DEMO MANUAL DC1228A
Quick start proceDure
Demonstration circuit 1228A is easy to set up to evalu-
ate the performance of the LT3573. Refer to Figure 1 for
proper measurement equipment setup and follow the
procedure below:
NOTE: When measuring the input or output voltage ripple,
care must be taken to avoid a long ground lead on the
oscilloscope probe. See Figure 2 for proper scope probe
technique.
2
1. With power off, connect the input power supply to V
and GND.
2. Turn on the power at the input.
NOTE: Make sure that the input voltage does not exceed
30V.
3. Check for the proper output voltages.
NOTE: If there is no output, temporarily disconnect the
load to make sure that the load current is not set too
high.
4. Once the proper output voltage is established, adjust
the load current within the operating range and observe
the output voltage regulation, ripple voltage, efficiency
and other parameters.
IN
dc1228af
