MULTI DUCTLESS INVERTER HEAT PUMP FLOOR AND CEILING TYPE INDOOR UNIT OWNER'S AND INSTALLATION MANUAL Models: CH09UFC230VI CH12UFC230VI CH18UFC230VI CH24UFC230VI... -
Page 2: User Notice
User Notice ◆ When installing, the entire capacity of the cooperating indoor unit should be not larger than 150% of outdoor unit, otherwise, it will cause the shortage of cooling (heating) capacity. ◆ The power supply of the entire unit must be the power supply of outdoor unit. And disconnect the main power of outdoor unit before cleaning. -
Page 3: Table Of Contents
Contents 1 Safety Precautions ..................1 2 Installation Precautions and Location Choosing ..........2 2.1 Installation Precautions ..................2 2.2 Location Choosing ....................2 2.3 Imappropriate Location ..................2 3 Installation of Floor and Ceiling Type Indoor Unit ..........3 3.1 Space Dimension for Unit Installation .............. -
Page 4: Safety Precautions
Free Match 1 Safety Precautions Please read this manual carefully before using this unit. Operate it correctly according to the guide in this manual. Please pay special attention to the indicating meaning of these two marks: Warning! This mark means that the unit may cause property damage, personal injury or loss of life if the operation is incorrect. -
Page 5: Installation Precautions And Location Choosing
Free Match 2 Installation Precautions and Location Choosing 2.1 Installation Precautions The installation of air conditioner must be conform to national and local safety laws. Installation quality will directly affect the normal use of air conditioner. Do not attempt to install the air conditioner by yourself. Please contact your dealer after buying this machine. -
Page 6: Installation Of Floor And Ceiling Type Indoor Unit
Free Match 3 Installation of Floor and Ceiling Type Indoor Unit 3.1 Space Dimension for Unit Installation The space around the unit is adequate for ventilation. (Refer to Fig.1) POWER TIMER >24 >24 >40 >12 >8 >59 >24 >24 Fig.1, distance in inches 3.2 Important Notice (1). - Page 7 Free Match (Refer to Fig.5). Installation Side panel fixing screw(M4) paper plank Fig.2 Fig.3 (3). Set the suspension bolt. (Use W3/8 or M10 size suspension bolts) ＊ Adjust the distance from the unit to the ceiling slab beforehand. (Refer to Fig.4) (4).
- Page 8 Free Match Celling Hanger bracket 1 3 /5” or less Hanger bracket setting bolt(M8) Suspension bolt Hanger bracket Hanger bracket fixing bolt(M6) Fig.4 Fig.5 Celling slab Hanger bracket Fig.6 Fig.7 Fig.8 Fig.9 When installing the indoor unit, you can refer the paper pattern for installation. Make sure that the drainage side must be 0.39in (10mm) lower than the other side in order to drain the condensate water easily.
-
Page 9: Electrical Wiring
Free Match Model CH09UFC230VI CH12UFC230VI 48in 28in 46in 11in (225mm) (1220mm) (700mm) (1158mm) (280mm) CH18UFC230VI CH24UFC230VI 3.4 Electrical Wiring Caution: The power of every indoor unit should be connected in outdoor unit. Open front panel. ① . Remove the electrical box cover. -
Page 10: Drainpipe Installation
Free Match CH42MVCT230VO POWER Caution! T he incorrect of wiring connection would lead malfunction of some of the electric parts. ① . B e sure to leave some space between the connecting end and the clamp end after the ② . wiring is fixed. -
Page 11: Install The Connection Pipes
Free Match ＊ Either the right rear or right side of the unit is suitable for fixing the drainpipe. ＊ The diameter of the drainpipe should be equal to or greater than that of the connecting pipe. ＊ Take the drainpipe as short as possible and slope downward at a gradient of at least 1/100 to prevent air pockets.(Refer to Fig.10) ＊... - Page 12 Free Match Pipe Flare Nut Pipe Spanner Nut-Required Torque Pipe Diameter (mm) Required Torque φ6.35 15--30 φ9.52 35-40 φ12 45-50 φ15.9 60-65 (1). Align the flared end of the copper tube with the threaded connector, and then hand-tighten the flared nut. (2).
-
Page 13: Part Names Of Floor And Ceiling Type Indoor Unit
4 Part Names of Floor and Ceiling Type Indoor Unit Air outlet Guide louver Front panel Air filter, purifier (in air inlet grille) Connecting pipe Air inlet Suitable model: CH09UFC230VI CH12UFC230VI CH18UFC230VI CH24UFC230VI Note: Different models of air conditioners as shown above have the same appearances. -
Page 14: Working Temperature Range
Free Match 5 Working Temperature Range Working Temperature Range Indoor side state ℉（℃） Outdoor side state ℉（℃） Dry bulb Wet bulb Dry bulb Wet bulb temp. ℉（℃） temp. ℉（℃） temp. ℉ （℃） temp. ℉ （℃） Rated. Cooling 80.0(26.7) 67.0(19.4) 95.0(35.0) 75.0(23.9) Max. -
Page 15: Maintenance Method
Free Match 6 Maintenance Method Warning! T urn off the unit and cut off the power supply when cleaning the air conditioner, otherwise, ① . electric shock may happen. D o not let the air conditioner get wet, or it will cause electric shock. Ensure that the air ②... -
Page 16: Operating Instructions
Free Match 7 Operating Instructions ＊ Airflow direction will be changed by ＊ The expected temperature should adjusting the louvers and flaps as shown, be set at a moderate level to avoid of accordingly well air condition the room unnecessary energy consumption. temperature. - Page 17 Free Match ＊ Check electrical system (voltage and frequency). Use the power supply indicated ＊ If electric shock suddenly happens, turn on the nameplate of the unit to operate the off the unit. If the unit is not to be used air conditioner and only fuses with specified for a long period, cut off the main power capacity should be done by technicians.
-
Page 18: Malfunction Analysis
Free Match 8 Malfunction Analysis Warning! Repairing work should be done by Gree technicians. For saving your time and spending, please check the following malfunction analysis before contacting customer service center. Malfunction Phenomena Malfunction Analysis After turning off the air The overload protection switch of the unit needs 3 mins before conditioner, the unit could not restarting. -
Page 19: After-Sales Service
Free Match ＊ When there is water leakage from indoor unit. ＊ When the power cord is overheating. ＊ Odor gives out when the unit is running. 8.2 After-sales Service Please contact the dealer if the air conditioner has any quality problems. - Page 20 www.cooperandhunter.us LIMITED WARRANTY STATEMENT Ductless Heat Pump Multi-Split System This warranty should be registered on our web-site www.cooperandhunter.us The warranty is only valid when installed by a Licensed HVAC Technician FOR WARRANTY SERVICE OR REPAIR: Contact your installing contractor. You may find the installer’s name on the equipment or in your Owner’s packet. Complete product registration below and send back by e-mail at PRODUCT REGISTRATION: Model No.: ______________________________________________________________________________________________...
- Page 21 LIMITATIONS OF WARRANTIES: ALL IMPLIED WARRANTIES AND/OR CONDITIONS (INCLUDING IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE OR PURPOSE) ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, SOME STATES OR PROVINCES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR CONDITION LASTS, SO THE ABOVE MAY NOT APPLY TO YOU.
