Summary of Contents for Dancover PA152010
- Page 1 Manual Gazebo 4,36x2,95x2,7m 24-02-2021...
- Page 2 Assembly Instructions PRODUCT SIZE(LxWxH):436x295x270cm PLEASE READ CAREFULLY BEFORE ASSEMBLY...
- Page 3 CONTENTS 1. Assembly Advice ..............Page 1 2. Product Features ..............Page 2 - 3 3. Parts List ................Page 4 - 6 4. Roof Vent Assembly ............Page 7 - 8 5. Door Assembly ..............Page 9 - 11 6. Base Assembly ..............Page 12 - 13 7.
- Page 4 Assembly and Maintenance Advice 1. For safety purposes, we strongly recommend that this product is assembled by at least two people. 2. Some components have sharp metal edges. Please be careful when handling metal components. Please wear gloves, shoes and safety goggles during assembly. 3.
- Page 5 Functions and Features: 1. Compared with traditional greenhouses this new product features many significant improvements. The hollow box profile aluminium framing is much stronger than other greenhouses and it can withstand much greater pressure. 2. Base anchor brackets are included as standard with expanding bolts to ensure a secure fixing into concrete or paving.
- Page 6 5. Manual window handles are included as standard with the roof vents. If required, automatic roof vent openers are available as an inexpensive optional extra. Manual Opener Automatic Opener 6. Remove approximately 2 inches of film from all sheet edges before installing and remove all film immediately after the construction is completed.
- Page 7 PA152010 PART PART PART L01A L03C M5X12 L04A M5X12 L04B M4.2X16 L18B Ø4X16D L19A M4.8X16 L23A M8X60 M6X12 Ø3.2X10 Tools Provided: D115 PART L02E L05A L07A L08A L09A L05C L03A L18A L19B...
- Page 8 PA152010 PART L03D L03E L05B L07B L08B L09B L05G L15A PART PART L03B L16A L06A L16B L05E L18C L18D L03A...
- Page 9 PA152010 PART PART 160M J107 Rubber for walls & roof (Provided for glass only) PC/Glass PART J107 N0.1 Rubber for walls only (Provided for glass only)
- Page 10 PART Window L19A L19B M4.2X16 L19A L19A L19B Fix A01 in the middle of L19B, 322.2mm from the ends. Insert H43 into the Slot Slot of L19A,L19B & L20 Insert Part B into the tube L19B Tube of L19A,L19B & L20 After connector D46 &...
- Page 11 PART PART 2.65M J107 L15A L15A M4.2X16 Ø4X16D J107 If glass is chosen, please seal it with rubber (J107) provided. If polycarbonate sheet is chosen, rubber is not provided. Please seal it with silicone sealant (not provided).
- Page 12 PART Left Door L18A L16A L16B L18A L05G L18B L16B L18C L18D L18D L05G M5X12 L05G M4.2X16 M6X12 L18B Insert Connector D45 into each end of frame profiles L16B & L18A & L18B & L18D, and then fix them with screws Z08. Before fixing with screws, please mark them with a pencil at distance about 20/30mm from each end, and make sure there is no gaps...
- Page 13 Right Door L18B L05G L18C L16A L05G L18A Insert Connector D45into each end of frame profiles L16A & L18A & L18B & L18C, and then fix them with screws Z08. Before fixing with screws, please mark them with a pencil at distance about 20/30mm from each end, and make sure there is no gaps between each profile.
- Page 14 PART 12.2M J107 J107 J107 If glass is chosen, please seal it with rubber(J107) provided. Noted: Rubber is not provided if you choose polycarbonate sheet as glazing panel.
- Page 15 Expansion screw/Concrete ground It is essential the dimensions a + b are the same to ensure the base is square. Steel pegs in soil Support at the corners only is inadequate.
- Page 16 PART M8X60 Expansion bolts assembly * This shows a layout for D22's positions where it is placedin the middle of the glazing panel for each section.
- Page 17 PART L01A L08B L08A L08A L08B L08A M5X12 L08B Insert J41 into the tube of L08A and L08B L08B L08A L01A L01A L01A L01A L01A Fix L01A to L08A & L08B through J41, using S26.
- Page 18 PART L07A L07B M5X12 L07B L07A L07A L07B Insert J39 into L01A, and then fix L07A & L07B to L01A using S26. Make sure the angle is Right Angle before tighting them up. L07A L07B...
- Page 19 PART Back Wall Assembly L03A M5X12 L03A L03A L03A L03A L03A Insert Panel Y5 into the channel of L01A, and then fix a L03A to L08B & L07B using S26. Make sure the other side of Y5 is completely in the channel of L03A. Insert another Y5 into the channel of L03A, then fix another L03A L08A using S26.
- Page 20 PART L03A M5X12 L03A L03A Side Walls Assembly Do the same as the back wall assembly, L07A Y6 is the last panel to insert in. L03A L08A L03A...
- Page 21 PART Front Wall Assembly L04A L04B L03A L03A L05C L03A M5X12 L04B M4.2X16 L04A L07A L03A Fix L03A and Y5 same as the back wall assembly. Fix L04A & L04B using S26. L03A And then fix L05C to glazing bars L03A & L04A/L04B L08A using S26.
- Page 22 PART L05A L05B L05B M5X12 M4.2X16 L05A L05A L01A L01A L05A L05A Install L05A (2PCS) & L05B Fix two ends of L05A/L05B onto L01A using S26, Fix L05A/L05B to L03A with the self-tapping screws (Z08) using a powered screwdriver. Eusure that L05A/L05B is fixed at a right angle (90 degrees) to the glazing bars.
- Page 23 PART L02E M5X12 M4.2X16 L03A L02E L03A L02E L02E Insert the other end of Y6 into the channel of L02E. Fix plate D49 onto L02E and L03A, using S26 and Z08 as shown above.
- Page 24 PART WINDOW M5X12 M4.2X16 1. Fix D49 onto the window profile L11 using S26; 2. Make a mark on L03A at distance 593MM from L02E (as shown on the left). Do the same on the other end. 3. Fix the window to L03A, using Z08. 4.
- Page 25 PART D115 M4.2X16 L02E D115 L19B L02E D115 Fix D115 onto L02E, using Z08; and fix the auto opener onto D115 and L19B (window profile), using Z08.
- Page 26 PART J107 If glass is chosen, please seal it with rubber(J107) provided. J107 J107 J107...
- Page 27 PART L23A L03D M5X12 L03D L23A L03D Fix L23A (2PCS) and L03D (2PCS) to D56 as shown above, using S26. L23A L03D L23A L03D L23A Fix the roof profiles L23A to L07A & L07B, with D52, using S26. Fix L03D to L07A & L07B, using S26. Note: Extra hands are needed to hold the profiles when you do this assembly.
- Page 28 PART L06A L03D L03D L03E L06A L03E L03D M5X12 Fix L06A to L23A & L03D with J40,using S26 L03D L03D L07A L06A L03E L07B L03E L06A L03E Fix L03E to L06A and L07A, using S26.
- Page 29 PART PART J107 L03B L03C L09A L03B L03C L09B M5X12 L03B&L03C L03B&L03C Insert Y1/Y2 into the right position before fixing L03B /L03C. Y1&Y2 If glass is chosen, please seal it with rubber (J107) provided. If polycarbonate sheet is chosen, rubber is not provided. Please seal it with silicone sealant (not provided).
- Page 30 Y8 Y8 Y3 Y8 Y8 Y4 Put Y3, Y4 and Y8 into positions J107 J107 If glass is chosen, please seal it with rubber (J107) provided. If polycarbonate sheet is chosen, rubber is not provided. Please seal it with silicone sealant (not provided).
- Page 31 Gutter Assembly L09B When the panels are completely inserted, fix gutter profile L09B. Tap it gently into position with a rubber mallet. Do the same on the other side. L07A L09B Y1 Y3 Assembly the other 2 sides. Firstly, put Y1 & Y2 into positions, and fix L03B & L03C to L23A & L07A; Secondly, put panel Y3 &...
- Page 32 PART L05A L05C L05A L05E L05E L05C L05E M4.2X16 L05E M5X12 L05C L05A L05E L05E L05E L03D L03B&L03C L03B&L03C L05C L05C Fix L05A&L05C to L03B & L03C using S26, and fix it to L03D using Z08. Fix the eave bracing L05E using Z08 as shown.
- Page 33 PART Door Assembly M4.2X16 M4.8X16 M5X12 Fix L24 to L07B, using Z08. Left Door Right Door Fix L25(4 PCS) one side to the door profile and the other side to L04A/L04B using S27. Then secure with Z17.
- Page 34 PART Ø3.2X10 M4.2X16 Z06&Z08 Drill the holes on each L03A as shown, Dia.3.2mm, and secure the hooks H10 with Z06 & Z08,then ensure H10 works with Door properly when the doors are open. Drill a hole in L01A, approximately 3mm diameter and 700mm If you wish to eliminate leaks up from the bottom.
- Page 35 Head office: Dancover A/S For more information Lyngevej 16A, Nørre Herlev please visit: 3400 Hillerød www.dancovershop.com Denmark...
