LG RC8001B Use And Care Manual page 16

C
aring for your dryer
Condenser
Condenser is also a very important part for efficient drying performance result so it needs a special care from you.
It is recommended that condenser be cleaned three or four times a year.
1. Open condensing cover by using a coin or flat
blade screwdriver.
2. Open sealing cover by turning
a locking lever.
Sealing cover
3. Release the both locking levers turning
towards each other.
16
4. Draw the condenser out by inserting a finger
into a hole down the front of condenser.
(Don't forcefully treat condenser.)
5. Clean the condenser completely under the
tap letting water to flow through.
6. Close all with the reverse order of opening.
CAUTION
- Operating when the heat exchanger is
clogged with lint can damage the dryer.
This also increases energy consumption.
- Do not use sharp objects to clean the heat
exchanger. You could damage it an cause
leaks.
- Never operate the dryer without the heat
exchanger.
< Front >
< Side >
