Summary of Contents for Super Vac 716WT
- Page 1 VENTILATOR USER GUIDE MODEL 716WT VentilatorUserGuide-716WT.docx...
-
Page 2: Table Of Contents
This manual covers the description, cautions, operation and maintenance of the Super Vac Hydraulic Positive Pressure Ventilator Model 716WT Please take the time to read this manual before operating the ventilator. Save this guide for future reference. CONTENTS 1. BREAKAGE OR DAMAGE DURING SHIPMENT ..............................3 2. -
Page 3: Breakage Or Damage During Shipment
Be sure to keep all damaged goods subject to examination of the truck or express company inspector, who may call on you some time later. These damaged goods, of course, will belong to them, and they will inform you what to do with them. If you dispose of these damaged goods, your claim may not be paid. VentilatorUserGuide-716WT.docx... -
Page 4: General Description And Specifications
Specifications are subject to change without notification. Refer to model decal affixed to ventilator to determine actual specifications. This ventilator is designed for high powered air movement. Super Vac’s propeller produces a greater intake of air and eliminates turbulence at the tips. Each blade is statically balanced for high efficiency and long life. -
Page 5: Product Safety Precautions
§ A complete inspection of the ventilator should be made prior to operation. § Check all threaded fasteners for proper tightness. § Inspect inlet and outlet guards for damage or missing pieces. Replace damaged or missing guards before operating ventilator. VentilatorUserGuide-716WT.docx... -
Page 6: Operation
Example: If the inlet pressure of the water supplied to the motor is 174 psi, and the resisting torque of the driven machine is 7.4 lb/ft, the rotational speed is 4560 rpm, water consumption is 117 gpm (graph 1) and the usable power is 5.5 HP (graph 2) VentilatorUserGuide-716WT.docx REV. 06/09/17... - Page 7 Inlet Pressure Water Flow Air Flow 5168 8781 10112 17179 10.0 16178 27487 13.3 19100 32450 16.7 22470 38177 The maximum feed pressure is 300 psi (20 bar). VentilatorUserGuide-716WT.docx...
-
Page 8: Inlet And Discharge Position
6. Inlet and Discharge Position As delivered, the standard position of the inlet and discharge connections on your 716WT allow for easier connection of water supply lines. This positioning does not allow full range of tilt positions. If your application requires the use of the two back tilt positions the inlet and discharge blocks on the water turbine motor may be rotated 90 degrees. -
Page 9: Parts List
WASHER, 3/8, SAE FLAT, ZINC 025-13430 DECAL SERIAL NUMBER, GREY 032-11133 NUT, HEX, 3/8-16, NYLOK, ZINC 025-13426 DECAL, SUPER VAC, VERT LTRS, BLACK REFLT 008-10189 PLUG, FINISHING, 1", SQ RIBBED, BLACK 025-15162 DECAL, HONDA ENGINE DIAGRAM, BLK ON WHT 018-10431... -
Page 10: Exploded View Drawing
8. Exploded View Drawing... - Page 11 POSITIVE PRESSURE VENTILATOR VentilatorUserGuide-716WT.docx REV 06/09/17...
-
Page 12: Warranty
9. Warranty Limited Warranty Five Years Super Vacuum Manufacturing Company warrants that the equipment is free from defects in materials and workmanship when used and operated for a period of five years. The responsibility of Super Vacuum Manufacturing Company under this limited warranty is limited to the repair and replacement of any parts which are found defective and which are returned to Super Vacuum Manufacturing Company at 1303 East 11th Street, Loveland, Colorado 80537 with transportation charges prepaid (C.O.D. -
Page 13: Contact Information
POSITIVE PRESSURE VENTILATOR 10. Contact Information For parts or service information, contact: Super Vacuum Manufacturing Company, Inc. 3842 Redman Drive Fort Collins, CO 80524 Phone: 1-800-525-5224 970-297-7100 FAX: 970-297-7099 Internet: www.supervac.com VentilatorUserGuide-716WT.docx REV 06/09/17...
