4.3: FX RETURN
CONSOLE ROUTING > FX RETURN
Stereo FX Return Channel
(Notepad 12FX only)
The FX Return channel is usually
used for return of effects pro-
cessing from the built-in Lexicon
effects. Alternatively this channel
takes a return from an external
effects processor into the TRS
jacks. When jacks are plugged
into the External FX sockets, the
routing from the built-in Lexicon
effects is disconnected.
The FX Return channel can not
contribute to the Aux/FX busses
(as this would cause a positive
feedback loop.)
There is no trim or EQ on this
channel.
The output of this channel feeds
the Master fader.

4.3: FX RETURN ROUTING
