red lion Graphite 7 Series Installation Manual

Model G07 - Graphite
Touchscreen Operator Interface Terminal
Installation Guide
U L
C US LISTED
R
IND. CONT. EQ.
E302106
U L
FOR USE IN HAZARDOUS LOCATIONS:
C C US US
Class I, Division 2, Groups A, B, C, and D
R
Class II, Division 2, Groups F and G
LISTED
Class III, Division 2
IND.CONT. EQ.
T4
E317425
See the Red Lion website at www.redlion.net or the enclosed USB
thumbdrive for full user manual, Crimson
manual.

SAFETY SUMMARY

All safety related regulations, local codes as well as instructions
that appear in this document or on equipment must be observed
to ensure personal safety and to prevent damage to either the
device or equipment connected to it.
Do not use these products to replace proper safety interlocking.
No software-based device (or any other solid-state device) should
ever be designed to be responsible for the maintenance of
personnel safety or consequential equipment not equipped with
safeguards. Red Lion disclaims any responsibility for damages,
either direct or consequential, that result from the use of this
equipment in a manner not consistent with these specifications.
CAUTION: Risk of Danger.
Read complete instructions prior to
installation and operation of the unit.
WARNING - EXPLOSION HAZARD - Do not
disconnect equipment unless power has been
switched off or area is known to be non-hazardous.
WARNING - EXPLOSION HAZARD - Substitution
of components may impair suitability for Class I,
Division 2.
DIMENSIONS In inches [mm]
5.51
[139.9]
®
II 3 G Ex ic nA IIC T4 Gc
II 3 D Ex tc IIIC T135°C Dc
° °
-20 C ≤ T ≤ 60 C
AMB
DEMKO 14 ATEX 1387X
IECEx UL 15.0035X
UL23UKEX2879X
®
software and software
7.70 [195.5]
Series 7" Color

ORDERING INFORMATION

DESCRIPTION
7" Color Touch Screen, Indoor Use
7" Color Touch Screen, Indoor/Outdoor Use

SPECIFICATIONS

POWER:
Input Voltage
Typical Power HMI only:
Maximum Power HMI only: 12 W
Available Power for Modules:
Max Power HMI With Module(s) 33 W
Must use a Class 2 circuit according to Nation Electrical Code
(NEC), NFPA-70 or Canadian Electrical Code (CEC), Part I,
C22.1 or a Limited Power Supply (LPS) according to IEC/EN
60950-1 or Limited-energy circuit according to IEC/EN
61010-1.
Power connection via removable three position terminal block.

ENVIRONMENTAL CONDITIONS:

Operating Temperature Range: -20 to 60 °C, or lowest range
among equipment used in your Graphite system. Consult the
user manual or
Storage Temperature Range: -20 to 70
Vibration to IEC 68-2-6: Operational 5-500 Hz, 4 g
2.00 [50.8]
2.97 [76]
Module sold
separately
(MOUNTING CLIPS INSTALLED)
1
Drawing No. LP0907
G07C
10 V 24 V 30 V 10 V
7 W 7W 8W 8 W
13 W 14 W 13 W
21 W
34 W 35 W 34 W
www.redlion.net/OpTemp for further details.
°
C
7.9 [202]
5.7
[146]
Install - G07-G
Revised 11/2023
PART NUMBER
G07C0000
G07S0000
G07S
24 V 30 V
9 W 9W
14 W 15 W
21 W
36 W 36 W
