FITTING INSTRUCTIONS
Pack includes
• Heavy duty barrel spring base
• Fibreglass radome
• Grub screw and hex key to secure the fibreglass pole
• Low-loss coaxial cable (4.5m)
• Pre-terminated FME connector and PL259 adaptor
IMPORTANT - Always fit in accordance with State Road & Traffic Safety Guidelines
Installation
1. Remove the shroud protecting the cable at the base of the antenna.
2. Install the spring base onto the bracket (not supplied). Tigten in a clockwise
direction using a hexagon wrench or spanner. IMPORTANT: Do not exceed 50N.
3. Remove the cap from the top of the spring base and install the fiberglass
extension pole on to the base by turning in a clockwise direction and secure in place
with the grub screw (using the hex key provied). Hand tighten only MAX. 15N.
ANU800 UHF CB ANTENNA
