fantastic furniture Java Lamp Table 1 Drawer Manual page 11

Step 11
You will need
2 x Dowels
Mallet
ø6
mm (H16)
Insert 2 x dowels (H16) into drawer side panels (P6, P7) as shown.
Use a mallet to gently tap the dowels into place if needed.
Step 12
You will need
Flat Head
Screwdriver
Position drawer sides (P6, P7)
onto drawer front (P5).
Insert 4 x small cam nuts (H15)
into drawer sides (P6, P7).
Rotate the cam nuts so the arrows
face incoming cam bolts.
Using a flat head screwdriver turn clockwise to lock.
Step 13
Slide drawer base (P9) into
the grooves of panels (P5, P6, P7).
fantasticfurniture.com.au
(P6)
H16
(P6)
H15
(P6)
(P7)
H16
(P7)
H15
(P5)
(P9)
(P7)
(P5)
Page 11
