- Page 1 WHAT’S IN THE BOX POWER SCREWDRIVER Screwdriver 6.35mm 500W INSTRUCTION MANUAL SPECIFICATIONS Input: 230-240V ~50Hz Motor: 500W Collet Size: 6.35mm (1/4”) No Load Speed: 0-2200/min Weight: 1.9kg ozito.com.au SCD-7000...
-
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION POWER SCREWDRIVER 1. INSERTING BITS 1 6.35mm (1/4”) Chuck 5 Lock-On Button 2 Torque Collar 6 Sure Grip Handle 3 Chuck Tightening Collar 7 Speed Selection Dial WARNING: ENSURE THE TOOL IS SWITCHED OFF AND DISCONNECTED FROM THE POWER SUPPLPY BEFORE 4 Forward Reverse Lever 8 Variable Speed Switch... -
Page 3: Operation
OPERATION 2. CONTROLS Lock-On Button WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK THE USE OF A RESIDUAL CURRENT DEVICE (RATED AT 30mA 1 Squeeze and hold the switch. OR LESS) IS RECOMMENDED. Variable Speed Switch 1 To start drilling squeeze the on/off trigger. - Page 4 5 Move the screwdriver towards the workpiece as the screw goes in. 3. Repeat until you reach the correct setting/ screw depth. Use this torque setting for the remaining screws. Note: Do not force the screwdriver or apply side pressure to elongate the hole. Let the tool do the work. SCD-7000...
-
Page 5: Maintenance
Always replace both carbon brushes at the same time. Note: Ozito Industries will not be responsible for The screwdriver bit cannot be removed any damage or injuries caused by the repair of Remove the torque collar by rotating anti-clockwise until it comes off. -
Page 6: Electrical Safety
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. The power supply for this product should be protected by a residual current device (rated at 30ma or less). A residual current device reduces the risk of electric shock. -
Page 7: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO 0814 Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
