DW Megapix Snapit DWC-MD421D Manual page 56

1080p indoor dome ip camera
Table of Contents

Advertisement

SPECIFICATIONS*
NETWORK
LAN
Video Compression Type
Resolution
Frame Rate
Stream Capability
IP
Protocol
Maximum User Access
Memory Slot
ONVIF Conformance
Web Viewer
Video Management Software
ENVIRONMENTAL
Operating Temperature/ Humidity
Operating Humidity
Storage Temperature
Other Specifications
Electrical
Power Requirement
Power Consumption
Mechanical
Housing Material
Dimensions
Weight
802.3 Compliance 10/100 LAN
H.264, MPEG4, MJPEG (Super Fine ~ Low)
1920X1080 (16:9) ~ 320X240 (4:3)
Up to 30fps at All Resolutions
Dual-Stream at Different Rates and Resolutions
IPv4, IPv6
TCP/IP, HTTP, DHCP, PPPoE, ICMP, ARP, RARP, RTSP, NTP, UDP, Multicast
20 Users
Local SDHC Card Backup
Yes
Supported OS: Windows XP, Windows Vista, Windows 7, MAC OS
Supported Browser: Internet Explorer, Google Chrome, Mozilla Firefox,
Safari
DW Spectrum™ IPVMS
-10°C ~ 55°C (14°F ~ 131°F)
Less than 90% (Non-Condensing)
-20°C ~ 70°C (-4°F ~ 158°F)
CE, FCC, RoHS
DC 12V, PoE (IEEE802.3af Class 3)
IR OFF: 7.2w, 600mA
IR ON: I8.64W, 720mA
Plastic
108 X 96.8 mm (4.25 X 3.8 in)
0.507 lbs
5 4
