Gomax SP-5004PZ User Manual

1x4 hdmi 2.0a splitter with edid management
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SP-5004PZ
1x4 HDMI 2.0a Splitter with EDID
Management
User Manual
rev: 150918
Made in Taiwan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP-5004PZ and is the answer not in the manual?

Questions and answers

Related Manuals for Gomax SP-5004PZ

Summary of Contents for Gomax SP-5004PZ

  • Page 1 SP-5004PZ 1x4 HDMI 2.0a Splitter with EDID Management User Manual rev: 150918 Made in Taiwan...

  • Page 2: Table Of Contents

    However, like all electronic equipments, the SP-5004PZ should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.

  • Page 3: Introduction

    HDMI splitter solution on the market, by which the high definition video and high quality audio can be transmitted to 4 different locations without losing quality. SP-5004PZ supports all 3D formats and the true 4K2K video! With built-in USB firmware update mechanism, the compatibility among countless HDMI sources and receivers can be further guaranteed.

  • Page 4: Specifications

    SPECIFICATIONS Model Name SP-5004PZ Technical Role of usage 1x4 Distribution Amplifier (Splitter) HDMI compliance HDMI 2.0a DVI compliance DVI 1.0 HDCP compliance HDCP 2.2 Video bandwidth Single-link 600MHz [18Gbps] Video support HDR 4K2K@60 (4:2:0 10bits) / 4K2K@60 (4:4:4 8bits) DTS-HD Master Audio, Dolby TrueHD Dolby Digital,...

  • Page 5: Panel Descriptions

    PANEL DESCRIPTIONS 1. Signal LED: Signal LED indicator 2. Power LED: Lights on when device is ready 3. HDMI IN: Connect to a HDMI input source 4. HDMI OUT1-4: HDMI outputs to HDMI displays [HDMI OUT1: EDID Learn Default] 5. Mini-USB: For technical support only [firmware update] 6.

  • Page 6: Hardware Installation

    HARDWARE INSTALLATION Broadcasts HDMI signal to 4 HDMI displays! 1. Switch off all devices, including monitors. 2. Connect to the displays. 3. Connect an HDMI source (such as a Blu-ray Disc player) to the HDMI In. 4. Make sure the rotary switch is NOT at “MODE 0” 5.

  • Page 7: Notice

    NOTICE 1. While connecting a new monitor to the splitter under mode D (auto EDID) & mode E and F (EDID learning), experiencing a short period of time without displaying might be expected. The splitter will do Automatic EDID learning which analyzes the newly connected monitor to see if the EDID for the HDMI input is necessary to update! 2.

  • Page 8: Warranty

    SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the SP-5004PZ features and specifications is subject to change without further notice.
