DW Megapix Snapit DWC-MD421D Manual page 34

WEBVIEWER*
S e t u p > E v e n t > M o t i o n D e t e c t i o n
T h e M o t i o n d e t e c t i o n f e a t u r e a l l o w s t h e M E G A P I X c a m e r a t o
d e t e c t m o t i o n a n d t r i g g e r a n a l a r m . To s e t t h e c a m e r a t o
s e n d e - m a i l n o t i f i c a t i o n s f o r e v e r y m o t i o n t r i g g e r e d a l a r m s ,
s e e p a g e 5 1 .
To setup motion detection:
1. Check the Use Motion box.
2. Sensitivity: Select from Low, Middle, or High.
3. Dwell Time: When a motion is triggered, the camera can be set to record for a certain period of time.
Dwell Time can be set up to 900 seconds.
4. Relay: an alarm out triggered by motion detection. Select None or 1.
5. Duration: determines how long the alarm out will last. Maximum is 900 seconds.
6. Select Apply to save changes.
To setup specific areas of the camera's view to motion detection, please see the next page.
3 4
