GOF-3240-OX / PARTS LIST

ITEM PART NO.
** 1 ARM-2010
** 2 ARM-2015
** 3 ARR-1080
* 4 BUG-1393
* 5 BUG-1415
6 BUG-1605
7 BUG-1625-D
8 BUG-1725
9 BUG-1982
* 10 BUG-2923
11 BUG-2924
12 BUG-5188
13 BUG-5451
14 BUG-5462
15 BUG-9103
* 16 BUG-9445
* 17 BUG-9675
18 BUG-9686
19 CIR-1010-3
20 FAS-0112
21 FAS-0114
22 FAS-0124
23 FAS-0155
24 FAS-0654
25 GOF-3001
26 GOF-3002
27 GOF-3003
28 GOF-3008
29 GOF-3014
30 GOF-3015
31 GOF-3016
32 GOF-3017
33 GOF-3018
34 GOF-3019
35 GOF-3022
36 GOF-3025
37 MUG-1258-GOF
38 PAN-1015
*See Electrical Component Chart for 240 VAC and 42 VAC part numbers.
**These items are supplied with GO-FER-OX Kit.
DESCRIPTION
On/Off Magnet Plate Assy.
Spacer Bar Assy.
H.D. Rigid Rail 93.50" (2.37 m)
Volt Trap 120 VAC
Pilot Light 120 VAC
Cam Clutch Assy.
Drive Unit (80:1)
[Includes Item 29]
Speed Control
External Adjustable Leg & Wheel Assy.
Circuit Breaker w/ Reset .7A
Reset Button Seal
Torchholder Assy.
Rackholder w/ Short Handle
Right Angle Clamp
Cord Grip
Power Cord 120 VAC
Transformer 120 VAC
Potentiometer Control & Knob
Twin Hose Assy. 32" (812 mm)
Pan Hd Scr #6-32 x 1/4"
Pan Hd Scr #6-32 x 3/8"
Pan Hd Scr #8-32 x 3/8"
Pan Hd Scr 1/4-20 x 1/2"
Soc Hd Shd Scr 5/16" x 3/8" x 1/4-20
Carriage Assy.
[Includes Items 6, 9, 24, 26, 27, 28]
Carriage Plate
Fixed Leg & Wheel Assy.
Spacer
Drive Pinion w/ Key & Set Screw
Enclosure Assy.
[Includes Items 4, 5, 8, 10, 11, 13, 15-18, 20-22, 31, 33, 34,37]
Cover
End Plate
Rear End Plate
Handle
Back-Up Plate
2-Hose Quick Acting Manifold
Forward/Off/Rev Switch
Rack 22.63" (574 mm)
17
