TCL TAC-07CHSA/VB Service Manual page 21

Outdoor Unit - TAC-24CHSA/VB
8
9
10
No. Part No.
1 42011-000107
2 41207-000019
3 92011-000646
4 41203-000040
5 22001-000019
6 42004-000086
7 41205-000128
8 41206-000026
9 42011-000069
10 92014-000246
11 92008-000180
12 92007-000880
13 41202-000160
14 41205-000058
15 92008-000018
16 41204-000014
17 92008-000116
18 41201-000005
19 42001-000037
20 42001-000038
21 11304-100007
22 10303-100017
23 22003-000007
24 42001-000030
25 41201-000005
26 92007-001911
27 41208-000120
28 A1201-009095
29 A2005-000493
30 41213-000007
TCL Air Conditioner Service Manual
7 6
5
11
Part Name
Back Grille
Top Cover
Condenser
Outdoor Motor Supporter
Outdoor Motor
Propeller Fan
Left Grille Supporter
Front Plate
Fan Guard
Compressor
4-way Valve
4-way Valve Assembly
Base
Right Plate
Two-way Valve
Valve Supporter
Three-way Valve
Electrical Box Cover
Cable Clampφ6
Cable Clampφ10
Terminal
Fan Motor Capacitor
Compressor Capacitor
Capacitor Strip
Electrical Parts Box
Capillary Assembly
Partition plate
Cabinet Carton
Base Carton
Cover Foam
4
3
12
Q'ty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
20
2
13 15 16
14
Remark
Not shown in
explosion view
1
27
26
25
24
23
22
21
20
19
18
17
