Summary of Contents for EKO MS-56
-
Page 2: Table Of Contents
A- 2. T h erm is t or Tem pe rat ur e Co n v er s io n Tab l e A- 3. Pt 10 0 C l as s A C o n ver s i o n Tab l e Pg. 1 EKO INSTRUMENTS CO., LTD. MS-56 Pyrheliometer Manual Ver.5... -
Page 3: Important User Information
For warranty terms and conditions, please contact EKO Instruments or your distributer for further details. EKO guarantees that the product delivered to customer has been tested to ensure the instrument meets its published specifications. The warranty included in the conditions of delivery is valid only if the product has been installed and used according to the instructions provided in this operating manual. -
Page 4: A Bo Ut Op Er Ati Ng Ma Nu Al
2- 3. A bo ut Op er ati ng Ma nu al Copy Rights Reserved by EKO INSTRUMENTS CO., LTD. Making copies of whole or part of this document without permission from EKO is prohibited. This manual was issued: 2016/10/06 Version Number: 5 2- 4. -
Page 5: Ce D Ec La Ra Ti O N
Amendment to the above directive: 93/68/EEC Date: April 28, 2011 Position of Authorized Signatory: Deputy General Manager of Quality Assurance Dept. Name of Authorized Signatory: Shuji Yoshida Signature of Authorized Signatory: Pg. 4 EKO INSTRUMENTS CO., LTD. MS-56 Pyrheliometer Manual Ver.5... -
Page 6: Safety Information
3. Safety Information EKO Products are designed and manufactured with consideration for safety; however, please make sure to read and understand this instruction manual thoroughly to be able to operate the instrument safely in the correct manner. WARNING Attention to user; pay attention to the instructions given on the CAUTION instruction manual with this sign. -
Page 7: Introduction
The MS-56 has a standard full 5° (degrees) opening angle and 1° slope angle as defined by ISO Pyrheliometers Standards and greatly performs when used in combination with the EKO STR-21(G) or STR-22(G) Sun Tracker. -
Page 8: C Ont En T Of Deliv E R Y
4- 2. C ont en t of Deliv e r y Check the package contents first; if any missing item or damage is noticed, please contact EKO immediately. (Standard Length: 10m) Figure 4-1. Package Contents Pg. 7 EKO INSTRUMENTS CO., LTD. MS-56 Pyrheliometer Manual Ver.5... -
Page 9: Getting Started
(Class A Pt100) to extend further research applications. Although the MS-56 dimensions are relatively small, it has a full 5° opening angle and 1° slope angle geometry. The front aperture has a unique integrated alignment sight for easy and precise alignment of the instrument on a Sun Tracker. -
Page 10: Se Tu P
5- 2. Se tu p 1. Installation In this application the MS-56 is mounted on the EKO Sun Tracker STR-21G/22G, which is a fully automatic sun tracking system supporting solar sensors capable of measuring Direct, Diffuse and Global radiation. X/Y-Axis... - Page 11 2. How to Replace the Mounting Plate (Optional) When installing MS-56 on EKO Sun Tracker STR-21G/22G, 3-hole mounting plate is required. If you already have EKO Sun Tracker purchased before July 2011, you need to purchase the “3-hole mounting plate” (optional part) separately for installing MS-56.
- Page 12 Arm, and remove the fixing screws on both V-Blocks (M3 x 5mm in 2 places on each V-Block). Disassembling is completed and the 2-hole mounting plate is replaced with 3-hole mounting plate. Pg. 11 EKO INSTRUMENTS CO., LTD. MS-56 Pyrheliometer Manual Ver.5...
- Page 13 In order to measure the solar irradiance, the MS-56 should be connected to a measurement device, in most cases a data logger. MS-56 is a passive sensor that does not need any power; however to operate the window heater, a DC12V (0.5W) power supply is required for heating.
- Page 14 4. Sight Spot Adjustment In order to take an accurate measurement, MS-56 has to be aligned with the sun properly. When the sky is clear, the sun light will go through the sight and a spot of light is shown on the sight spot surface of body top.
-
Page 15: O P Er At I On
5- 3. O p er ati o n After installing and connecting MS-56 to the measurement device, MS-56 can be operated and is ready to collect solar radiation data. It is recommended to use the window heater to prevent dew deposition at the Quartz window. Turn on the heater at least 30 minutes before sunrise. -
Page 16: Maintenance & Troubleshooting
6. Maintenance & Troubleshooting 6- 1. Mai nt en a nc e Once the MS-56 is installed, it is essentially free of any maintenance although care must be taken to keep the instrument in the best condition for accurate measurement. - Page 17 3) Take off the inner lid. 4) Exchange the desiccant then put the inner lid back on the cartridge. Place the drying cartridge back on the MS-56 body and secure it gently. Pg. 16 EKO INSTRUMENTS CO., LTD. MS-56 Pyrheliometer Manual Ver.5...
-
Page 18: C Alib Ra Ti On An D Me As U Re Me Nt U Nc E Rtaint Y
Davos (CH). Both MS-56 and reference pyrheliometer are mounted on a Sun Tracker to capture the direct solar radiation. The direct solar radiation is measured based on 1 minute samplings for total of more than 2 hours both in the morning and the afternoon on a clear day. -
Page 19: Tro Ubl Es Hoo Ti N G
Check if the voltage reading is divided by the correct unrealistically high or low. sensitivity value. 2. Check the sight spot and make sure the MS-56 is aligned to the direction of the sun. Although the sensor is hardly susceptible to Electro Magnetic... -
Page 20: Specification
Every 2 years - - - - - - - Pt100 Class A, Sensor for Temperature Measurement IEC751 Compliance - - - - - - (Internal Temperature Measurement) - Thermister 44031, 10kΩ@25℃ Pg. 19 EKO INSTRUMENTS CO., LTD. MS-56 Pyrheliometer Manual Ver.5... -
Page 21: Spec I Fic A Ti On D Efi Ni Tio N S
A response time of less than 1s to achieve 95% of the final measurement value is one of the unique features of the MS-56. The small thermopile detector having a low heat capacitance and high thermal conductivity responds quickly to changes of the solar radiation. To keep the detector-output stable and in perfect thermal balance during changing environmental and solar radiation conditions, the detector body is isolated from the sensor housing. - Page 22 In general the sensitivity of optical detectors depends on the temperature of the instrument because of material properties, known as the temperature coefficient (TC). However the MS-56 sensor construction has a built in special passive compensation network which reduces the temperature dependency to less than +/-0.5% between –20...
-
Page 23: P Rod Uc T Ac C Es S O Ries
Cable Length* 20, 30, 40, 50m Fixing Ring STR-21/22 Mounting Jigs Mounting Plate (3-holes) Drying Cartridge Drying Cartridge Replacement Silica Gel Replacement Silica Gel (desiccant) container (500g) *Standard cable length: 10m Pg. 22 EKO INSTRUMENTS CO., LTD. MS-56 Pyrheliometer Manual Ver.5... -
Page 24: Appendix
APPENDIX A- 1. S ymb ol s Table A-1 Definitions of Symbols List of symbols Definitions Units μ Output Voltage μV/W･m Sensitivity Time τ Response Time Temperature °C Solar Irradiance Pg. 23 EKO INSTRUMENTS CO., LTD. MS-56 Pyrheliometer Manual Ver.5... -
Page 25: A- 2. Th Er Mis T Or Tem Pe Ra Tu R E Con V E Rs Io N Table
47540 12260 3893 45270 11770 3758 43110 11290 3629 41070 10840 3504 39140 10410 3385 37310 10000 3270 35570 9605 3160 33930 9227 3054 32370 8867 2952 30890 8523 2854 Pg. 24 EKO INSTRUMENTS CO., LTD. MS-56 Pyrheliometer Manual Ver.5... -
Page 26: A- 3. Pt1 00 Cl As S A C Onv E R S Ion Ta Ble
96.1 107.8 119.4 96.5 108.2 119.8 96.9 108.6 120.2 97.3 109.0 120.6 97.7 109.3 120.9 98.0 109.7 121.3 98.4 110.1 121.7 98.8 110.5 122.1 99.2 110.9 122.5 99.6 111.3 122.9 Pg. 25 EKO INSTRUMENTS CO., LTD. MS-56 Pyrheliometer Manual Ver.5...
