CORDLESS
SCREWDRIVER
3.6V Lithium Ion
INSTRUCTION MANUAL

SPECIFICATIONS

Voltage:
3.6V
Bit Holder Size:
6.35mm (1/4")
No Load Speed:
180/min
Max Torque:
3.5Nm
Battery:
1.3Ah Li-ion
Charge Time:
3-5 Hours
Weight (tool only):
0.34kg
ozito.com.au
WHAT'S IN THE BOX
Cordless Screwdriver
Driver Bits x 29
Charging Cable
SDU-5100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDU-5100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ozito SDU-5100

  • Page 1 Cordless Screwdriver 3.6V Lithium Ion INSTRUCTION MANUAL SPECIFICATIONS Driver Bits x 29 Voltage: 3.6V Bit Holder Size: 6.35mm (1/4”) No Load Speed: 180/min Max Torque: 3.5Nm Battery: 1.3Ah Li-ion Charge Time: 3-5 Hours Weight (tool only): 0.34kg ozito.com.au Charging Cable SDU-5100...
  • Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS SCREWDRIVER 1. CHARGING 1 Bit Holder 4 On/off Trigger 2 LED Worklight 5 Charge Indicator 3 Forward/ Reverse Lever 6 Charging Point WARNING! THE POWER SUPPLY FOR THIS CHARGER SHOULD BE PROTECTED BY A RESIDUAL CURRENT DEVICE (RATED AT 30MA OR LESS).
  • Page 3 2. CHANGING DRIVER BITS 3. CONTROLS Installing CRV Drive Bits On/off Trigger 1. To start drilling squeeze 1. Insert the CRV bit directly into the magnetic bit holder. the on/off trigger. 2. To stop drilling release the trigger. 2. Pull gently on the CRV bit to ensure it is properly secured. Forward/ Reverse Lever 1.
  • Page 4 2. Hold the screwdriver firmly and place the bit on the screw to be fastened. 3. Squeeze the on/off trigger to start the screwdriver. 4. Fasten the screw into the workpiece. Note: Do not force the screwdriver or apply side pressure to elongate the hole. Let the screwdriver do the work. SDU-5100...
  • Page 5 Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or stress. Note: Ozito Industries will not be responsible for any damage or Do not operate the tool if it has received a sharp blow, been dropped or otherwise damaged in any way.
  • Page 6 Model No. SDU-5100 How To Order Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you have any further questions, please contact Ozito Customer Service on: Australia: 1800 069 486 New Zealand: 0508 069 486...
  • Page 7 GENERAL POWER TOOL SAFETY WARNINGS - PERSONAL SAFETY WARNING! Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves Read all safety warnings and all instructions. Failure to follow the warnings and away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. instructions may result in electric shock, fire and/or serious injury.
  • Page 8 • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO 0415 Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
