NOTEPAD
CONSOLE ROUTING > STEREO INPUT
Stereo Line sources
STEREO INPUT LINE
TRS left and right
5
L
inputs can also be used
as a mono input with a
LINE
single jack in the left
6
socket
R
TRIM
Increase / decrease the
signal level
–20
LEVEL ROTARY
Level control to
mix the source.
∞
- +10dB
BALANCE
Adjust the left /
right mix levels
L R
AUX/FX AUX/FX AUX/FX
5, 8FX, 12FX User Manual
+20dB
To USB audio routing
Pre-fade aux send
AUX/FX
Send an independent
0 0
signal level to the
e ects module and
aux bus
∞
-
To master
level control
AUX/FX AUX/FX
AUX/FX AUX/FX AUX/FX
–
LINE
5
L
LINE
6
R
TRIM
To aux master
-20 +20dB
control and
e ects
0
+10dB
NOTEPAD-12FX NOTEPAD-12FX
AUX/FX MASTER
AUX/FX AUX/FX
∞
-
+10dB
BAL
L R
LEVEL
∞
-
+10dB

4.2: STEREO INPUT ROUTING

4.2: STEREO INPUT
Stereo TRS Input
Channels
Stereo TRS channels
have two TRS input
jacks and have the same
routing options as mono
input channels.
Aux bus contributions
from stereo channels
are stereo such that
when the Aux output is
in headphone mode, a
stereo mix is heard.
These stereo channels
have trim controls.
Stereo RCA/USB Input
Channel
The Stereo RCA/USB
input channel is a stereo
sum of the RCA inputs
and USB channels 1
and 2. It is usually used
as a playback channel
and works for conven-
ient 2-track playback
functionality from unbal-
AUX/FX
0
anced consumer audio
players into the RCA
jacks, or from computer,
tablet, or phone connec-
tions to the USB jack.
There is no trim or EQ
0
on this channel.
Stereo FX Return
Channel (Notepad
12FX only)
(See next section: FX
Return)
4 x 4 USB 4x4 USB
