4.4 Electrical Connection
Each unit has its own power requirements, please understand their differences. This unit must be
operated on its own circuit Installed by a licensed professional.
Plugs:
UHC-10/40 | NEMA 6-20P
UHC-20/40 | NEMA L6-30P
UHC-50/40 | Single phase quick disconnect panel
UHC-100/40 | Three phase quick disconnect panel
4.5 Operating Area
Always leave 12-16 inches around the unit. Obstructing the ventilation will cause poor performance or
part failure. Always keep the operating area clean and organized to prevent injury or damage.
15
