JOLIN LAB TABOR Build Manual

Hide thumbs
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual
Hi fellow!
Just a quick intro before starting,

Materials to have near you:

1. Soldering Iron - better with temperature control
2. Solder wire
3. A pair of tweezers
4. Multimeter
5. Cutter
6. Solder sucker / wick (optional)
7. Silicone soldering mat (optional)
8. Helping hands (optional)
9. Flux (optional)
If you want to refresh yourself a bit about soldering stuff you can watch
Another tool that can help you finding the components on the boards is the interactive BOM linked
here:
Download it and open the .html file with a browser. You can use it to check where a component is
located on the board. Works also offline.
1
https://www.youtube.com/watch?v=VxMV6wGS3NY
TABØR
smd pre-soldered build guide
∞
tinyurl.com/taborsmdbom
1
this video
by GreatScott!
1
