9. Installation manual
9.1 Installation Details
Connecting pipe length
Model
TAC-07CHSA/VB
TAC-09CHSA/VB
TAC-12CHSA/VB
TAC-24CHSA/VB
Outdoor unit
Pi pe length is
15 meters Max.
Indoor unit
Mode
TAC-07CHSA/VB
TAC-09CHSA/VB
TAC-12CHSA/VB
TAC-24CHSA/VB
Connecting cables
The power cord should be selected according to the following specifications sheet.
Appliance Amps
TCL Air Conditioner Service Manual
Liquid
1/4
1/4
1/4
1/4
Standard length: m
3.0
3.0
3.5
5.0
5
10
13
18
25
30
Pipe size(Inch)
Indoor unit
Refrigerant piping
Max. length: m
A
15
15
15
15
Wire Size
AWG21/0.75 mm
AWG18/1.0 mm
AWG15 /1. 5 mm
AWG14/1.6 mm
AWG12/2.0 mm
AWG10/2.5 mm
24
Gas
3/8
3/8
3/8
5/8
Pipe l ength is
15 meters Max.
Outdoor unit
Additional refrigerant
Calculation: ×g=20g/m(A-5m)
20g/m
20g/m
20g/m
30g/m
2
2
2
2
2
2
