Summary of Contents for Phonic AM844D USB
- Page 1 AM844D USB User's Manual Manual del Usuario...
- Page 2 AM844D COMPACT MIXERS MEZCLADORAS COMPACTAS ENGLISH ........I ESPAÑOL ........II APPENDIX .
-
Page 3: Table Of Contents
USER'S MANUAL CONTENTS INTRODUCTION..............1 FEATURES................1 SYSTEM REQUIREMENTS............1 BASIC SETUP................1 MAKING CONNECTIONS............2 CONTROLS AND SETTINGS..........4 SPECIFICATIONS..............8 APPENDIX DIGITAL EFFECT TABLE............1 APPLICATION.................2 DIMENSION................3 BLOCK DIAGRAM..............4 Phonic preserves the right to improve or alter any information within this document without prior notice. - Page 4 IMPORTANT SAFETY INSTRUCTIONS The apparatus shall not be exposed to dripping or splashing and that no objects with liquids, such as vases, shall be placed on the apparatus. The MAINS plug is used as the disconnect device, the disconnect device shall remain readily operable.
-
Page 5: Introduction
Getting Started compact mixers. The AM844D USB compact mixer – designed Ensure all power is turned off on the AM844D USB mixer. To by the talented engineers that, in the past, have created a variety totally ensure this, the AC cable should not be connected to of mixers fantastic in style and performance –... -
Page 6: Making Connections
Control Panel’s audio menu. be duplicated to the right due to the miracle of jack normalizing. If you don’t want to use the AM844D USB as your default audio device, you can simply enter your DAW or other audio... - Page 7 Please use the power cable that is included with this mixer only. The fuse holder (located above the AC Power connector) is for the AM844D USB’s fuse. If the fuse happens to blow, open the holder cover, and replace the fuse with a suitable replacement (as indicated below the power connector).
-
Page 8: Controls And Settings
20. Phantom Power Switch audio. When this switch is in the on position, it The stereo channels of the AM844D USB mixer feature a High- activates +48V of phantom power for all Mid and Low-Mid control instead of microphone inputs, allowing condenser the typical controls described above. - Page 9 This button is pushed to turn the corresponding effect panel on or off. Effects can also be disabled by using a footswitch with the jack on the rear of the mixer. Please note: this button will not lock down as similar buttons on the mixer do. AM844D USB...
- Page 10 Control Room and Phones feeds, for use in the monitoring and tracking of audio. The Control Room control adjusts the final level sent to the C-R outputs on the rear of the AM844D USB mixer, whereas the Phones control adjusts the final signal sent to the Phones A and B jacks on the top of the mixer’s face.
- Page 11 4 audio feeds (the signals of which are doubled in the 5 – 8 Group outputs), sent to the corresponding Group outputs on the rear of the AM844D USB to feed external devices such as effect processors, and, most commonly, multi-track recorders.
-
Page 12: Specifications
2/4 as far right as possible. Reference=+6dBu) Master @ unity, channel fader down -86.5 dBu Master @ unity, channel fader @ unity -84 dBu S/N ratio, ref to +4 >90 dB Microphone Preamp E.I.N. (150 ohms terminated, max gain) <-129.5 dBm AM844D USB... - Page 13 Sampling Rate 48 kHz Digital Effect Processor 16 effects with parameter control Footswitch EFX on/off Power Requirements 100-240 VAC, 50/60 Hz Dimensions (WxHxD) 418 x 140 x 438 mm (16.5” x 5.5” x 17.25”) Weight 5.9 kg (13 lbs) AM844D USB...
- Page 14 Phonic, at its option, shall repair or replace the defective unit covered by this warranty. Please retain the dated sales receipt as evidence of the date of purchase.
-
Page 15: Digital Effect Table
0.3 to 2.45 Stage Reverb Time (S) 0.6 to 1.6 Doubler Feedback Ratio 20% to 90% Echo Delay Average (S) 0.12~0.55 Chorus 0.66~9.6 0.8 to 8.8 Chorus + Rev Reverb Time (S) 0.4 to 0.8 Spring 0.16 to 1.33 AM844D USB... -
Page 16: Application
GRABADORA DE DAT IZQUIERDO DERECHO PA ALTAVOCES (RELLENO LATERAL) AMPLIFICADOR INTERRUPTOR DE PEDAL MONITORES ACTIVOS MICRÓFONOS COMPUTADORA PORTÁTIL REPRODUCTOR DE CD MÁQUINA DE BATERÍA AUDÍFONOS COMPRESOR / LIMITADOR EFECTOS DE COMPRESOR / LIMITADOR GUITARRA TECLADO GUITARRA BASS GUITARRA AM844D USB... -
Page 17: Dimension
DIMENSIONS DIMENSION All measurements are shown in mm/inches. Todas las medidas están mostradas en mm/pulgadas. AM844D USB... -
Page 18: Block Diagram
BLOCK DIAGRAM DIAGRAMA DE BLOQUE EFX3 SEND SOLO C PFL R PFL L AFL R AFL L AUX4 AUX3 AUX2 AUX1 MAIN R MAIN L AM844D USB... - Page 19 MEMO AM844D USB...
