SPECIFICATION
MODEL
DWC-UD1222
Voltage / Frequency
AC 220-240V / 50Hz
Dimension (mm)
630 x 792 x 976 (WxDxH)
Power Consumption
2150 W
Unit Weight (kg)
82(Net) / 88(Gross)
Maximum mass of dry clothes (kg)
Wash: 12Kg (Dry: 7Kg)
Standard Water Consumption
Wash : 95ℓ
Max Spin Speed(PRM)
1200 RPM
Operating Water Pressure
0.03MPa ~ 0.8MPa (0.3kgf/cm
2
~ 8kgf/cm
2
)
WIRING DIAGRAM
Diedarkan Oleh :
Daewoo Electronics Sales & Services (M) Sdn Bhd
Lot 886, Bay B3-B5, Jalan Subang 9, Taman Perindustrian
Subang, Batu 14, Jalan Puchong-Hicom, 47100 Puchong,
Selangor Malaysia.
31
