red lion Graphite G07 Series Installation Manual

7" color touchscreen operator interface terminal

Advertisement

Quick Links

Inside US: +1 (877) 432-9908

Outside US: +1 (717) 767-6511
www.redlion.net
Model G07 ‐ Graphite® Series 7" Color Touchscreen Operator Interface
U L
C
US LISTED
IND. CONT. EQ.
34AD
U L
C
US
FOR USE IN HAZARDOUS LOCATIONS:
Class I, Division 2, Groups A, B, C, and D
LISTED
Class II, Division 2, Groups F and G
Class III, Division 2
IND.CONT. EQ.
3PWL
T4
II 3 G Ex ic nA IIC T4 Gc
II 3 D Ex tc IIIC T135°C Dc
-20°C ≤ T
DEMKO 14 ATEX 1387X
IECEx UL 15.0035X
See the Red Lion website at www.redlion.net or the
enclosed USB thumbdrive for full user manual, Crimson®
software and software manual.
SAFETY SUMMARY
All safety related regulations, local codes and instructions that appear
in the manual or on equipment must be observed to ensure personal
safety and to prevent damage to either the instrument or equipment
connected to it. If equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment may be
impaired.
Do not use the controller to directly command motors, valves, or other
actuators not equipped with safeguards. To do so can be potentially
harmful to persons or equipment in the event of a fault to the unit.
WARNING - EXPLOSION HAZARD - DO NOT D
CAUTION: Risk of Danger.
EQUIPMENT UNLESS POWER HAS BEEN SW
Read complete instructions prior to installation
OR AREA IS KNOWN TO BE NON-HAZARDOU
and operation of the unit.
WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT
WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT
EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF
EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF
OR AREA IS KNOWN TO BE NON-HAZARDOUS.
OR AREA IS KNOWN TO BE NON-HAZARDOUS.
WARNING - EXPLOSION HAZARD - SUBSTITUTION OF
COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS I,
DIVISION 2.
DIMENSIONS In inches (mm)
5.51
(139.9)
Terminal Installation Guide
≤ 60°C
AMB
7.70 (195.5)
ORDERING INFORMATION
DESCRIPTION
7" Color Touch Screen, Indoor Use
7" Color Touch Screen, Indoor/Outdoor Use
SPECIFICATIONS
POWER:
Input Voltage 10V
Typical Power HMI only: 7 W
Maximum Power HMI only: 12 W
Available Power for Modules:
Max Power HMI With Module(s): 33 W
Must use a Class 2 circuit according to National Electrical Code
(NEC), NFPA-70 or Canadian Electrical Code (CEC), Part I, C22.1
or a Limited Power Supply (LPS) according to IEC/EN 60950-1 or
Limited-energy circuit according to IEC/EN 61010-1.
Power connection via removable three position terminal block.
ENVIRONMENTAL CONDITIONS:
Operating Temperature Range: -20 to 60 °C, or lowest range among
equipment used in your Graphite system. Consult the user manual
2.00 (50.8)
2.97 (76)
Module sold
separately
(MOUNTING CLIPS INSTALLED)
-1-
Bulletin No. G07-F
Drawing No. LP0907
Released 2017-03-30
PART NUMBER
G07C0000
G07S0000
G07C
G07S
24V
30V
10V
24V
7 W
8 W
8 W
9 W
13 W
14 W
13 W
14 W
21 W
21 W
34 W
35 W
34 W
36 W
7.9 (202)
5.7
(146)
30V
9 W
15 W
36 W
