External
Super Multi DVD Rewriter
SERVICE MANUAL
MODEL: GSA-E10N
/GSA-E10L
P/NO : 3828HS1050E
June, 2006
Printed in Korea
MODEL : GSA-H10N/GSA-E10L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GSA-E10L and is the answer not in the manual?

Questions and answers

Related Manuals for LG GSA-E10L

Summary of Contents for LG GSA-E10L

  • Page 1 External Super Multi DVD Rewriter SERVICE MANUAL MODEL: GSA-E10N /GSA-E10L P/NO : 3828HS1050E June, 2006 Printed in Korea MODEL : GSA-H10N/GSA-E10L...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION 1 : GENERAL INTRODUCTION ..................................3 GENERAL FEATURES .................................3~4 SPECIFICATIONS.................................5~8 OPERATING MANUAL ...............................9~17 DISASSEMBLY ..................................18 1. TOP COVER ...................................18 2. INTERNAL DVD MULTI DRIVE ............................18 3. USB/1394 BRIDGE BOARD............................18 EXPLODED VIEW ................................19~20 MECANICAL REPLACEMENT PARTS LIST ........................21~23 MAJOR IC INTERNAL BLOCK DIAGRAM AND PIN DESCRIPTION(USB BRIDGE BOARD)........23~29 USB BRIDGE BOARD TROUBLESHOOTING GUIDE ......................30 POWER CORD SECTION ...............................31...

  • Page 3: Supported Disc Formats

    SECTION I GENERAL INTRODUCTION This service manual provides a variety of service information. It contains the mechanical structure of the External Super Multi DVD Rewriter and the electronic circuits in schematic form. This External Super Multi DVD Rewriter was manufactured and assembled under our strict quality control standards and meets or exceeds industry specifications and standards.
  • Page 4 Ultra DMA Mode 4 66.6 Mbytes/s max. Multiword DMA Mode 2 16.6 Mbytes/s max. PIO Mode 4 16.6 Mbytes/s max. 6) Multimedia MPC-3 compliant * You can use a variety of Drive. GSA-E10N GSA-E10L LightScribe USB2.0 only USB2.0 only Internal Drive GSA-H10N GSA-H10L...

  • Page 5: Specifications

    SPECIFICATIONS I. MODEL : GSA-E10L 1. SYSTEM REQUIREMENTS -CPU: IBM Compatible Pentium 4 2.8GHz (or faster) -512MB Memory or greater -USB 2.0 support 2. SUPPORTING OPERATING SYSTEM * Operating System * Recording tool Window 2000 Professional (1) Nero(Ahead) Window XP Home Edition, Professional (2) In CD(Ahead) (3) Power Producer Gold (Cyber Link) 2.1 Applicable disc formats...

  • Page 6: Drive Performance

    2.3 Disc diameter ..........120mm 80mm (Horizontal only) 2.4 Data capacity • User Data/Block DVD-ROM/R/RW/RAM/+R/+RW ..2,048 bytes/block CD (Yellow Book) ..........2,048 bytes/block(Mode 1 & Mode 2 Form 1) 2,336 bytes/block (Mode 2) 2,328 bytes/block (Mode 2 Form 2) 2,352 bytes/block (CD-DA) 2.5 RPC (Regional Playback Control) Phase2, No Region 3.
  • Page 7 * Rotational speed (CLV, ZCLV) DVD-R/RW/ROM, +R/RW .......1x: Approx. 1,390(Inside) - 580 r/min(Outside) DVD-RAM........Ver. 1.0 ...1x: Approx. 2,390(Inside) - 1,010 r/min(Outside) Ver. 2.2 ...2x: Approx. 3,250(Inside) - 1,380 r/min(Outside) CD-R/RW/ROM ..........1x: Approx. 500(Inside) - 210 r/min(Outside) *1) “+” : change by step for ZCLV *2) “-”...

  • Page 8: Quality And Reliability

    INPUT : 100-240V AC, 0.6A 47-63Hz OUTPUT : 12V DC 2A (max2.5A) 6. Dimensions External dimensions (W x H xD) 160x 50 x 230mm 7. Mass ..........Approx. 1,500g * Please Contact the friendly staff of LG Service Care at: Website http: //www.LGEservice.com...
  • Page 9 OPERATING MANUAL Contents Introduction System requirements ................10 Important precautions ................11 Location and function of controls ...............12 Installation Hardware Installation ................13 Removing the USB converter cable ............14 Operation Loading and ejecting a disc ...............15 Playing a music CD..................16 Playing DVD video and MPEG2 movie video ...........16 Appendix Troubleshooting ..................17 WARNING: Only drives bearing the logo Compact Disc ReWritable Ultra Speed...

  • Page 10: System Requirements

    Windows 2000 Professional(SP4)/XP(Home Edition/ Software Required Professional/SP2), Direct X 9.0 or Higher is required. CD-R, CD-RW, CD-R : LG, Mitsubishi Kagaku Media, Verbatim, Taiyo Yuden, TDK discs are recommended. DVD-R, DVD-RW, CD-RW : LG, Ricoh, Mitsubishi Kagaku Media, Verbatim discs DVD+R, DVD+RW, are recommended.

  • Page 11: Important Precautions

    Important precautions Follow these precautions when handling the drive or discs. Precautions Please note that the manufacturer of this equipment does not offer any warranty against data loss due to inappropriate installation, handling, direct or indirect damages. Please note that the manufacturer will bear no responsibility for direct or indirect damages (including lost data)caused by the use of this product or its malfunction.

  • Page 12: Location And Function Of Controls

    Location and function of controls This following is the general figure of the design of the drive. The driveʼs appearance and specifications may change without prior notice. 1. Disc Tray 2. Drive activity indicators The LED used to indicate the operation of External Super Multi DVD Rewriter.

  • Page 13: Installation

    Installation NOTES Connecting to computer Make sure you have a personal computer with an open USB port before connecting the drive to your computer. Power for all device should be turn off before attaching the cables. Connect the drive to the computer as shown in figure.

  • Page 14: Removing The Usb Converter Cable

    Removing the USB converter cable The drive supports the plug and play(not swap) function of Windows, and can be removed and inserted by performing the following operation. 1. Stop the application softwre being currently used. 2. Clic k the icon " "...

  • Page 15: Operation

    Operation Loading and ejecting a disc Remember - AC adapter must be connected. Make sure the power is turned on. Loading a disc 1. Push the Eject Button to open the Disc tray. 2. Load a disc. (Label facing up.) 3.

  • Page 16: Playing A Music Cd

    Playing a music CD Listening to sound When connected to a computer, you can play audio CD’s through your computer’s audio system after setting Digital Audio mode. Check your Windows or “Windows Media Player” manual for detail. Playing DVD video and MPEG2 movie video The drive must be connected to a computer, and basic installation already done.

  • Page 17: Appendix

    Appendix Troubleshooting If you are experiencing problems with the drive, verify the following items. Since the problem may be caused by a device other than the drive, check other things such as system settings or other software being used, etc. If you cannot resolve the problem after verifying these items, contact your dealer or our customer service department.

  • Page 18: Disassembly

    DISASSEMBLY 1. TOP COVER 3. USB BRIDGE BOARD A. Remove 4 side rubbers and release 5 screws(A). A. Release 2 screws(B) and remove Top Shield (3). B. And then, remove Top Cover and Front B. Release 4 screws(C) and remove the Plate Decoration in the direction of arrow(1).

  • Page 19: Exploded View

    EXPLODED VIEW PBS00 (USB C.B.A)

  • Page 20: Mecanical Replacement Parts List

    ROUND D5.5 4MM PA 5.5 MM Note: Refer to DVD MULTI DRIVER ASSY REPLACEMENT PARTS LIST in order to look for the part number of A40. MISCELLANEOUS PARTS 3828HM1012E MANUAL, INSTALLATION EXTERNAL DRIVE GSA-E10N/E10L 3840HF1035L CARD, INFORMATION D.O.C SHEET GSA-E10N/E10L 3840HR1010A CARD, REGISTRATION...
  • Page 21 3828HM1012E MANUAL, INSTALLATION EXTERNAL DRIVE GSA-E10N/E10L 3840HR1010A CARD, REGISTRATION OPTICAL STORAGE[LGEUS] 3840HW1023B CARD, WARRANTY NORTH OR SOUTH AMERICA, OPTICA 3890H-2048A GIFT GSA-E10N WITH HANDLE 3890H-2127A SHIPPING GSA-E10N LG(W/W)-KR 3920H-1121A PACKING INDIVIDUAL GSA-5160B (EXTER) 6956H-D030H COMPACT DISC TITLE, CD-R GSA-E10N 6851HC3005A...

  • Page 22: Major Ic Internal Block Diagram And Pin Description(Usb Bridge Board)

    MAJOR IC INTERNAL BLOCK DIAGRAM AND PIN DESCRIPTION (USB Bridge Board) IC101(PL2507C) : Hi-Speed USB 2.0 to IDE Bridge Controller 1-1. General description The PL-2507C is a single chip Hi-Speed USB-to-IDE bridge controller that is designed to perform seamless protocol transfer between the USB and ATA interface. The operating speed is determined by the capability of the host/hub it is connected to.
  • Page 23 2.0. PIN Assigment & Description 2-1. Pin Assigment for LQFP64 Package...
  • Page 24 2-2. USB2.0 PHY Related Pins...
  • Page 26 IC501(X6417CE01) : High speed LDO Regulator+VD 1. Block Diagram 2. Pin Configuration and Pin Assignment Power 3. Function OPERATION...

  • Page 27: General Description

    IC505(APW1172) :2.5A SWITCH STEP DOWN SWITCHING REGULATOR 1. General Description The APW1172 is a step down monolithic power switching regulator with a switching current limit of 3.8A so it is able to deliver more than 2.5A DC current to the load depending on the application conditions. The output voltage can be set from 1.235V to 22V.The high current level is also achieved utilize an SO8 package with exposed pad frame.

  • Page 28: Pin Function Description

    3. Block Diagram 4. Pin Function Description Description Regulator Output. SYNC Master/Slave synchonization. A logical signal (active high) disables the device. If INH not used the pin must be connected to GND. When it is open an internal pull-up disable the device. COMP E/A output for frequency compensation.

  • Page 29: Usb Bridge Board Troubleshooting Guide

    USB Bridge Board Trouble Shooting Guide Drive Operation? Check the Adaptor Power.(12V) Check the Power Cable connection. • CN601 pin 1, 4 (5V,12V) Check the DC-DC Converter Circuit.(5V) • IC505(APW1172), L501, D501 about 11V Switching Frequency (IC505 pin1) 250 + 25 KHz USB Operation? Check the USB Cable connection.

  • Page 30: Power Cord Section

    POWER CODE SECTION UK (6410HE1201J) America (6410HE1201M) Australia (6410HE1201N) Corea (6410HE1201K) Euro (6410HE1201L)

  • Page 31: Block Diagram

    BLOCK DIAGRAM (USB2.0 BRIDGE BOARD)

  • Page 32: Circuit Diagram

    CIRCUIT DIAGRAM...

  • Page 33: Section Ii Dvd Multi Drive Assy Disassembly

    SECTION II DVD MULTI DRIVE ASSY DISASSEMBLY 1. CABINET and CIRCUIT BOARD 1-3. Cabinet and Main Circuit Board DISASSEMBLY A. Remove the Cabinet in the direction of arrow (4). (See Fig. 1-3) 1-1. Bottom Chassis B. When the CD tray has been opened completely, lift A.

  • Page 34: Pick-Up Unit

    2. MECHANISM ASSY DISASSEMBLY 2-1. Pick-up Unit A. Release screws (B). B. Separate the Pick-up Unit in the direction of arrow (6). Pick-up Unit Mechanism Assy Fig. 2-1 2-2. Pick-up A. Release 1 screw (C) and remove the Pick-up. Pick-up Unit Pick-up Fig.

  • Page 35: Exploded View

    EXPLODED VIEW PBM00 (MAIN C.B.A) PBF00 (FRONT C.B.A) (LightScribe only)

  • Page 36: Dvd & Cd Data Processing

    DVD & CD DATA PROCESSING 1. Data Processing Flow...
  • Page 37 2. Copy Protection and Regional Code Management Block Block Diagram Change the “KEY” HOST DVD PLAYER R8J32018 (EMPEG2 B/D) Scrmbled MPEG data KEY Magagement Control Brief Process 1. Regional Code for DVD Disc – DVD-ROM drive transfers the regional code of the control data to host by the command of host, the DVD player of host reads the regional code, and plays title in the case of allowed regional code only.

  • Page 38: About Prevention The Dvd-Rom From To Be Copy

    3. About Prevention the DVD-ROM from to be copy A data is able to encode and record in the disc, if a copyright holder wants to prevent the disc from copying. In case of a disc enhanced movie of 3 titles..DISC KEY (2048 Bytes) is used to encode the whole contents in the disc and TITLE KEY (5 Bytes) is used to encode the title respectively.

  • Page 39: About The Dvd-Rom Regional Code

    4. About the DVD-ROM Regional Code Regional code U.S.A PRI. VIR DISC ROM - DRIVE MPEG-2 BOARD VGA CARD MONITOR Transfer to Receiving If the board is setting to the regional The disc has MPEG-2 board data from the code 1 for the U.S.A..the regional reading the MPEG-2...

  • Page 40: Internal Structure Of The Pick-Up

    INTERNAL STRUCTURE OF THE PICK-UP 1. Block Diagram of the PICK-UP(HOP-7642TS) Tilt- 44 Tilt+ IC2(FM) 43 TR- 42 TR+ CD-VR 41 AF- 40 AF+ 39 GND(FM) 38 FM DVD-VR 37 VREF 36 SEL 35 VCC(FM) 34 ENA 33 IAPC 32 SLG 31 VSA5 30 VSL25 IC2(LDD)

  • Page 41: Pick Up Pin Assignment

    2. Pick up Pin Assignment Signal Name Signal Description GND(OEIC,TEMP) Ground for OEIC Vcc(OEIC) Power supply for OEIC Vc(OEIC) Reference voltage input for OEIC GAINSW OEIC output gain control (High:Low gain, Middle:Middle gain, Low:High gain) E3+F3 Single OEIC output EF3 Single OEIC output B Single OEIC output D E4+F4...

  • Page 42: Signal Detection Of The P/U

    3. Signal detection of the P/U Infrared Iaser Pick-Up module Focusing Tracking Photo Diode 1) Focus Error Signal ==> (A+C)-(B+D) This signal is generated in RF IC (IC101 : R2S35004) and controls the pick-up’s up and down to focus on Disc.

  • Page 43: Description Of Circuit

    DESCRIPTION OF CIRCUIT 1. ALPC (Automatic Laser Power Control) Circuit 1-1. Block Diagram...

  • Page 44: Alpc (Automatic Laser Power Control) Circuit

    1-2. ALPC (Automatic Laser Power Control) Circuit ALPC function DVD/CD anlaog front-end IC(IC101 R2S35004) is for constant power control purpose. Based on the accurate power sensor(FMON) in P/U, ALPC feedback loop maintains constant power level against laser diode’s temperature variation. The ALPC loop amplifies(10x) the FMON signal to enhance the accuracy of read power level control.

  • Page 45: Focus Circuit

    2. Focus Circuit 2-1. Block Diagram A+B+C+D HAVC A,B,C,D 0.8V IC101 R2S35004 HAVC A,B,C,D (EF1~EF4) R102 Disc (A+C)-(B+D) Optical (A+C)-(B+D)+K[(EF1+EF3)-(EF2+EF4)] Motor unit Pick-up C405 HOP-7642TS R103 Focusing C406 Compensator IC301 FACT- FACT+ R8J32018 R329 FOIN FACT+ C335 FACT- IC601 1.65V R2S30202FP CTL1 CTL2...

  • Page 46: Tracking & Sled Circuit

    3. Tracking & Sled Circuit 3-1-1. Block Diagram (Tracking Following) IC101 R2S35004 MPPO (A+D)-(B+C) HAVC SPPO A,B,C,D (EF1~EF4) Disc R101 Optical (A+D)-(B+C)-K[(EF1+EF4)-(EF2+EF3)] Motor unit Pick-up HOP-7642TS C101 Tracking Compensator TACT- TACT+ Sled IC301 Compensator R8J32018 SLED MOTOR Unit (CN601) R330 TOIN TACT+ IC601...
  • Page 47 3-1-2. Block Diagram (Seek) IC101 R2S35004 MPPO (A+D)-(B+C) HAVC SPPO (EF1~EF4) A,B,C,D [(EF1+EF4)-(EF2+EF3)] Disc Optical VREF1 Motor unit Pick-up A+B+C+D HOP-7642TS TACT+ VREF1 TACT- HAVC MIRR MIRR SUMF BOTTOM RFIP HOLD HOLD SLED MOTOR RFIN Unit MIRRTOPH MIRRBOTH C128 C127 C101 IC301 R8J32018...
  • Page 48 3-2-1. Tracking Servo The aim of tracking servo is to make laser beam trace the data track on disc. Tracking Error(TE) Signal is generated from tracking error detected block in R2S35004 using DPP(Differential Push-Pull) Method and DPD (Differential Phase Detection) Method. DPP Method uses not only main beam(A, B, C, D) but also side beam(EF1~EF4) for correcting DC offset generated in Push-Pull Method.

  • Page 49: Spindle Circuit

    4. Spindle Circuit 4-1-1. Block Diagram(FGCAV Servo) Optical Pick-up HOP-7642TS Disc Motor unit X301 33.8688MHz VCK4M IC301 Control Clock R8J32018 Generator CAV FD R349 CAV PD VCK4M R361 R375 Motor Kick 3.3V C349 1.65V SPIN IC601 DAVC 1.65 R2S30202FP CTL1 CTL1 CTL2 CTL2...
  • Page 50 4-2-1. Block Diagram (Wobble CLV Servo) C116 C117 C118 WAG1 WAG2 WAG3 18 19 AGC1 AGC2 Disc Motor uni t Optical Pick-up C171 AGC3 HOP-7642TS C172 WOBSIG C173 VREF C174 IC101 WBLSH R2S35004 WBLS IC301 1.65V R8J32018 R375 R349 C349 Motor Kick 1.65V 4-2-2.

  • Page 51: Major Ic Internal Block Diagram And Pin Description

    MAJOR IC INTERNAL BLOCK DIAGRAM AND PIN DESCRIPTION IC101 (R2S35004) : RF AMP Analog Signal Processor Pin Assignment AGFU MCLK AGFR PORT07 PORT06 (5V)VCC1 PORT05 SUMF/SUMF2 PORT04 RFIP PORT03 RFIN PORT02 SRVREF PORT01 FVREFO R2S35004 PORT00 IREFT R2S35002 VREF1 GND4 HAVC (TOP VIEW) IP1/LPPOUT...
  • Page 52 Block Diagram *3300p 3300p 0.1u Lo-Z function by IDGATE. VREF1 0.47u fast mode 3.3us (*2) *3300P/0.068u 4700p Lo-Z function by IDGATE. mclk to MIRR.DEFECT 0.068u RFIP SUBP.N EQOP RF SLIM/SUB RFIN EQON (RGA) AUTO SUMF2 0.068u EQOS to WRF IP1/LPPOUT ATEST LPPMON/EQOS/RRF/WRF IP2/MIRR...
  • Page 53 • Pin Functions pin Name pin No. Type max. voltage Function Analog-Output Tracking error output terminal Analog-Output Focus error output terimnal Analog-Output PE output terminal Analog-Output Lens error output terminal BCENT Analog-Output OPC center signal output terminal PHBETA/TCE Analog-Output OPC top hold level signal and APC write sampleing signal output terminal/tilt servo detecting output terminal BHBETA/TIE Analog-Output...
  • Page 54 pin Name pin No. Type max. voltage Function BLANK Digital-Output Record/non-record detecting/BD detecting output terminal WOBSIG Digital-Output WOBBLE signal output terminal IP2/MIRR Digital-Output ID detection/Mirror detection output terminal IP1/LPPOUT Digital-Output ID detection/LPP detection output terminal Digital-Output Defect detection output terminal GND4 Ground Ground connected terminal (Digital)
  • Page 55 pin Name pin No. Type max. voltage Function SUBO/LPPMON Analog-Output ID detecting HPF output terminal/LPP detecting HPF output terminal EQFCF External-capacitor required Terminal to connect RF-equalizer fc auto-adjustment external capacitor IREFE External-resistor required Terminal to connect RF-equalizer fc setting external resistor AGHPF2 External-capacitor required...

  • Page 56: Pin Layout

    IC301 (R8J32018FPV) : Encoder, Decoder & DSP Singal Processor 1.1 Pin Layout VSSR W2LPF0 VCCR W2LPF1 CPU14 W2LPF2 CPU13 VDD AA CPU12 VSSAA VSSIO DE FECT VCCIO BL AN K VCCRQ LN DTRK CPU11 WOBSIG CPU10 L OWZB VSSRQ ID GATE CPU9 RFH L D CPU8...
  • Page 57 1.2 Block Diagram LOUT AUDIO ROUT AUDIO DOUT DREQ Data VINP DACKB VINN CD-ROM DASPB Descramble Decoder CS3FXB REXT CS1FXB PRML PTEST [2:0] PDIAGB ATAPI W1LPF[2:0] CD-DSP Scramble WPLL Jitter IOCS16B W2LPF[2:0] Counter HINTRQ IORDY ZIORB ZIOWB Wobble WOBSIG Generator Detector HRSTB DATA [15:0]...
  • Page 58 1.3 Pin Table Pin no Pin Name Pin no Pin Name Pin no Pin Name Pin no Pin Name VSSR DOUT W1LPF2 VCCR GPIO05 TEST0 W1LPF1 CPU14 VSSIO TEST1 W1LPF0 CPU13 VCCIO TEST2 VCCA CPU12 HRSTB TEST3 VSSA VSSIO DATA7 VSSA VCCIO DATA8...

  • Page 59: Pin Functions

    1.4 Pin Functions It corresponds to the following signs as a pin I/O specification. AI : Analog Input IOU : Standard Input/Output with Pull Up AO : Analog Output 5I : 5V Tolerant Input AIO : Analog Input/Output 5O : 5V Tolerant Output Standard Input 5TO : 5V Tolerant Three State Output...
  • Page 60 Servo Pin List Pin Name Pin No. I/O destination Function BLANK Blank signal input (also connected to the H8S interrupt port INT5) DEFECT Defect (scratch detect) signal DRVR Spindle FG pulse (also input to the H8S interrupt port INT4) Spindle FG pulse for Light Scribe (also input to the H8S interrupt port INT4) DRVR Tilt drive signal (PWM output)
  • Page 61 ATAPI Interface Pin List Pin Name Pin No. destination Function HRSTB ATAPI ATAPI-IF control signal (host reset signal) ATAPI ATAPI-IF register address signal DATA[15:0] 79,77,71, ATAPI ATAPI- IF data bus 69,67,65, 63,61,60, 62,64,66, 68,70,76, DREQ ATAPI ATAPI-IF DMA request signal ZIOWB ATAPI ATAPI-IF write strobe pulse...
  • Page 62 Encoder Interface Pin List Pin Name Pin No. I/O destination Function IP1LPPIN PID area identification signal/LPP input signal IP2MIRR PID area identification signal/MIRR signal WOBSIG Wobble signal input LOWZB Input impedance switch control signal/SPDSH; running OPC sampling pulse (Pit top) IDGATE ID/data switch signal RFHLD...
  • Page 63 Audio Interface Pin List Pin Name Pin No. destination Function DOUT ATAPI Digital output pin,also functions as the CPU general port 1-2 ROUT ATAPI Audio Lch & Rch output LOUT Clock Generator Pin List Pin Name Pin No. destination Function FEMCK Front End LSI clock X’tal...
  • Page 64 LSI/TEST Control Pin List Pin Name Pin No. destination Function MRSTB RESET IC Master reset input TESTB2 Test select TESTB1 E10emulator Test data switch for E10emulator E10emulator Test clock for E10 emulator It can function as a SCI serial clock output port when E10 emulator is not used (multiplexed).
  • Page 65 Power Supply/GND Pin List Pin Name Pin No. Function 28,41,72, DSP core power supply (1.5V) 130,146 VCCR 2,53 SDRAM power supply (3.3V) VCCRQ 8,26 SDRAM I/O power supply (3.3V) VDDAA 1.5V system analog power supply (1.5V) WPLL1,2 189,193,197 1.5V system analog power supply (1.5V) PRML A/D Data PLL VCCA Analog power supply (3.3V):AUDIO / ADIP Analog power supply (3.3V):PLL multiplication...

  • Page 66: Pin Function

    IC601 (R2S30202FP) : SPINDLE MOTOR AND 6CH ACTUATOR DRIVER Pin Layout R2S3 0202FP Package outline : 42 PIN POWER SSOP (42P9R-K) Pin Function No Pin name Function Pin name Function SPIN Spindle control voltage input Reference voltage input SL1IN Slide control voltage input1 LOIN Loading control input SL2IN...
  • Page 67 Block Diagram...
  • Page 68 Input/Output circuit diagram SPIN, SL1IN, SL2IN FOIN, TOIN,TLIN EN1, EN2 LOIN TEST 5VCC 5VCC 5VCC 5VCC SPGS ACTFLG,FG ACTRST COMMON (Temperature monitor) 5VCC 5VCC 5VCC 5VCC 5VCC COMMON VM1, U, V, W VM2, SL1+, SL1-, SL2+, SL2- SL1+ SL1- SL2+ SL2- 5VCC, FO+, FO-, TO+, TO-, TL+, TL- VM3, LO+, LO-...

  • Page 69: Troubleshooting Guide

    TROUBLESHOOTING GUIDE (01) Laser Power Adjust (using RD Power/WR Power/Erase Power) MPU & DSP IC301 Pickup Setting Pin#175 Front Monitor Driver IC101 IC102 pin#98 (02) High Frequency/NRZI skew Adjust Pickup 17,18,20,21 MPU & DSP Driver IC301 (03) Data Slice/Equalizer Boost/Raw Slice/ Equalizer Frequency Adjust Pin#79 MPU &...
  • Page 70 (06) Focus Amp. and Total Amp. Adjust All Disc Setting Pin# Pickup 87-90 FE:R102,C405 IC101 MPU & DSP IC301 PE:R103,C406 Focus:#34-35 R329, Driver C335 IC601 (07) Tracking Amp. Adjust All Disc Setting Pin# Pickup 87-90 IC101 TE:R101,C101 MPU & DSP IC301 Tracking #30-31...
  • Page 71 (09) Unwritten Slice Level Adjust for DVD-RAM DVD-RAM Disc Pin# Setting 80-81 IC101 Pickup MPU & DSP IC301 SIGM:R148, C151 #100 #171 Slider FPC Slider:#6, 8-10 Driver IC601 (10) Focus Offset Adjust for DVD-ROM, CD-R/RW DVD-ROM Disc Pin# 87-90,80-81 Setting IC101 MPU &...
  • Page 72 (13) Tilt Adjust for DVD-RAM DVD-RAM Disc Pin# Setting Pickup 87-90,80-81 IC101 TCE:R106, C106 MPU & DSP IC301 TIE:R107,C107 Slider FPC Driver Slider:#6, 8-10 IC601 (14) Tilt Adjust for DVD-R/RW, DVD+R/RW, CD-R/RW DVD-R/RW Disc Pin# Setting 87-90, 80-81 IC101 TE:R101, C101 MPU &...
  • Page 73 (17) Lens Sensitivity Adjust Pickup MPU & DSP (Temp.Information) #178 IC301 putemp (18) Spindle Offset Adjust Pin# #211 Spindle 12-14 Driver MPU & DSP IC601 IC301 SPD:R349, C349 #213 (19) ADIP BPF/Read Timing Adjust for DVD+R/RW DVD+R Disc Setting Pin# 87-90,80-81 IC101 Pickup...
  • Page 74 (21) RTZ TimeOut Fail IC101 Slider/ Slider FPC Driver Spindle Slider:#6,8-10 IC601 Spindle FFC (22) Focus Servo/Tracking Servo Fail All Disc Pin# Setting 87-90 IC101 FE:R102,C405 Pickup MPU & DSP IC301 TE:R101,C101 Focus:#34-35 Tracking:#30-31 PE:R103,C406 R329,C335 Slider FPC Driver Slider:#6,8-10 IC601 R330, C336...
  • Page 75 Detail Error Code & Fail Analysis 1. Laser Power Initial Adjust Error Code Contents of fail Fail Analysis Block Diagram SSB Byte8,9 28xx LP Adjust NG. 1) Check Pickup FFC Connection. No.01 (Exchange 2) Check solder of IC101circumference. low/high byte) (pin#6, 10, 12, L150, L151) 3) Check solder of IC102.
  • Page 76 2. Adjusting Error during Disc Load Sequence (Lead in Error) No. Error Code Contents of fail Fail Analysis Block Diagram SSB Byte21,22 42xx Circuit Offset Adjust NG. 1) Check Pickup FFC Connection. No.04 2) Check solder of IC101circumference . (pin#,1,2,3 pin#87-90, FE_Servo: R102, C405 TE_Servo: R101, C101 PE_Servo: R103, C406)
  • Page 77 No. Error Code Contents of fail Fail Analysis Block Diagram SSB Byte21,22 4Axx Focus Offset Adjust NG. 4A08: Disc Unmatch(Exchange Disc). No.10 (DVD-ROM,CD-R/RW) 1) Check Pickup FFC Connection. 2) Exchange Pickup. 3) Exchange IC301(MPU & DSP). 4A5x Focus Offset Adjust NG. 1) RAM Disc NG (Exchange RAM Disc) No.11 4A6x...
  • Page 78 No. Error Code Contents of fail Fail Analysis Block Diagram SSB Byte21,22 54xx DPP Amp Adjust NG. 1) Check Pickup FFC Connection. No.07 (CD Disc Only) 2) Exchange Pickup. 3) Check solder of IC101circumference. (pin#1,2,3 pin#87-90, TE_Servo: R101, C101) 4) Exchange IC101(AFE). 5) Exchange IC301(MPU &...
  • Page 79 No. Error Code Contents of fail Fail Analysis Block Diagram SSB Byte21,22 5Cxx Signal Amp Error. 1) Check Pickup FFC Connection. No.06 2) Exchange Pickup. 3) Check solder of IC101 circumference. (pin#1,2,3 pin#87-90, PE_Servo: R103, C406) 4) Exchange IC101(AFE). 5) Exchange IC301(MPU & DSP). 5Dxx Focus Offset Adjust NG.
  • Page 80 JR7 Power Supply System Diagram * Ver1.0 It created based on the PLT circuit diagram. L601 Poly SW DRV IC601 R2S30202FP 12V in SW701 VM1 #22 Motor power supply 1(Spindle) VM2 #05 Motor power supply 2(Slide) miniSMDC150F/24 S705 OPEN (OPEN) CN101 P/U (LDD) Vso5V #29 S704 OPEN L151...
  • Page 81 PCB Poor Analysis - Check list Circuit/IC Signal Signal/Level mesurement-point (IC-pin or Device) Power supply Line-12V CN801-41 Line-5V CN801-44 (IC715) reg-1.5V 1.5V IC701-2 reg-2.8V 2.8V IC703-5 (IC703) reg-3.3V 3.3V IC703-2 Flash-ROM VDD : 3.3V 3.3V (IC302) Active-Low read-CK VDD : 1.5V 1.5V 41, 28, 72, 130, 146, 159, 189, 193, 197 (IC301)
  • Page 82 HW Self- Diagnostic function 1. Self-Diagnostic Function by LED Blink. • Basic operation: At JR7, MPU is included in DSP, MPU accesses each peripheral (inside, exterior) device, and discover a defect by the ability of a read/write of data to be performed correctly. Since MPU operates by the program with a built-in Flash-ROM, when abnormalities are in MPU, Flash-ROM, and these Data-Bus &...
  • Page 83 2. LED does not blink at all at the time of a power supply injection. Eject-SW does not react. (1) Is it normal to the exterior Bus (Data-Bus, Address-Bus, control signal system) of MPU? Viewing — check: -- a short circuit, opening, etc. •...
  • Page 84 3. Motor, Abnormalities in Actuator System The drive circuit of a motor & actuator consists of the three ICs IC601(R2S30202FP). The work of each IC is as follows. (1) IC601(R2S30202FP) : 7ch driver Spindle motor driver: 180° audio drive Type, an analog input, a PWM drive, a Vm=12V. Stepping motor driver X2: analog input, a PWM drive (differential), a Vm=12V Loading motor driver: Input/Output PWM drive, Vm=5V.

  • Page 85: Block Diagram

    BLOCK DIAGRAM Flash-ROM (2MByte) SST39VF601 OPU:HOP-7642TS or Equivalent (HITACHI ME) (FUJITSU) Disc Interface Loading motor connector Analog Front End DVD/CD DSP Analog R2S35004 (DVD/CD/Servo/ATAPI) audio Disc R8J32018FP 100pin-TQTF Slide motor 256pin LQFP motor (RENESAS) Unit (RENESAS) mechanism DVD-codec Host IDE CD-codec LPP/ADIP decorder 7ch-Driver...
