EKO MS-40S Instruction Manual

Pyranometer iso9060:2018 class c iso9060:1990 second class
Hide thumbs Also See for MS-40S:
Table of Contents

Advertisement

Quick Links

Download this manual
MS-40
INSTRUCTION MANUAL
Pyranometer
ISO9060:2018 Class C
ISO9060:1990 Second Class
MS-40S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-40S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EKO MS-40S

Summary of Contents for EKO MS-40S

  • Page 1 MS-40 INSTRUCTION MANUAL Pyranometer ISO9060:2018 Class C ISO9060:1990 Second Class MS-40S...

  • Page 2: Table Of Contents

    A- 5. C om m un ic a t io n S pec if ic a t io ns [ M S - 4 0 S SD I - 12 ] A- 6. R ec al i br at i on EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 2...

  • Page 3: Important User Information

    For warranty terms and conditions, please contact EKO Instruments or your distributer for further details. EKO guarantees that the product delivered to customer has been tested to ensure the instrument meets its published specifications. The warranty included in the conditions of delivery is valid only if the product has been installed and used according to the instructions provided in this operating manual.

  • Page 4: A Bo Ut Op Er Ati Ng Ma Nu Al

    2- 3. A bo ut Op er ati ng Ma nu al Copy Rights Reserved by EKO INSTRUMENTS CO., LTD. Making copies of whole or part of this document without permission from EKO is prohibited. This manual was issued: 2019/7/30 Version Number: 4 2- 4.

  • Page 5: I So / I

    EKO is a unique manufacturer who can offer calibration service for pyranometers and pyrheliometers in-house. Based on the applied calibration methods EKO provides the best quality solar sensor calibrations compliant to the international standards defined by ISO/IEC17025 / 9847 [Indoor method] and ISO9059 [Outdoor method] [Certification: L13-94-R2 / www.pjlabs.com]...

  • Page 6: Ce D Ec La Ra Ti O N

    Date: April 4 , 2019 Position of Authorized Signatory: General Manager of R & D Department Name of Authorized Signatory: Shuji Yoshida Signature of Authorized Signatory: EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 6...

  • Page 7: Safety Information

    3. Safety Information EKO Products are designed and manufactured with consideration for safety; however, please make sure to read and understand this instruction manual thoroughly to be able to operate the instrument safely in the correct manner. WARNING Attention to user; pay attention to the instructions given on the CAUTION instruction manual with this sign.
  • Page 8 EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 8...

  • Page 9: Introduction

    2. MS-40S The MS-40S with smart sensor technology and onboard diagnostic functions. 4 different output types can be selected, which is a great benefit for system integrators who work with various industrial standards. This new Smart transducer will also have additional features such as internal temperature and humidity sensors and a tilt sensor for remote sensor diagnostics.

  • Page 10: Pac K Ag E Co Nte Nt S

    Humidity and temperature sensor to monitor the sensor temperature and condition of the drying agents (silica gel) inside the sensor body. 4- 2. Pac k ag e Co nte nt s Check the package contents first; if any missing item or damage is noticed, please contact EKO immediately. Table 4-1. Package Contents Contents...

  • Page 11: Getting Started

    Besides the mechanical protection, the optical properties of the glass dome minimize the undesired influence of long wave radiation on the shortwave radiation: the dome of the EKO pyranometers is only transparent for radiation emitted by the sun. Hence they block the undesired infrared radiation emitted by the Earth’s atmosphere.
  • Page 12 Durable materials are used for the cable and connector, and pin terminals are attached at the end of the cable for easy connection with data logger terminal block. * If longer cables, round terminals or fork terminals are required, please contact EKO Instruments or your distributor. [Also see [7. Specification, 7-4. Accessories List] for optional items.] The connector should be protected by the self-fusing tape when the pyranometers are used in the areas with the risk of the salt damage.

  • Page 13: Se Tu P

    If the pyranometer is not levelled properly, the pyranometer readings are affected by cosine and azimuth errors. Periodically check the spirit level and adjust the pyranometer’s position if necessary. EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 13...
  • Page 14 *When installing the instrument, do not remove the levelling feet or fixed feet; if the levelling feet are removed, it may cause abnormal output values due to the thermal effects from the mounting part. In the case of MS-40S, it is possible to acquire tilt information obtained from the built-in tilt sensor through Modbus RTU.
  • Page 15 Connect the output cable, DC power supply [5 to 36 V], and ammeter as shown in the figure below. Install a fuse [0.5A] in series between the DC power supply [+] and the MS-40S connection as shown below for over current protection.
  • Page 16 Connect the output cable, DC power supply [12 V], and data logging device as shown in the figure below. Install a fuse [0.5A] in series between the DC power supply [+] and the MS-40S connection as shown below for over current protection.
  • Page 17 Master represents the data logging device [such as PC], and slaves represent devices such as MS-40S. Connect the + and – for the master to [A] and [B] for each MS-40S. Also at the end of network, connect a 120Ω termination resistor.
  • Page 18 *When selecting 0-1V output, a precision resistor is required separately. The output depends on the accuracy of the resistor. Figure 5-6. Connector pin number of MS-40S ach number corresponds to the number in Table 5-4. EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 18...

  • Page 19: Me As U Ri N G S Ol A R Ir R Adi Anc E

    1,400W/m in both horizontal and tilted measurement positions. When this is converted into MS-40S output, the result will be 20mA [default]. The output for the MS-40S [4-20mA output] is set to be 1,600W/m at 20mA.
  • Page 20 Hence, sampling rates and data reduction methods can be defined right at the beginning of the data acquisition process. The response time that is given in the specifications of the EKO pyranometers states the amount of time, which is necessary to reach 95% of the final measurement value. It is also possible to define a 63.2% response [which is equal to 1-1/e].

  • Page 21: Maintenance & Troubleshooting

    6. Maintenance & Troubleshooting 6- 1. Mai nt en a nc e Using the EKO pyranometers, accurate results can be obtained if the glass dome and the condition of the instrument are maintained properly. Environmental conditions, such as for instruments mounted near highly frequented traffic lanes or airports, may have a deteriorating effect on the materials.
  • Page 22 Any change in tilt position after the For the S-series with Modbus output installation affect Data Weekly check the tilt position. measurements due to the cosine response of the sensor. EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 22...

  • Page 23: C Alib Ra Ti On An D Me As U Re Me Nt U Nc E Rt Aint Y

    Internal reference pyranometer is calibrated directly compared against the pyrheliometer, which is measured against the EKO absolute cavity, and 2 units of internal reference pyranometers by Shading Method [[A New Method for Calibrating Reference and Field Pyranometers [1995]] Bruce W Forgan] every year.

  • Page 24: Tro Ubl Es Hoo Ti N G

    6- 3. Tro ubl es hoo ti n g Read the following in case of any sensor trouble. If any questions should remain, please contact EKO for further technical support. Table 6-3. Troubleshooting Failure Action Make sure that the sensor cable is connected properly to the instrument.

  • Page 25: Specification

    7- 1. Sp ec ific a tion s 1. Pyranometer Specifications The comparison table below, Table 7-1, shows typical values for the characteristic parameters of the EKO Pyranometers and the corresponding values of the ISO 9060: 2018 standard. The content of the characteristic item is partly changed from ISO 9060: 1990.
  • Page 26 Sensor setting can be changed by connecting the sensor to a PC (Use the optional RS-485 to USB converter cable and download the free configuration software from the WKO website When 4-20mA is 0-1600W･m , 0-1V : 0-1600W･m (default) EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 26...

  • Page 27: D Im Ens Io Ns

    B. Body Height 85 mm C. Levelling Screw Height 16 mm D. Width [including Sunscreen/Cover] Φ96 mm E. Overall Height 101 mm Figure 7-1. Outer Dimensions EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 27...

  • Page 28: O Ut Pu T C Ables

    PC with USB terminal * The standard cable length is 10m *The setting can be changed with the 485 / USB conversion cable and dedicated software. EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 28...

  • Page 29: Appendix

    Pyrheliometer is classified into 4 classes of AA, A, B and C based on the performance of each characteristic, and specifications of "spectrally flat radiometer" and "Fast response radiometer" are set as sub-categories. EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 29...

  • Page 30: A- 2. P Yr An Om Ete R C Ha Rac Te Ris Tic S

    [ISO 9060: 2018 added] Error generated when converting the analog output of Pyranometer processing errors or Pyrheliometer into a digital signal with a signal converter etc. EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 30...

  • Page 31: A- 3. Co Nfi Gu R Ato R So Ft Wa Re [Ms -4 0S]

    [2400/4800/9600/19200/38400/115200] and parity check [None/Even/Odd] from the pulldown list, and [3] enter the MS-40S address in the “Modbus Address”, then finally press the “OK” button. Modbus address is the last 2 digits of the product serial number. If the last 2 digits are “00”, the address is set as “100”.
  • Page 32 Fig. A-4. Query Success 3] Main window open. 4] When “Read Memory” is pressed, configurations are read from the MS-40S memory and displayed on the window. EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4...
  • Page 33 Modbus Addr. Modbus address number [1 to 100] to be connected [Default: The last 2 digits of the MS-40S serial number is setup as address number. If the number is “0X”, the “X” would be the address number. In the case of “00”, the address would be “100”.
  • Page 34 [Default: 4mA=0W/m 、20mA=1600W/m Read Memory Reads and displays the information on #1 to 15 from the memory. Save Memory Writes the changed contents to MS-40S memory. To save the changed contents permanently, press Reboot. Reboot Reboot. Load File Reads the configuration from the file. The file name is “XXX.xml”...
  • Page 35 With code, 16 bit integer value UINT32 Without code,32 bit integer value SINT32 With code,32 bit integer value IEEE754 32bit Single precision floating FLOAT32 point A string[ASCII Code] EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 35...
  • Page 36 109, 110 Calibration value of analog input setting FLOAT32 9 types in combination of amplifier type and range 127, 128 129, 130 FLOAT32 Pt100 Calibration value EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 36...
  • Page 37 Calibration history 0[Sensitivity [μV/W/m 188, 189 Calibration history 1[Calibration date,YYYYMMDD UINT32 type] 190, 191 FLOAT32 Calibration history 1[Sensitivity [μV/W/m 192, 193 Calibration history 2[Calibration date,YYYYMMDD UINT32 type] EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 37...
  • Page 38 Ex.] S/N SXXXXXX05: Address = 5, S/N SXXXXXX00: Address = 100 [when “00”, the address is ”100”] Serial Communication Setup [Address Number: 104] Value: 6 [Default] Select with number [3] from the combination of baud rate and parity bit. EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 38...
  • Page 39 Correction value for analog output power Load Resistor for 0-1V Output [Address Number: 133, 134] Value: 100 [Default] Precision resistor value [Ω] used when analog 0-1V output is selected. EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 39...
  • Page 40 [k1: Address 172/173, k2: Address 174/175, k3: Address 176/177, k4: Address 178/179] Default Value {k1 : 0, k2 : 1, k3 : 0, k4 : 0} Setting that does not use linearity correction EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 40...
  • Page 41 Conversion example: Data conversion of power supply voltage and reference voltage [addresses 60 to 61] Conversion result: Power supply voltage 5000 [mV], reference voltage 2048 [mV] Address No. MS-40S Output Data Conversion result 12050 2048 EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 41...
  • Page 42 Next, calculate the data before conversion according to the IEEE754 standard. Conversion result: 820.52 [W/m2] Address No. Output Data Pre-conversion 444D2147 data Conversion result 820.52 EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 42...

  • Page 43: A- 5. C Om M Un Ic A T Io N S Pec If Ic A T Io Ns [ M S - 4 0 S Sd

    The device will return the W/m value. * Example of response by "al!" Command: “a18EKOMS-40vvvxx…xx<CR><LF>” EKO: Manufacturer, MS-40: Model name, vvv: Version number[3 digits], xxxxxxx: Serial Number EKO INSTRUMENTS CO., LTD. - Pyranometer MS-40/40S - Instruction Manual Ver. 4 Pg. 43...

  • Page 44: A- 6. Rec Alib R Ati O N

    2. MS-40S In case of MS-40S, the scale difference can be applied to the sensitivity figure default to the sensor. This can be done through the EKO “SensConf” Software. Since the internal sensor sensitivity figure is specified in µV/W/m...
  • Page 45 EKO Asia, Oceania 1-21-8 Hatagaya, Shibuya-ku, Tokyo 151-0072 Japan P. +81.3.3469.6713 F. +81.3.3469.6719 info@eko.co.jp www.eko-asia.com EKO North America 111 North Market Street, Suite 300, San Jose, CA 95113, USA P. +1-408-977-7751 F. +1-408-977-7741 info@eko-usa.com www.eko-usa.com EKO Europe, Middle East, Africa,...
