- Page 1 HPSB 1348B v.1.0 HPSB 54V/1,3A/4x7Ah Buffer switch power supply unit. EN** Edition: 1 from 18.03.2016 Supercedes the edition: ------------...
-
Page 2: Green Power
4x7Ah/12V battery. A micro switch indicates door opening (front cover). The power supply housing has space for additional modules (fuse blocks, voltage regulators and DC-DC converters). Optional power supply configurations are available at the website: www.pulsar.pl Refer to chart 1... - Page 3 GREEN POWER www.pulsar.pl HPSB1348B 1.2 Block diagram (fig.1) Fig.1. The block diagram of the PSU. 1.3 Description of PSU components and connectors. Table 1. Elements of the PSU. Element no. Description [Fig. 2] PSU module Connectors PSU: L-N power supply connector 230V AC,...
- Page 4 GREEN POWER www.pulsar.pl HPSB1348B Fig.2. The view of the PSU. 1.4 Specifications: - electrical parameters (tab.2) - mechanical parameters (tab.3) - operation safety (tab.4) - operating parameters (tab.5) Table 2. Electrical parameters PSU type A (EPS - External Power Source) 176÷264V AC 50Hz...
- Page 5 GREEN POWER www.pulsar.pl HPSB1348B Table 3. Mechanical parameters Enclosure dimensions 400 x 350 x 90+8 [mm] (WxHxD) Fixation see figure 2 Fitting battery 4x7Ah/12V (SLA) max. 395x160x85mm (WxHxD) max Net/gross weight 3,20/ 3,50 kg Enclosure Steel plate DC01, thickness: 1,0mm, colour: RAL 9003...
-
Page 6: Green Led
GREEN POWER www.pulsar.pl HPSB1348B 2. Installation. 2.1 Requirements. The buffer PSU shall be mounted by a qualified installer with appropriate permissions and qualifications for 230V/AC installations and low-voltage installations (required and necessary for a given country). The device shall be mounted in confined spaces, according to the environment class II, with normal air humidity (RH=90% max. - Page 7 GREEN POWER www.pulsar.pl HPSB1348B 4. Operation and use. 4.1 Overload or short circuit of the PSU output (SCP on) In case of overload, the output voltage is automatically shut off, and so is the LED indicator. The restoration of the voltage takes place immediately after the failure (overload) is over.
-
Page 8: General Warranty Conditions
GENERAL WARRANTY CONDITIONS 1. Pulsar (the manufacturer) grants a two-years warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects,...
