TuffStuff CXT-200 Owner's Manual page 35

Safety Precautions (For CXT-225 option)
CXT-200 Corner Multi-Funtional Trainer
4. DANGER: Once the unit is completely assembled take the time to ensure
that the unit is assembled correctly square and perpendicular. Pay special
attention to the Weight Lift Bar (#8) making sure both hooks engage uniformly
and completely into each Stopper Prong (#6). If both of the Weight Lift Bar
Hooks are not engaging uniformly into the Stopper Prongs (#6), it will be
necessary to loosen so m
r t - e g i t h n e t e h hardware. If problem persists, Do Not Use the Machine
and contact your TuffStuff Retailer or Customer Service (888) 884-8275.
Disengaged Press Bar
5. The illustrations above depict the Weight Lift Bar (#8) disengaged setting
which is used during exercise.
o L k c n i g
1
6. DANGER: The Safety Stoppers (#2, #3) prevent the Weight Lift Bar (#8)
from being lowered below required point and avoid getting crushed under the
Weight Lift Bar (#8) if the weight is too heavy to control. Use the Decal
numbers on the Side Frames (#4, #5) to ensure that the Safety Stoppers
(#2, #3) are set to an equal adjustment setting (same height).
Before you add weight plates to the Weight Lift Bar (#8), you must fi rst
set-up the Safety Stoppers (#2, #3) for the required exercise. It is
recommended that you test the desired setting without weight plates on the
Weight Lift Bar (#8) to make sure the Safety Stoppers (#2, #3) are set to the
appropriate exercise setting.
Press Bar
Fully Engaged
WRONG
WRONG
f e a r m e a h d r w a e r h t n e r - e i l a
During Exercise
U
2
www.tuffstuffitness.com
n g t e h f a r m e a d n
n o l k c n i g
2
1
