WEBVIEWER*
S e t u p > V i d e o & A u d i o > C o l o r S e t t i n g s
U s e t h i s s e t u p m e n u t o a d j u s t t h e c a m e r a 's W h i t e B a l a n c e ,
E x p o s u r e , D a y / N i g h t a n d i m a g e s e t t i n g s .
• WDR/ BLC Mode: In this menu you can select to apply either Wide Dynamic Range or Backlight
Compensation to adjust the image in harsh lighting environments.
1. WDR Level: If WDR is selected, adjust the level of WDR between 0 (no WDR) to 9 (high WDR
adjustment). The default value is 5. The higher the WDR level, dark areas in the image will appear
brighter, and bright areas will appear darker.
2. Back Light Compensation (BLC): Adjust the camera's capture of light when there is strong
backlight in the camera's Field of View [FoV]. Select to enable or disable.
• Select 'Apply' to save changes, 'Reload' to return to the last saved settings, or 'Default' to return all
settings to their factory default values.
