Cordless auto-loading screwdriver

Advertisement

Quick Links

CORDLESS
AUTO-LOADING
SCREWDRIVER
3.6V Lithium Ion
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage:
3.6V
Driver Bit Size:
6.35mm (1/4")
No Load Speed:
180/min
Max. Torque:
4Nm
Battery:
1.5Ah Li-ion (Integrated)
Charge Time:
3-5 Hours
Weight (tool only):
484g
ozito.com.au
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO
Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
WARRANTY
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from the
original date of purchase and is intended for DIY (Do It Yourself)
use only. If a product is defective it will be replaced in accordance
with the terms of this warranty. Lithium Ion batteries are covered
by a 12 month warranty. Warranty excludes consumable parts, for
example: driver bits, etc.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
WHAT'S IN THE BOX
Cordless Screwdriver
Pre-Loaded Driver
Bits x 10
Charging Adaptor
Kit Bag
SDA-2100
0816

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDA-2100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ozito SDA-2100

  • Page 1 3-5 Hours Weight (tool only): 484g ozito.com.au Kit Bag SDA-2100 WARRANTY IN ORDER TO MAKE A CLAIM UNDER THIS The benefits provided under this warranty are in addition to other rights and remedies which are available to you at law.
  • Page 2: Know Your Product

    KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS SCREWDRIVER 1. CHARGING 1 Bit Holder 6 Forward / Reverse Button 2 LED Worklight 7 Charge Indicator LED WARNING! THE TOOLS CHARGER IS RECOMMENDED 3 Bit View Window 8 Charging Socket FOR USE WITH A RESIDUAL CURRENT DEVICE WITH 4 Bit Cartridge 9 Loading Switch A RATED RESIDUAL CURRENT OF 30MA OR LESS.
  • Page 3 2. LOADING A DRIVER BIT 3. CHANGING CARTRIDGE BITS Selecting and Loading Driver Bits Selecting and Loading Driver Bits The pre-loaded driver bits can be removed from the cartridge and 1 Rotate the cartridge until the replaced with a different driver bit if desired. required driver bit can be seen through the view window.
  • Page 4: Operation

    Do not force the screwdriver charge of the integrated battery. or apply side pressure to elongate the hole. Let the tool do the work. Low State of Charge (Battery Requires Charging) Mid State of Charge Full State of Charge SDA-2100...
  • Page 5: Maintenance

    Blow out the ventilation slots with compressed air periodically . necting the charger. Note: Ozito Industries will not be responsible for any damage or Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or stress.
  • Page 6: Electrical Safety

    Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock.
