- Page 1 EN - User’s manual AC/DC current clamp...
- Page 2 To identify the phase (or the direction) of the primary current. Chauvin Arnoux has adopted an Eco-Design approach in order to design this appliance. Analysis of the complete life- cycle has enabled us to control and optimize the effects of the product on the environment. In particular this appliance exceeds regulation requirements with respect to recycling and reuse.
-
Page 3: Table Of Contents
1.1. Delivery condition ................................4 1.2. Accessories ..................................4 1.3. Inserting the battery ................................ 4 1.4. Functions ..................................4 1.5. E25 clamp ..................................5 2. USE ......................................6 2.1. Getting started ................................6 2.2. Zero adjustment ................................6 2.3. Measurement .................................. 6 2.4. -
Page 4: Presentation
1.4. FUNCTIONS The E25 clamp is used to measure currents from 5mA to 80ADC OR 60AAC without opening the circuits in which they flow. It reads out the waveform and amplitude of the current being measured, in the form of a voltage. -
Page 5: E25 Clamp
1.5. E25 CLAMP Mobile jaw. Fixed jaw. Arrow indicating the direction of current flow. 2 male banana plugs 4mm in diameter. Guard. Mobile arm. 600 V CAT III Reset button. Zéro ON and OL indicators. Three-position slide switch. 1 V/A... -
Page 6: Use
2. USE 2.1. GETTING STARTED Switch the clamp on by pushing the slide switch to the 1V/A or the 10mV/A setting. The 1V/A setting corresponds to the 2A range. The 10mV/A setting corresponds to the 80A range. The ON indicator lights green. If it blinks, there remain less than 4 hours of use. If it fails to light, you must replace the battery (see §... -
Page 7: Auto Off
If the OL indicator lights, it means that the current is too strong to be measured. If you are in the 1V/A range, switch to the 10mV/A range. „ Apply the conversion factor corresponding to the setting of the switch. 1 V/A 10 mV/A 150 mV... -
Page 8: Specifications
3. SPECIFICATIONS 3.1. REFERENCE CONDITIONS Quantity of influence Reference values Temperature 23 ± 5 °C Relative humidity 20 to 75%RH Position of the conductor centred Frequency of the measured signal DC to 65Hz sine wave by battery: 6.5 to 9 V Powered external supply: 5 V ±... - Page 9 Typical amplitude error curve for a 60Hz AC current, 10mV/A range Error (%) 14,00 12,00 10,00 8,00 6,00 4,00 2,00 0,00 -2,00 -4,00 -6,00 -8,00 -10,00 -12,00 -14,00 Current (Aac) 3.2.2. NOISE Typical noise level at output 10mV/A range ± 120 µVdc 180 µVrms Calibre 1V/A ±...
- Page 10 Typical amplitude error curve as a function of frequency, I = 0,5A, 1V/A range Error (%) -5dB -10dB -15dB -20dB -25dB -30dB Frequency (Hz) 1000 10000 100000 1000000 Typical amplitude error curve as a function of frequency, I = 1A, 10mV/A range Phase shift (°) 0,00 -20,00...
-
Page 11: Operating Limits
3.2.5. PULSE RESPONSE Pulse response at ±2 Apeak at the frequency of 1 kHz in the 10mV/A range Reference signal Clamp Pulse response at ±0.5 Apeak at the frequency of 1 kHz in the 1V/A range Reference signal Clamp 3.3. OPERATING LIMITS „... -
Page 12: Variations In The Range Of Use
3.4. VARIATIONS IN THE RANGE OF USE Error in % of reading Quantity of influence Range of influence Typical Maximum Drift of the zero ± 10 mA/°C Temperature -10 to + 50 °C Drift of the gain ± 800 ppm/°C Relative humidity 0 to 85%HR <... -
Page 13: Construction Specifications
3.7. CONSTRUCTION SPECIFICATIONS Dimensions (L x W x H) 231 x 36 x 67 mm Weight approximately 330 g Measurement lead 1.5 m long USB cord 15 cm long Clamping capacity: 11.8mm in diameter Protection by the housing „ IP 20 per IEC 60529 „... -
Page 14: Maintenance
4. MAINTENANCE Except for the battery, the instrument contains no parts that can be replaced by personnel who have not been specially trained and accredited. Any unauthorized repair or replacement of a part by an “equivalent” may gravely impair safety. 4.1. - Page 15 5. Clamp a conductor carrying a current of: „ 10Aac 60Hz for the 10mV/A range „ 1Aac 60Hz for the 1V/A range 6. Then press the DC Zero button. The first press substantially lowers the polarization adjustment of Hall effect sensors. Subsequent presses increase this adjustment by one step.
-
Page 16: Warranty
5. WARRANTY Except as otherwise stated, our warranty is valid for 24 months starting from the date on which the equipment was sold. Extract from our General Conditions of Sale provided on request. The warranty does not apply in the following cases: „... - Page 18 FRANCE INTERNATIONAL Chauvin Arnoux Chauvin Arnoux 12-16 rue Sarah Bernhardt Tél : +33 1 44 85 44 38 92600 Asnières-sur-Seine Fax : +33 1 46 27 95 69 Tél : +33 1 44 85 44 85 Our international contacts Fax : +33 1 46 27 73 89 info@chauvin-arnoux.com...
