  • Page 1 MS-713 INSTRUCTION MANUAL Grating Spectroradiometer...
  • Page 2 9- 3 . Tr o ub l es h o ot i n g 10. Specification 10- 1 . S ens or Sp ec if ic a ti o ns Pg. 1 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 3 10- 2 . S oft war e 10- 3 . Ca b l es 10- 4 . Dim e ns i o ns 10- 5 . Ac c es s or ies Lis t Pg. 2 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...

  • Page 4: Important User Information

    For warranty terms and conditions, contact EKO or your distributor for further details. EKO guarantees that the product delivered to customer has been verified, checked and tested to ensure that the product meets the appropriate specifications. The product warranty is valid only if the product has been installed and used according to the directives provided in this instruction manual.
  • Page 5 Copy Rights Reserved by EKO INSTRUMENTS CO., LTD. Making copies of whole or parts of this document without permission from EKO is prohibited. This manual was issued: 2019/07/29 Version Number: Pg. 4 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...

  • Page 6: Safety Information

    Installation base or mast should have enough load capacity to set the Grating Spectroradiometers MS-713. Fix MS-713 securely to the base or mast with bolts and nuts. Carefully install the computer as well. The instrument/computer may drop due to gale or earthquake and vibration, and may invite unexpected accidents.
  • Page 7 EKO Instruments will not be held responsible in case of accidents or measurement accuracy by using cables other than specified by EKO. 3. Handling  Hold the bottom part of the instrument firmly when carrying this instrument.  Holding the cover, glass dome or any other part of this instrument can lead to damage or dropping instrument.
  • Page 8 Therefore, it provides improved stability for continuously measuring outdoor, and excellent robustness in transportation for cyclic measurements. MS-713 have a separate power supply and can be controlled through RS232 / 422 by a PC or data logger. The PC software provide different fuctions for operating, data management and visualisation.

  • Page 9: Main Features

    MS-713 can be used for a long-term outdoor measurement. 2. Wide Measurement Range By combining the MS-711 (300nm to 1,100nm) and MS-713(900nm to 2,500nm), it is possible to measure a wide wavelength range from 300nm to 2,500nm. 3. Operating Software The operating software has different measurement functions, to make either a “single measurement”...

  • Page 10: Package Contents

    4- 2. Pac k ag e Co nte nts Check the package contents first; if any missing item or damage is noticed, please contact EKO immediately. Table 4-1. Package Contents Standard Items Qty. Remarks Sensors Power supply unit Set of Sensor fixing screws Bolts: M8 x 230, Washers, Nuts (2pcs/set) φ5.2x20, 250V, 2A...

  • Page 11: Consumable Items

    4- 3. C ons um a bl e It ems MS-713 contains following consumable items. These items are not covered under warranty. Table 4-2. Consumable Items Standard Items Qty. Remarks Approx. Particle size: 2 to 3mm Silica Gel Replace when the color changed to red.

  • Page 12: Getting Started

    MS-713. Ventilation Power Connect ventilation power supply cable Supply Connector ④ ③ ⑦ ① ⑤ ② ⑥ ⑪ ⑨ ⑧ ⑩ Figure 5-1. Parts Name and Function (Sensor) Pg. 11 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 13 Voltage range is AC100 to 240V, frequency is 50 / 60Hz. Grounding Terminal Use this terminal when AC power supply is not grounded. ① ④ ③ ⑤ ⑥ ② Figure 5-2. Parts Name and Function (Power Supply Part) Pg. 12 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 14 2. Installing at Horizontal or tilted Positions Prepare Installation Base Check the installation base where the MS-713 has to be mounted and make sure it has two fixing holes with the appropriate pitch. The pitch sizes of the fixing holes are as follows (in mm): Table 5-3.
  • Page 15 If the sensor is not leveled properly, the readings are affected by cosine and azimuth errors. Periodically check the spirit level and adjust its position if necessary. Adjust Height To take measurements by setting up the MS-713 side by side, the sensor surface must be adjusted to the same height level. Cover Place the Cover on the instrument and fasten with 3 screws (M3).
  • Page 16 Connect the PC COM port and the RS-232C connector at the back of the power supply with RS-232C cable. When connecting, insert the connector which has ferrite core to the power supply. Pg. 15 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...

  • Page 17: Installation And Uninstallation

    6. Software This software is exclusively used for measuring and processing the data acquired by MS-713. It is used for taking measurements and analyzing data. Below describes the system configuration. MS-713 [WSDac_V5.0.x.x.exe] RS232C Measurement Software RS422 [WSDisp_V5.0.x.x.exe] Power Data Analysis Software...
  • Page 18 [Next] button to go to the next step. Figure 6-3. License Agreement Window “Destination Folder” window appears. If the software will be installed in the “C:\EKO” folder, click [Next] button to go to the next step. To change the destination folder, click [Change…] button and select the appropriate folder.
  • Page 19 Figure 6-6. User Account Control Window As the installation is completed, the following window appears. Click [Finish] button to close the installation window. Figure 6-7. Installation Complete Window Pg. 18 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 20 When the installation is completed, a shortcut icon as shown below will be created on the desktop, as well as under the Start Menu, “All Programs”  “EKO”  “WISER”. Figure 6-8. Software Shortcut Icon 2. Uninstallation There are 2 ways to uninstall the software.
  • Page 21 “Modify”, “Repair” and “Remove”. Select “Remove” from this window and click [Next] button. Follow the messages on each step will result in uninstalling the software. Figure 6-11. Uninstalling from CD-ROM Pg. 20 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 22 [Measured Value of CSV Data File] Radiation data of each wavelength is saved. This file contains the instrument data (MS-711, MS-712, MS-713, or Merge) which is selected ahead of time. See “CSV Format Data” in section “7-2 Before Starting Measurements”...
  • Page 23 Integral[300-1800](W/m 7:00:00 25.49 117.8 5935.9 138.2 7:01:00 25.5 117.8 5937.1 139.5 7:02:00 25.46 117.7 5931.2 131.7 Measured PPFD ILLUMINANCE Radiation Integrated Date & Time Data Data Data Data Pg. 22 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 24 WSD file. In each data measurement, the most appropriate exposure time is automatically setup by the software and takes and save the spectrum data. NOTE: When taking measurements by switching multiple units of MS-713 on one computer, make sure to do the following: Restart the software each time the instrument is switched.

  • Page 25: Be Fo Re Star Ti N G M Eas U R Eme Nt

    Select Data to saved in CSV be saved in CSV Format Folder Location Auto-Start After for saving CSV Software Format Data Starting Checkbox Figure 7-3. Measurement Setup Window Pg. 24 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 26 Wavelength Pitch is setup with “1nm”. Data Selection Saves the data of the instrument which is selected. When measuring the MS-711 and MS-713 at the same time, the combined data of MS-711 and MS-713 can be saved by selecting “Merge.” Folder for Saving Click [Browse] button to specify the folder for data to be saved.
  • Page 27 The statuses of the measuring instruments are displayed. The Table 7-2 describes the meaning of each message and status, and how to deal with the statuses. Abort Button Terminates the manual or interval measurement. Pg. 26 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 28 MS711 Measurement failed. ERROR MS712 MEAS MS712 Measurement failed. ERROR MS713 MEAS MS713 Measurement failed. ERROR WSD SAVE WSD File Saving failed. ERROR CSV SAVE CSV File Saving failed. Pg. 27 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 29 [Integration Range] in the Measurement Setting. [Instrument Information]: Displays the information of [Buildup Time (Exposure Time)], [Sensor Temperature], [Power Supply Voltage], and [Sensor Cooler Drive (MS-712 or MS-713)] Pg. 28 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 30 Clicking [Apply] button will allow the user to see the changes on the graph with the Graph Setting window still opened. [Cancel] button can cancel the setting changes on the Graph Setting. Pg. 29 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...

  • Page 31: Version Information

    The software version information can be displayed. Go to [Help  About WSDac…] from the tool bar or click the [?] button (Figure 7-13) at the top to see the software version information. About Button Figure 7-13. About Button Pg. 30 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 32 8- 1. Sta rti ng Da ta A nal ys i s So ft wa re C S VDi s p .e x e As the CSVDisp is started, the Figure 8-1 Window is displayed. Figure 8-1. WSDips_V3.0.x.x.exe Window Pg. 31 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 33 Double click the data shown on the Tiled Data window, or go to [View  Selected Data] on the tool bar, or clicking the [Selected Data] button (Figure 8-4) will display the “Tiled Data window” as shown on Figure 8-5. Selected Data Button Figure 8-4. Selected Data Button Pg. 32 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 34 [Integration Range] in the Measurement Setting. [Instrument Information]: Displays the information of [Buildup Time (Exposure Time)], [Sensor Temperature], [Power Supply Voltage], and [with/without Sensor Cooled Drive] Pg. 33 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 35 [Shift] key, click the last data in the range. The data can be selected as shown on the Figure 8-7. Also by using [Ctrl] key, the desired multiple data can be selected. Figure 8-7. Selecting Multiple Data Pg. 34 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 36 [COLOR TABLE]. Also by adding the number of lines, more than 10 colors can be registered. WSDisp.ini File [COLOR_TABLE] #LINE_COLOR001=R,G,B LINE_COLOR001=255,0,0 LINE_COLOR002=255,94,25 LINE_COLOR003=251,236,53 LINE_COLOR004=128,255,0 LINE_COLOR005=0,255,0 LINE_COLOR006=0,255,128 LINE_COLOR007=0,255,255 LINE_COLOR008=0,128,255 LINE_COLOR009=0,0,255 LINE_COLOR010=128,0,255 Pg. 35 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...

  • Page 37: Deleting Data

    In order to setup the range or pitch of wavelength for saving data in CSV format, contents of the data to be saved (MS-711, MS-713, or to merge), or setup the integration range, click the [Data Settings] button. Go to [File ...
  • Page 38 Clicking [Apply] button will allow the user to see the changes on the graph with the Graph Setting window still opened. [Cancel] button can cancel the setting changes on the Graph Setting. Pg. 37 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...

  • Page 39: D Ata S Av I Ng

    NOTE: If the CSV converted data is lined more than 256, error message may appear when the file is opened, depending on the spreadsheet software type. If such error message appears, convert into CSV when there are less than 256 data lines. Pg. 38 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 40 The software version information can be displayed. Go to [Help  About WSDisp…] from the tool bar or click the [?] button (Fig. 8-17) at the top to see the software version information. About Button Figure 8-17. About Button Pg. 39 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...

  • Page 41: Maintenance And Troubleshooting

    2 years. Contact EKO for more details and requests for a recalibration and maintenance service. Pg. 40 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...

  • Page 42: C Al I B Ra Ti On Me Th Od

    EKO for assistance - S/N value of acquired data is 2) If multiple MS-713 are connected to one PC to operate, make sure to restart not good. the software each time the instrument is switched.

  • Page 43: Sensor Specification

    Difference from the theoretical value (cos θ) at zenith angle of 0° to 80° Cosine Response Tolerance of change in output when ambient temperature changes between Temperature Dependency -30℃ to +50℃. Exposure Time Shutter open time. Pg. 42 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...

  • Page 44: Power Supply Unit

    Temperature:-20 to +70℃ IP Classification IP55 Housing Model No.: 03T-JWPF-VSLE-S Terminals Contact Model No.: SWPT-001T-P025 Manufacturer: J.S.T.MFG.CO.,LTD. Input: 100-240VAC Output 12VDC, 1A AC Adapter Model No. UIA312-12-EIAJ-4 Manufacturer: Unifive Pg. 43 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 45 Interface: Measurement Software: WSDac, Version: 5.0.x.x Software Name/Versions Data Analysis Software: WSDisp, Version: 5.0.x.x Data Measurement (Continuous measurement, single measurement) Data Saving (CSV format) Software Function Data Graphing Pg. 44 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 46 Table 10-6. Cable Specifications Cable Name Details Cable Type： MVVS Diameter: 0.5mm x 12pins Φ10.4mm Outer Diameter: Sensor Cable Cable end: Y Terminal (1.25Y-4) Cable Length: Figure 10-1. Sensor Cable Connections Pg. 45 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 47 φ4.8mm Ventilation Unit Power Supply Outer Diameter: Cable ends: AD Adapter side: THB387-3P Cable Ventilation Unit side: NJW-163-PF Cable Length: Figure 10-2. Ventilation Unit Power Supply Cable Connections Pg. 46 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...

  • Page 48: Sensor Part

    10 -4 . Di me ns i ons 1. Sensor Part Figure 10-3. Sensor Part Dimensions Pg. 47 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 49 2. Power Supply Figure 10-4. MS-713 Power Supply Pg. 48 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 50 Maximum static pressure: 70.4 Pa Spare Ventilation Expected Life: 100000hr / 60℃ IP Class: IP55 No ribs Frame Materials: Aluminum [Specification of Terminal] Housing Model: 03T-JWPF-VSLE-S Contact Model: SWPT-001T-P025 Manufacturer: J.S.T.MFG.CO.,LTD. Pg. 49 EKO INSTRUMENTS CO., LTD Grating Spectroradiometer MS-713 Instruction Manual Ver5...
  • Page 51 EKO Asia, Oceania 1-21-8 Hatagaya, Shibuya-ku, Tokyo 151-0072 Japan P. +81.3.3469.6711 F. +81.3.3469.6719 info@eko.co.jp www.eko.co.jp EKO North America 111 North Market Street, Suite 300, San Jose, CA 95113, USA P. +1-408-977-7751 F. +1-408-977-7741 info@eko-usa.com www.eko-usa.com EKO Europe, Middle East, Africa,...
