TCL TAC-07CHSA/VB Service Manual page 14

6. Explosion view and parts
Indoor Unit- TAC-07CHSA/VB
No. Part No.
1 41106-001262
2 42008-000065
3 41106-002337
4 41105-000160
5 31102-000066
6 42003-000001
7 92011-002979
8 41108-000103
9 42004-000038
10 42007-000001
11 22001-000259
12 41101-000244
13 41108-000012
14 41105-000104
15 31101-000597
16 10502-100028
17 42001-000103
18 22001-000313
19 41199-002713
20 41101-000066
21 41103-000216
22 41109-000038
23 10104-100014
24 22013-000777
25 A1101-008446
26 41110-000214
27 41110-000258
TCL Air Conditioner Service Manual
Part Name
Front Panel
Air Filter
Face Frame
Electrical Box Cover
Display PCB
Display PCB Box
Evaporator
Screw Cover
Cross Fan
Bearing Mount
Indoor Motor
In And Out Pipe Fixer
Indoor Motor Cover
Electrical Box
Main PCB
Transformer
Cable Clamp
Vane Motor 1
Base
Vertical Vane Assembly
Vane
Installation Plate
Indoor Sensor Assembly
Remote Controller
Indoor Carton
Left Foaming
Right Foaming
13
Q'ty Remark
1
2
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
Not shown in
1
Explosion view
1
1
