hager Muse WGMS113SUSBKB Installation Manual

13A single switched socket + USB
Hager Muse
Safety instructions
Electrical equipment must only be installed and assembled by a qualified electrician in
accordance with the relevant installation standards, regulations, directives and safety
and accident prevention directives of the country.
Failure to comply with these installation instructions may result in damage to the
device, fire or other hazards.
Function
The device combines a BS socket outlet with a single/twin USB port charging unit.
USB
port
Switched socket with 1 USB
Socket features:
The BS socket outlet is compatible with BS 1363-1 plugs. It can be switched ON/OFF using
the integrated single pole switch.
USB features:
- The USB port charging unit is suitable for charging most portable electronic devices con-
nected via a USB type A plug.
- It is supplied independently of the ON/OFF switch position.
- With dynamic load recognition
- Short-circuit proof and overload proof
Correct use
- For the flush-mounted installation in standard wall boxes
(recommended wall box depth ≥ 35 mm).
- Only suitable for use in indoor areas with no drip and no spray water.
2 USB
ports
ON/OFF
switch
Switched socket with 2 USB
Installation manual
ON/OFF
switch
