Contact Details for Oricom Support and
Warranty claims in Australia
Oricom International Pty Ltd
Unit 1, 4 Sovereign Place
South Windsor, NSW 2756 Australia
Email: support@oricom.com.au Phone:
1300 889 785 or (02) 4574 8888
(Monday to Friday 8am to 6pm AEST)
Web: www.oricom.com.au
Fax: (02) 4574 8898
Contact details for Oricom Support and
Warranty Claims in New Zealand
Email: support@oricom.co.nz
Phone: 0800 674 266
(Monday to Friday 10am to 8pm NZST)
Web: www.oricom.co.nz
ORICOM UHF CB ANU250 ANTENNA WARRANTY220715
USER GUIDE - ORICOM ANU250 ANTENNA
ANU250 Pack Includes:
Independant
Spring and Elevated Feed
Mounting Base
Installation
1) Join the Whip onto the Spring and Elevated Feed section. Hand-tighen in a
clockwise direction: Do not exceed 30N
2) Install the Independent Base onto the bracket (not supplied). Tighten in
an anti-clockwise direction, using a hexagon wrench or spanner.
IMPORTANT: Do not exceed 50N
3) Join the Spring and Elevated Feed section to the Independent Base. Hand-
tighten in a clockwise direction. IMPORTANT: Do not exceed 15N
Join the independent lead to the base. Hand-tighten in a clockwise direction.
4)
IMPORTANT: Do not exceed 15N
1
MAX:30N
3
MAX:15N
Whip
Independant Lead
2
MAX:50N
4
MAX:15N
Images are for illustration purposes only.
