- Page 1 1x2 HDMI Splitter over Cat.X with HDBaseT-Lite, 4K2K, IR & RS-232 User Manual rev: 140806 Made in Taiwan...
- Page 2 fety Noti The SP-50 has been 1x2 H DMI Splitte er over Ca t.X with HD DBaseT-Lit te, 4K2K, I R & RS-23 tested for conforman nce to saf fety regulat tions and requiremen nts, and h has been c certified fo internationa al use.
- Page 3 Cat-5/5e/6 cables with HDMI over CAT.X receivers. For convenience, SP-5012V is also equipped a local HDMI output for monitoring. With the built in equalization, the input HDMI cable can be extended up to 20 meters (66 feet) long under Full HD, and make the overall transmission distance superior than regular HDMI splitters or matrix switches in the market.
- Page 4 SPECIFICATIONS Model Name SP-5012V Technical Role of usage 1x2 Distribution Amplifier Transmitter [TX] HDMI compliance HDMI Deep Color, full 3D & 4K2K@30 HDCP compliance Video bandwidth Single-link 340MHz [10.2Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 up to 36-bit color Transmission over 1080p@60 60m (198ft) [CAT.X]...
- Page 5 PANEL DESCRIPTIONS Front Panel Power LED: Lights on when power is on RS-232 IR blaster IR receiver Rear Panel Dip Switch: FW update HDMI IN: 8- rotation :EDID mode HDMI OUT & Stereo audio out HDBaseT Signal OUT: Link LED: +5V DC: *EDID Mode: EDID 0: 1080P multi-channel audio...
- Page 6 NOTICE 1. If the DVI or HDMI device requires the EDID information, please use EDID Reader/Writer to retrieve and provide DVI or HDMI display EDID information. 2. All HDMI over Cat.X transmission distances are measured using Belden 1583A CAT5e 125MHz UTP cable and ASTRODESIGN Video Signal Generator VG-859C &...
- Page 7 SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the SP-5012V features and specifications is subject to change without further notice.
