Bug-O Systems GO-FER III-OX Instructions And Parts Manual page 10

GOF-3250-OX GO-FER III OXY-FUEL KIT (120VAC/50-60Hx/1Ph)
Includes:
1 GOF-3240-OX GO-FER III w/ Dynamic Brake
8-100 ipm (203-2540 mm/min)
Includes:
1 GOF-3025 2-Hose Q.A. Manifold
1 CIR-1010-3 Twin Hose Assembly 32" (812 mm)
1 BUG-5451 Rackholder with Short Handle
1 PAN- 1015 Rack 22.62" (574 mm)
1 BUG-5462 Right Angle Clamp
1 BUG-5188 Torchholder Assembly
1 BUG-9444 Tool Kit
1 ARR-1080 Heavy Duty Rigid Rail 93.5" (2.37 m)
2 ARM-2010 On-Off Magnet Plate Assembly
2 ARM-2015 Spacer Bar Assembly
Same as above except
GOF-3252-OX
w/ 240 VAC GO-FER III
GOF-3242-OX
Same as above except
GOF-3254-OX
w/ 42 VAC GO-FER III
GOF-3244-OX
TECHNICAL DATA (Oxy-fuel)
Power Requirement: - 60 watts at rated voltage:
(Oxy-Fuel) 120 VAC/50-60Hz/1Ph
GOF-3240-OX
(Oxy-Fuel) 240 VAC/50-60Hz/1Ph
GOF-3242-OX
GOF-3244-OX (Oxy-Fuel)
Travel Speed:
Load Capacity:
Magnet Holding Capacity:
Net Weight Of Drive Unit:
Dimensions of Drive Unit:
Rail (Ordered Separately)
Net Weight of Kit:
Shipping Weight of Kit:
10
POSITIVE RACK
AND PINION DRIVE
42 VAC/50-60Hz/1Ph
Ininitely variable from
8-100 ipm (203-2540 mm/min)
15 lbs. (6.8 kg) vertical or
60 lbs. (27.3 kg) horizontal
250 lbs. (113 kg)
17 lbs. (7.7 kg)
10" L x 8" W x 13" H
(254 mm x 203 mm x 330 mm)
4' (1.18 m) ARR-1085
8' (2.37 m) ARR-1080
39 lbs. (17.7 kg)
50 lbs. (22.7 kg)
CONVENIENT
CARRYING HANDLE
ON/OFF MAGNET
ASSEMBLY (2)
TWIN HOSE ASSEMBLY
32" (812 mm)
2-HOSE QUICK ACTING
MANIFOLD
HEAVY DUTY
RIGID RAIL
TOOL KIT
TORCHHOLDER
ASSEMBLY
SPACER BAR
ASSEMBLY (2)
