- Page 1 SP-5002IZ 1x2 HDMI 2.0a Splitter with Built-in & User Adjustable EDID Management User Manual rev: 171121 Made in Taiwan...
-
Page 2: Table Of Contents
However, like all electronic equipments, the SP-5002IZ should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
With built-in USB firmware update mechanism, the compatibility among countless HDMI sources and receivers can be further guaranteed. With the upmost HDR/4K2K@60 4:4:4 8bits and high definition audio support, SP-5002IZ is suitable for high quality HDMI broadcasting, digital signage and education applications! FEATURES ●... -
Page 4: Specifications
SPECIFICATIONS Model Name SP-5002IZ Technical Role of usage 1x2 Distribution Amplifier (Splitter) HDMI compliance HDMI 2.0a HDCP compliance HDCP 2.2 / 1.4 Video bandwidth Single-link 600MHz [18Gbps] Video support HDR 4K2K@60 (4:2:0 10bits) / 4K2K@60 (4:4:4 8bits) DTS-HD Master Audio, Dolby TrueHD Dolby Digital,... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS 1. EDID MODE: See more detail in the DIP SWITCH SETTING section 2. Mini-USB: For technical support only [firmware update] 3. Power LED: Lights on when device is ready 4. Signal LED: Input signal LED indicator 5. Signal LED: Output 1-2 signal LED indicator 6. -
Page 6: Dip Switch Setting
DIP SWITCH SETTING DIP Switch Position Description Pin 2 Pin 3 Pin 4 Off [] Off [] Off [] Ultra HD(4K2K@60) – 8/10/12bit 3D HDR video & 7.1ch audio On [ ] Off [] Off [] Ultra HD(4K2K@60) – 8/10/12bit 3D HDR video & 2ch audio Ultra HD(4K2K@30)(4K2K@60 420) –... -
Page 7: Connection Diagram
CONNECTION DIAGRAM... -
Page 8: Notice
NOTICE 1. If somehow user cannot get video output, please try to adjust EDID dip switch to “[pin2,pin3,pin4]=[↓- ↑-↓]” or “[pin2,pin3,pin4]=[↑-↓-↓]” for trouble shooting. Under “[pin2,pin3,pin4]=[↓-↑-↓]”, there will be video output. The only requirement is that the display has to support at least Full HD. If default Full-HD EDID still cannot work, user can switch to “[pin2,pin3,pin4]=[↑-↓-↓]”... -
Page 9: Warranty
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the SP-5002IZ features and specifications is subject to change without further notice.
