Tools
Provides tools for capturing images, displaying files in a
CompactFlash Card and drawing.
NOTE: The "Capture" and "PC Card Files" features are required for a
CompactFlash card.
Capture:
Allows you to capture an image from a source that is currently being
displayed. The image is saved as JPEG in the CompactFlash card.
When you select Capture from the menu, you will get a tool bar. You
can capture an image directly using the tool bar when the menu is not
displayed.
The tool bar includes the following buttons:
Drag ........... Drags to move the tool bar. (for USB mouse operation only)
Capture ....... Captures an image and save it as a JPEG file in a CompactFlash
card.
Freeze ......... Freezes and unfreezes images.
Exit ............. Exits the Capture function.
Unless a CompactFlash card is inserted into the PC Card slot of the
projector, the Capture feature is not available.
The "Card Error" display means that the free space of the
CompactFlash card is insufficient for saving images. Make more space
available on the card by erasing unwanted images with your PC. The
number of images that can be captured depends on the size of the
CompactFlash card.
NOTE: Be sure not to turn off the power or remove the CompactFlash card
while capturing an image. Doing so could cause a loss of the data in the
CompactFlash card or damage to the card itself.
NOTE: Captured images with higher resolution than the projector's native reso-
lution cannot be displayed correctly.
PC Card Files:
Displays a list of all the files stored in the CompactFlash card so that
you can select a file you want to display. You can also sort files by file
name or date, or display the file.
Although a list of all the files in the CompactFlash card is displayed,
you can view files in idx, text, HTML, JPEG and BMP format only.
Selecting BMP and JPEG files automatically switches to the PC Card
Viewer source.
NOTE: When an image with a resolution of XGA(1024 768) or higher is
projected, the PC Card Files screen may not be correctly displayed.
Selecting "Execute" displays the file you selected.
When you select a JPEG or BMP file and press the Enter button on
the remote or the cabinet, or "Execute" on the above, you will get a
toolbar. This toolbar is used to return to the PC Card Files screen.
Files screen
Drag
Drag ........... Moves the toolbar.
Return ......... Returns to the PC Card Files screen.
Close .......... Close the toolbar.
Changing Background Logo
The Logo button allows you to select a background logo from graphic files
on a CompactFlash card and change to it as the background logo.
NOTE: File size must be 64KB or less. Other file formats than JPEG and BMP
are not available.
1. Use the Select
or
your background logo.
2. Use the Select
and then
3. Press the Enter on the remote control or the cabinet. You will get
the confirmation dialog box.
4. Select "OK" and press the Enter button. This completes changing
a logo for the background.
* Once you have changed the background from the NEC logo to another,
you cannot return the logo to background even by using Factory Default.
To do so, repeat the above steps. The NEC logo file is included on the
supplied CD-ROM (/logo/nec_b_x.jpg).
E–43
Close the toolbar
button to select a JPEG or BMP file for
button to select "Logo".
