Model Numbers:
CH-09DKT230VI/ CH-09DKT230VO
CH-12DKT230VI/ CH-12DKT230VO
CH-18DKT230VI/ CH-18DKT230VO
CH-24DKT230VI/ CH-24DKT230VO

Table of Contents

1.
2.
3.
4.
5.
6.
7.
8.
9.
dakota HYPER MINI Split Air
Conditioner WITH HEAT PUMP
SERVICE MANUAL
