-group Sub-group Description 01 to 32 User number Non-medical alarm (paramedic) Any user number 01 to 32 Zone number Zone forced Any zone number Zone included...

  • Page 28: Pgm Options

    Magellan & Spectra SP • Programming Guide PGM Options Table 13: Description of PGM options PGM 1 [261] PGM 2 [262] PGM 3 [263] PGM 4 [264] PGM 5 [265] PGM 6 [266] PGM 7 [267] PGM 8 [268] Option Description ...

  • Page 29: Pgm Delays

    Magellan & Spectra SP • Programming Guide PGM Delays Use worksheet 15 to record your settings for the MG/SP PGM delays. Worksheet 15: PGM Delays Section PGM Delay Value Default Section PGM Delay Value Default [281] PGM 1 ___/___/___ (001 to 255 x 1 sec./min.) [289] PGM 9 ___/___/___...

  • Page 30: User Programming

    Magellan & Spectra SP • Programming Guide User Programming Use the following section to program the various user features on your MG/SP control panel. System Codes Use worksheet 18 to record your settings for the MG/SP system codes. For access options, see section [701], in table 25 on page 37. NOTE: The maintenance code cannot access the following sections: [395] (Installer code lock);...

  • Page 31: User Report Codes

    Magellan & Spectra SP • Programming Guide User Report Codes Use worksheet 20 to record your settings for the MG/SP user report codes (the default code is FF). To clear and reset these codes, see Description of Sections [966] and [967] on page 54.

  • Page 32: Wireless Repeater Signal Strength

    Wireless Repeater Signal Strength The signal strength for wireless repeaters is visible in sections [548] and [549]; these sections represent repeaters 1 and 2, respectively. To view the signal strength, proceed as follows: Enter the wireless repeater’s respective section (e.g., for repeater 1, enter section [548]). Press the repeater’s anti-tamper switch.

  • Page 33: Wireless Repeater Labels

    Magellan & Spectra SP • Programming Guide Wireless Repeater Labels Use worksheet 23 to record your settings for wireless repeater labels. To reset these labels, see Description of Section [965] on page 53. Worksheet 23: Wireless Repeater Labels Section Description Wireless Repeater Label [568] Repeater 1...

  • Page 34: Wireless Keypad Signal Strength

    Magellan & Spectra SP • Programming Guide Wireless Keypad Signal Strength The signal strength for wireless keypads is visible in sections [591] to [598]; these sections represent keypads 1 through 8, respectively. To view the signal strength, proceed as follows: Enter the wireless keypad’s respective section (e.g., for keypad 1, enter section [591]).
  • Page 35 Worksheet 26: Programming Remote Controls REM3 Remote Control REM1/REM2/RAC1/RAC2/REM15 PGM 1 PGM 2 PGM 3 PGM 4 PGM 5 PGM 6 PGM 3 & 4 PGM 5 & 6  +  Default Data Disabled Disabled Default Data Disabled RC # Section RC # Section...

  • Page 36: User Assignment For Remote Controls

    Magellan & Spectra SP • Programming Guide User Assignment for Remote Controls Table 23: User assignment per remote control Section Description Section Description Section Description Section Description RC 1 for user 1 RC 9 for user 9 RC 17 for user 17 RC 25 for user 25 [651] [659]...

  • Page 37: Cancelling The Tamper Supervision For Wireless Sirens

    Cancelling the Tamper Supervision for Wireless Sirens To cancel tamper supervision, access section [695], and then press . The tamper supervision is disabled until the cover is replaced or after 30 minutes have elapsed. ENTER Description of Sections [700] to [704] The following section provides information on sections [700] to [704].

  • Page 38: Zone Options

    Magellan & Spectra SP • Programming Guide Zone Options Use the following section to program zone options for your MG/SP control panel. ATZ Options Table 26: Description of section [705] Option Description  ATZ zone doubling Disabled  Enabled  ATZ wiring options Series ...

  • Page 39: Miscellaneous System Options

    Magellan & Spectra SP • Programming Guide Miscellaneous System Options Table 29: Description of section [708] Option Description  Enter code to view trouble One-touch  Enter code  Enter code to view alarm in memory/event list One-touch  Enter code ...

  • Page 40: Country Codes

    Magellan & Spectra SP • Programming Guide Country Codes Table 31 lists countries and their respective codes. This information is required when programming section [731] (see worksheet 31 for details). Table 31: Country codes for MG/SP control panels Input Value Country Input Value Country Mexico;...

  • Page 41: Partition Timers

    Magellan & Spectra SP • Programming Guide Table 33: Description of partition 2 options (section [742]) Option Description Option Description  Auto-arm on time Disabled  Enabled  Auto-arm on no movement Disabled  Enabled Regular (default) See options 3 See options 3 3 &...

  • Page 42: Communication Programming

    Prioritization of signals and messages are based on a “first in, first out” scheme. Systems meet EN 50136 ATS2 or ATS3 requirements when configured as depicted. NOTE: For increased security, it is suggested that redundant communication methods be installed. Table 34: Communication features for MG/SP panels Control Panel Communication Feature MG5000 MG5050 SP4000 SP5500 SP6000 SP65 SP7000      ...

  • Page 43: Event Call Direction Options

    Magellan & Spectra SP • Programming Guide Event Call Direction Options Table 38: Description of event call direction options (sections [802] to [804]) Option Description Option Description Call tel. #1/monitoring rcvr. #1 for Call tel. #1/monitoring rcvr. #1 for  ...

  • Page 44: Report Codes And Partition Accounts

    Magellan & Spectra SP • Programming Guide Report Codes and Partition Accounts Use worksheet 36 to record your settings for sections [810] to [812]. Worksheet 36: Report Codes and Partition Accounts Section Data Description Tel. 1 & Tel. 2; Reporting format: [810] ___/___ 0 = Ademco Slow;...

  • Page 45: Test Report And Report Delays

    Magellan & Spectra SP • Programming Guide Test Report and Report Delays Use worksheet 40 to record your settings for sections [850] to [852]. For additional timers, see worksheets 38 and 49 on pages 44 and 51, respectively. Worksheet 40: Test Report and Report Delays Section Data Description...

  • Page 46: System Trouble Report Codes

    Magellan & Spectra SP • Programming Guide System Trouble Report Codes Use worksheet 44 to record your settings for system trouble report codes. Worksheet 44: Special Trouble Report Codes Section Data Description Section Data Description Section Data Description ___/___ ___/___ Bell output overload ___/___ Fail to communicate...

  • Page 47: Contact Id Report Codes

    Magellan & Spectra SP • Programming Guide Contact ID Report Codes Table 44: Ademco contact ID report codes (Continued) Table 44: Ademco contact ID report codes (Continued) Table 44: Ademco contact ID report codes Type CID # Reporting Code Value Type CID # Reporting Code Value...
  • Page 48 Magellan & Spectra SP • Programming Guide Table 44: Ademco contact ID report codes (Continued) Table 44: Ademco contact ID report codes (Continued) Table 44: Ademco contact ID report codes (Continued) Type CID # Reporting Code Value Type CID # Reporting Code Value Type CID # Reporting Code...

  • Page 49: Automatic Report Codes

    Magellan & Spectra SP • Programming Guide Automatic Report Codes Table 45: List of automatic report codes System Event Default Contact ID Report Code Default SIA Report Code Arming with user code (##) 3 4A1 Close by user Closing report Auto arming 3 4A3 Automatic close...
  • Page 50 Magellan & Spectra SP • Programming Guide Table 45: List of automatic report codes (Continued) System Event Default Contact ID Report Code Default SIA Report Code Bell absent 1 321 Bell 1 Bell fault Clock lost 1 626 Time/date inaccurate Time changed Fire loop trouble 1 373...

  • Page 51: Communication Report Codes

    Magellan & Spectra SP • Programming Guide Table 45: List of automatic report codes (Continued) System Event Default Contact ID Report Code Default SIA Report Code RF zone supervision lost 1 381 Loss of supervision - RF Untype zone supervision RF zone supervision restore 3 381 Supervision restore - RF...

  • Page 52: Babyware Options

    Magellan & Spectra SP • Programming Guide BabyWare Options Use worksheet 50 to record your settings for BabyWare options. Worksheet 50: BabyWare Options Section Data Description [910] ___/___/___/___ Panel ID [911] ___/___/___/___ PC password [915] __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__ PC telephone number (landline/GSM communication only) WARNING: For increased communication security, change the default panel ID and PC password.

  • Page 53: Usability Sections

    Magellan & Spectra SP • Programming Guide Worksheet 53: IP Receiver 1 Configuration Section Data Description Default WAN1 IP address (e.g., ); for one or 100.100.100.100 [929] __/__/__ . __/__/__ . __/__/__ . __/__/__ two-digit numbers, add s before the first digit [930] __/__/__/__/__ WAN1 IP port 10000...

  • Page 54: Description Of Sections [966] And [967]

    Magellan & Spectra SP • Programming Guide Description of Sections [966] and [967] Table 50: Description of sections [966] and [967] (clear and reset report codes) Option Description Option Description   Clear zone report codes  Disabled Enabled Reset zone report codes to default ...

  • Page 55: Catalogues Of Special Characters

    Magellan & Spectra SP • Programming Guide Catalogues of Special Characters The following section outlines the different catalogues of special characters, including those in Hebrew, Greek, and Russian. Figure 1: Standard special characters Figure 2: Hebrew special characters Figure 4: Greek special characters Figure 3: Russian special characters A069 Figure 5: Polish, Hungarian, and Turkish special characters...

  • Page 56: Keypad Letter Assignments

    Magellan & Spectra SP • Programming Guide Keypad Letter Assignments The following section outlines the different configurations for keypad letter assignments, including those in Hebrew, Greek, and Russian. Table 53: Standard keypad letter assignment Figure 6: Hebrew keypad letter assignment Press Key Press Key Press Key...
  • Page 57 Magellan & Spectra SP • Programming Guide Table 55: Description of troubles for MG/SP control panels Telephone line monitoring on control panel Fail to communicate on monitoring telephone 1, on control panel Fail to communicate on monitoring telephone 2, on control panel Fail to communicate on voice telephone, on control panel Fail to communicate with PC, on control panel Communication trouble...

  • Page 58: Hardware Connections

    Magellan & Spectra SP • Programming Guide Hardware Connections Single Zone Inputs NOTE: Keyswitches are connected as standard zones and will follow ATZ options 1 and 2, programmed in section [705] (see page 38). Advanced Technology Zone (ATZ) Connections...

  • Page 59: Connecting Fire Circuits

    Auxiliary supply rate • MG5000/MG5050: typ. 600 mA / max. 700 mA requirements. • SP5500/SP6000/SP7000: typ. 600 mA / max. WARNING: Improper connection of the transformer may result in 700 mA damage to the system. • SP4000: typ. 450 mA / max. 600 mA WARNING: Disconnect battery before replacing the fuse.

  • Page 60: Pcb Layouts/Wiring Diagrams

    1 PGM +/- trigger not supported by the MG5000 7 Serial: Used for connecting the IP Internet Module/PCS (Data); also used for In-Field Firmware upgrade through a 307USB Direct Connect 2 Paradox Memory Key (PMC5) Interface 3 EBUS (J3) and Dialer (J4) used with: 8 Panel Reset •...

  • Page 61: Mg5050/Mg5050E

    PGMs are ground (-), or give out 12V (+) for In-Field Firmware upgrade through a 307USB Direct Connect Interface 2 Paradox Memory Key (PMC5) 8 Panel reset 2 EBUS (J3) and Dialer (J4) used with: 9 Refer to Hardware Connections page 58 •...

  • Page 62: Mg5075

    Magellan & Spectra SP • Programming Guide MG5075 Do not cut, bend, or alter the antenna, and ensure that electrical wires do not cross over it, as this may affect signal reception. To provide maximum lightning protection we strongly recommend having separate earth connections for the dialer and zone ground terminals.
  • Page 63 8 Refer to AC Power & Backup Battery Connections on page 3 1 Paradox Memory Key (PMC5) 2 EBUS (J3) and Dialer (J4) used with: 9 The output will shutdown if the current exceeds 3A...
  • Page 64 In-Field Firmware upgrade through a 307USB Direct Connect Interface disconnect all loads from the output for at least 10 sec. before 7 Paradox Memory Key (PMC5) reconnecting any load back to the auxiliary output The sum of the current drawn from the must be limited to 1.3A.
  • Page 65 In-Field Firmware upgrade through a 307USB Direct Connect Interface reconnecting any load back to the auxiliary output 7 Paradox Memory Key (PMC5) The sum of the current drawn from the must be limited to 1.3A. Exceeding this limit will overload the panel power supply BELL and lead to complete system shutdown.
  • Page 66 Voice Module. disconnect all loads from the output for at least 10 sec. before 3 Paradox Memory Key (PMC-4, PMC5) reconnecting any load back to the auxiliary output 4 Used for connecting the IP Internet Module; also used for In-Field 17 For the keypad’s zone configurations, see Installer Quick Menu on page 7;...
  • Page 67 In-Field Firmware upgrade through a 307USB Direct Connect Interface reconnecting any load back to the auxiliary output 7 Paradox Memory Key (PMC5) The sum of the current drawn from the must be limited to 1.3A. Exceeding this limit will overload the panel power supply BELL and lead to complete system shutdown.
  • Page 68 Magellan & Spectra SP • Programming Guide Appendix A EN 50131 Programming The following sections describe all the programming required for your panel to be EN 50131 compliant (MG5050 version 4.96 or higher). NOTE: The Installer Quick Menu is not available anymore for MG5050 V4.96 or higher. To set your panel to be EN 50131 compliant: Enter section [951] to unlock the software and set EN 50131 defaults.
  • Page 69 Magellan & Spectra SP • Programming Guide Table 61: Description of options 3 & 4 and 6 & 7, in section [705] Option Description RF Zone/Hardwired Zone Tamper Recognition Options Keypad/Bus Module Tamper Recognition Options* Disabled Disabled Trouble only Trouble only When disarmed: trouble only;...
  • Page 70 Magellan & Spectra SP • Programming Guide Keypad Lockout Use the following section to program keypad lockout settings for your MG/SP control panel. Use worksheet 30 to record your settings. Worksheet 57: Keypad Lockout Section Data Description Default [716] ___/___/___ 000 to 255 minutes Keypad lockout delay 015 minutes...
