- Page 1 Manual Gazebo 2,95x2,95x2,7m 24-02-2021...
-
Page 2: Assembly Instruction
Assembly Instruction PRODUCT SIZE(LxWxH):295x295x270cm PLEASE READ CAREFULLY BEFORE ASSEMBLY... - Page 3 CONTENTS 1. Assembly Advice ..............Page 1 2. Product Features ..............Page 2 - 3 3. Parts List ................Page 4 - 6 4. Roof Vent Assembly ............Page 7 - 8 5. Door Assembly ..............Page 9 - 11 6. Base Assembly ..............Page 12 - 13 7.
- Page 4 Assembly and Maintenance Advice 1. For safety purposes, we strongly recommend that this product is assembled by at least two people. 2. Some components have sharp metal edges. Please be careful when handling metal components. Please wear gloves, shoes and safety goggles during assembly. 3.
- Page 5 Functions and Features: 1. Compared with traditional greenhouses this new product features many significant improvements. The hollow box profile aluminium framing is much stronger than other greenhouses and it can withstand much greater pressure. 2. Base anchor brackets are included as standard with expanding bolts to ensure a secure fixing into concrete or paving.
- Page 6 5. Manual window handles are included as standard with the roof vents. If required, automatic roof vent openers are available as an inexpensive optional extra. Manual Opener Automatic Opener 6. Remove approximately 2 inches of film from all sheet edges before installing and remove all film immediately after the construction is completed.
- Page 7 PA152000 PART L01A L01B L01C L04A L04B L05A L08A L09A L23A PART PART PART L07A M5X12 L09A M5X12 L03A M4.2X16 Ø4X16D L15A M5X12 M8X60 M6X12 Tools Provided: D115...
- Page 8 PA152000 PART PART L02E L16A L16B L03D L05B L18A L05C L18B L03A L18C L03B L18D L05G L03C L05E L05F PART L19A L19B...
- Page 9 PA152000 PART PART 125M J107 Rubber for walls & roof (Provided for glass only) PC/Glass PART 81.5M J107 N0.1 Rubber for walls only (Provided for glass only)
- Page 10 PART Window L19A L19B M4.2X16 L19A L19A L19B Fix A01 in the middle of L19B, 322.2mm from the ends. Insert H43 into the Slot Slot of L19A,L19B & L20 Insert Part B into the tube L19B Tube of L19A,L19B & L20 After connector D46 &...
- Page 11 PART PART 2.65M J107 L15A L15A M4.2X16 Ø4X16D J107 If glass is chosen, please seal it with rubber (J107) provided. If polycarbonate sheet is chosen, rubber is not provided. Please seal it with silicone sealant (not provided).
- Page 12 PART Left Door L18A L16A L16B L18A L05G L18B L16B L18C L18D L18D L05G M5X12 L05G M4.2X16 M6X12 L18B Insert Connector D45 into each end of frame profiles L16B & L18A & L18B & L18D, and then fix them with screws Z08. Before fixing with screws, please mark them with a pencil at distance about 20/30mm from each end, and make sure there is no gaps...
-
Page 13: Right Door
Right Door L18B L05G L18C L16A L05G L18A Insert Connector D45into each end of frame profiles L16A & L18A & L18B & L18C, and then fix them with screws Z08. Before fixing with screws, please mark them with a pencil at distance about 20/30mm from each end, and make sure there is no gaps between each profile. - Page 14 PART 12.2M J107 J107 J107 If glass is chosen, please seal it with rubber(J107) provided. Noted: Rubber is not provided if you choose polycarbonate sheet as glazing panel.
- Page 15 Expansion screw/Concrete ground It is essential the dimensions a & b are the same to ensure the base is square. Steel pegs in soil Support at the corners only is inadequate.
- Page 16 PART M8X60 2899MM Expansion bolts assembly Door * This shows a layout for D22's positions where it is placedin the middle of the glazing panel for each section.
- Page 17 PART L08A L01A L01B L08A L01C L08A M5X12 L08A L08A L08A Insert J41 into each L08A L01A L01A L01B L01C L01A Fix L01A to L08A through J41, using S26.
- Page 18 PART L07A M5X12 L07A L07A L07A L07A Insert J39 into L01A, and then fix L07A to L01A using S26. Make sure the angle is Right Angle before tighting them up. L07A L07A...
- Page 19 PART Back Wall Assembly L03A L03A L03A L03A M5X12 L07A L07A L01A L01A L08A L08A L08A Insert Panel Y5 into the channel of L01A, and then fix a L03A to L08A & L07A using S26. Make sure the other side of Y5 is completely in the channel of L03A.
- Page 20 PART L03A M5X12 L03A L03A L07A L03A Side Walls Assembly Do the same as the back wall assembly, Y6 is the last panel to slide in. L08A L03A The last panel...
- Page 21 PART Front Wall Assembly L04A L04B L05B M5X12 L04B L04A L07A Fix L04A/L04B and Y5 same as the L03A back wall assembly using S26. And then fix 1 X L05B to L01A & L04A and 1 X L05B to L01A & L04B using S26. L03A L08A L05B...
- Page 22 PART L05A M5X12 M4.2X16 L01A L01A L05A L05A Install L05A (3PCS) Fix two ends of L05A onto L01A using S26, Fix L05A to L03A with the self-tapping screws (Z08) using a powered screwdriver. Eusure that L05A is fixed at a right angle (90 degrees) to the glazing bars.
- Page 23 PART L02E M5X12 M4.2X16 L02E L02E L03A L03A L02E L02E Insert the other end of Y6 into the channel of L02E. Fix plate D49 onto L02E and L03A, using S26 and Z08 as shown above.
- Page 24 PART WINDOW M5X12 M4.2X16 1. Fix D49 onto the window profile L11 using S26; 2. Make a mark on L03A at distance 593MM from L02E (as shown on the left). Do the same on the other end. 3. Fix the window to L03A, using Z08. 4.
- Page 25 PART D115 M4.2X16 L02E D115 L19B L02E D115 Fix D115 onto L02E, using Z08; and fix the auto opener onto D115 and L19B (window profile), using Z08.
- Page 26 PART J107 If glass is chosen, please seal it with rubber(J107) provided. Rubber is not provided if you choose polycarbonate sheet as glazing panel. J107 J107 J107...
-
Page 27: Roof Assembly
PART L23A Roof Assembly L23A L23A L23A M5X12 L23A Fix 4 X L23A to D54 as shown above, L23A using S26. L23A L07A L23A Fix the roof profiles L23A to L07A with D52, using S26. Note: Extra hands are needed to hold the profiles when you do this assembly. - Page 28 PART L03D M5X12 L03D L03D L03D Fix L03D (4 PCS) to D54 as shown, using S26. Twist M06 into the bolt on D55, and then insert the bolt of D55 through D54. Adjust the position of the above M06 to allow enough space for another M06 below to tight it up.
- Page 29 PART PART 43.5M J107 L03B L03C L03C L03B L09A M5X12 L03B&L03C L03B&L03C Fix L03B & L03C to L07A & L23A as shown Y1&Y2 Insert Y1/Y2 into the right position before fixing L03B /L03C. If glass is chosen, please seal it with rubber (J107) provided. If polycarbonate sheet is chosen, rubber is not provided.
- Page 30 Insert Y3 & Y4 into positions. J107 J107 If glass is chosen, please seal it with rubber (J107) provided. If polycarbonate sheet is chosen, rubber is not provided. Please seal it with silicone sealant (not provided).
- Page 31 PART Gutter Assembly 43.5M J107 When the panels are completely inserted, fix gutter L09A to profile L07A. Tap it gently into position with a rubber mallet. L07A L09A Do the same on the other sides...
- Page 32 PART L05C L05E L05E L05F M4.2X16 M5X12 L05C L05E L03D L03B&L03C L03B&L03C L05C L05C Fix L05C to L03B & L03C using S26, and fix it to L03D using Z08. Fix the eave bracing L05E using Z08 as shown.
-
Page 33: Door Assembly
PART Door Assembly M4.2X16 M4.8X16 M5X12 Left Door Right Door Fix L24 to L07A, using Z08. Left Door Right Door Fix A51(4 PCS) one side on the door profile and the other side to L04A/L04B using S27. Then secure with Z17. - Page 34 PART M4.2X16 If you wish to eliminate leaks Drill a hole in L01A, use glue when fixing the downpipe approximately 3mm diameter and 700mm bends (not provided). up from the bottom. Fix the J92 downpipe bracket with Z08 screws and then clip the L25 downpipe into the J92 bracket.
- Page 35 Head office: Dancover A/S For more information Lyngevej 16A, Nørre Herlev please visit: 3400 Hillerød www.dancovershop.com Denmark...
