LG GSA-E20N Quick Start Manual

Installation
Hardware Installation
• Make sure you have a personal computer with
an open USB port before connecting the drive
to your computer.
• Power for all devices should be turned off
before attaching the cables.
Connect the drive to the computer and to a
camcorder, VCR or video device with
Audio/Video cables or S-video cable
(not supplied.) as shown in figure.
A. Connecting to computer
Connect the USB converter cable to the
External Super Multi DVD Rewriter.
Connect the other end of the USB
converter cable to your computer.
Connect the AC adapter plug to the
power connector at the rear of the drive.
Attach the AC adapter to the AC wall
outlet.
When the computer is ready, confirm
that the drive is detected. And then,
insert the supplied software CD into the
External Super Multi DVD Rewriter and
install the software.
B. Connecting to Camcorder or
Video Device
Connect the Camcorder or Video device.
Refer to the manual supplied with the
device to be connected.
NOTE
• If your Video device is equiped with S-Video
output, you can connect an RCA cable from
the audio output of the video device to the
audio input of the drive, and S-Video cable
from the S-Video output of the video device
to the S-Video input of the drive.
USB converter cable
To AC wall outlet.
OR
