LG RC7055*H Series Owner's Manual

Hide thumbs

Advertisement

Quick Links

SEC.
WORK
88
<BACK>
154
3
2
인쇄내용 변경
EAGH700560
1
인쇄내용 변경
EAGH700061
REV. NO.
REVISION DESCRIPTION
REF. NO.
기호
변경 사항
시방 번호
PRINTING DEGREE
LG MODEL 명.
EXTERIER
1
RC*055*H*M
<FRONT>
154
17.07.18
문성철
정영석
17.07.04
문성철
정영석
DATE
PREPARED
APPROVED
년/월/일
시방자
승인자
MATERIAL AND PRINTING DESCRIPTION
LANGUAGE
INTERIER
1
모조지 80g OFFSET 인쇄
English
<< 주기 >>
1. 재질, 인쇄방법, 인쇄도수, 외곽치수등은 작업표에 준한다.
2. 인쇄내용, 문자크기 및 형상, 선의 굵기 등은 설계에서 제시된 FILM에 준함.
3. 외곽치수는 절단후 치수임.
4. 양산전에 설계 한도를 득할 것.
5. 본 부품에 금지물질이 포함되지 않도록 하고,
상세 내용은 LG(63)-A-5501-34를 만족할 것.
<< NOTES >>
1. Material, printing and exterier size are refer to work tables.
2. Printing, text size and line are based on LG design film.
3. Exterier size on the drawing is cutting line.
4. Before product controlled by criteria sample.
5. The part should not contain prohibited substances(Pb,Cd,Hg,Cr+6,PBB,PBDE)
and details should comply with LG standard of LG(63)-A-5501-34.
TRIG.
MODELING
DESIGNED
박 은 진
17.05.29
LG 전자
LG Electronics Inc.
PAGE
REMARK
-
SCALE 1
MANUAL,OWNER'S
UNIT
mm
1
T
REVIEWED
CHECKED APPROVED
I
T
윤 혜 진
정 영 석
L
E
17.05.29
17.05.29
RELATED DWG.
MFL68721088
(주)
DWG.
No.
RELEASING THIS DRAWING
WITHOUT PERMISSION LG
Electronics SHOULD BE
ACCUSED ACCORDING TO THE
LAWS AND COMPANY RULES.
이 도면은 LG전자의 자산으로 불법
유출시 관계법과 회사규정에 의해 처벌됨.
DR COMPLETED
PDF
도면 DR 완료
ILLUSTRATOR
완료일 :
1/1
CI Eco Jupiter(D) Wifi

Advertisement

loading

  Related Manuals for LG RC7055*H Series

  Summary of Contents for LG RC7055*H Series

  • Page 1 << NOTES >> 1. Material, printing and exterier size are refer to work tables. 2. Printing, text size and line are based on LG design film. 3. Exterier size on the drawing is cutting line. 4. Before product controlled by criteria sample.
  • Page 2 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. RC7055*H** RC8055*H** www.lg.com MFL68721088 Copyright © 2017 LG Electronics Inc. All Rights Reserved. Rev.02_071717...
  • Page 3: Table Of Contents

    Programme Table ..................19 Option Programme ................... 21 Rack Dry (Optional) .................. 23 SMART FUNCTIONS .............24 Using LG SmartThinQ Application ............24 Using Smart Diagnosis™ ................. 27 MAINTENANCE ..............28 Cleaning the Lint Filter ................28 Emptying the Water Container..............29 Cleaning the Cool Air Inlet Grill ..............
  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk.
  • Page 5 For use in Europe: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 6 •This appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the appliance, in such a way that a full opening of the appliance door is restricted. •This appliance must be grounded.
  • Page 7 Improper use can cause fire or explosion. •In case of flood, disconnect the power plug and contact the LG Electronics customer information centre. •Do not push down the door excessively, when the appliance door is open.
  • Page 8 •If the drain hose or inlet hose is frozen during winter, use it only after thawing. •Keep all washing detergents, softener and bleach away from children. •Do not touch the power plug or the appliance controls with wet hands. •Do not bend the power cable excessively or place a heavy object on it.
  • Page 9 Technical Safety for Using the Dryer •Do not dry unwashed items in the appliance. •Fabric softeners, or similar products, should be used as specified by the fabric softener instructions. •Remove all objects from pockets such as lighters and matches. •Never stop the appliance before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated.
  • Page 10: Disposal Of Your Old Appliance

    WEEE collection point. For the most up to date information for your country please see www.lg.com/global/recycling. •This dryer contains fluorinated greenhouse gases. R134a (GWP: 1430): 0.390 kg / 0.558 t CO2-eq. Hermetically...
  • Page 11: Installation

    7 kg 8 kg • Appearance and specifications may vary without notice to improve the quality of the appliance. Accessories (Optional) Please contact the LG Electronics Customer Information Centre for purchase. Condensing Drain Hose Dry Rack Stacking Kit and Hose Holder...
  • Page 12: Installation Place Requirements

    Installation Place Positioning Requirements • Install the appliance on a flat hard floor. • Make sure that air circulation around the Location appliance is not impeded by carpets, rugs, etc. • Never try to correct any unevenness in the floor with pieces of wood, cardboard or similar materials under the appliance.
  • Page 13: Stacking Installation Instructions

    • Do not use an extension cord or double Stacking Kit adapter. • Always unplug the appliance after use. In order to stack this dryer an LG stacking kit is required. • Connect the appliance to an earthed socket in accordance with current wiring regulations.
  • Page 14: Installation Procedure

    Installation Procedure WARNING • Incorrect installation can cause serious Place the LG dryer on the LG washing accidents. machine. • The weight of the appliance and the height of installation make the stacking procedure too risky for one person. This procedure should...
  • Page 15 Condensed Water Drain-out Leveling the appliance Normally, condensed water is pumped up to the Leveling the appliance prevents unnecessary water container where water is collected until noise and vibration. Place the appliance on a manually emptied. Water can also be drained solid, level floor.
  • Page 16: Operation

    OPERATION Using the Appliance CAUTION • Be careful not to trap laundry between the Before the first cycle, set the appliance to dry door and rubber seal. for five minutes to warm up the drum. Open the door between loads the first few times you use Turn the power on.
  • Page 17: Sorting Laundry

    Rubber and Plastics CAUTION • Do not dry any items made from or containing • Be careful! The drum inside may still be hot. rubber or plastics such as: • The appliance must not be used for purposes − Aprons, Bibs and Chair Covers other than those for which it was designed.
  • Page 18: Control Panel

    Control Panel RC7055*H** RC8055*H**...
  • Page 19 Display Power Button : This icon indicates that the lint filter • • Press the Power button to turn power on should be cleaned or is clogged. and off. − Cleaning notice: When you press the Power • Press the Power button to cancel the button, the icon will become displayed.
  • Page 20: Programme Table

    Programme Table Drying Programme Sensor Dry Programmes Programme Laundry Type Detail Drying Capacity Level 7 kg 8 kg Towels, dressing For thick and quilted Extra 7 kg 8 kg gowns and bed linen fabrics Terry towels, tea For thick and quilted towels, towels and bed fabrics that do not Very...
  • Page 21 Sensor Dry Programmes Programme Laundry Type Detail Drying Capacity Level 7 kg 8 kg Sports Soccer kit and training For polyester material 2 kg 2 kg Wear wear For fabrics that are Silk, fine fabrics and Delicate heat-sensitive, such as 1.5 kg 1.5 kg lingerie...
  • Page 22: Option Programme

    Option Programme Drum Light Whilst the appliance is running it is possible to Time Delay see inside the drum if you select the Drum Light function. You can use the Time Delay option to delay the finishing time of the drying cycle. Maximum •...
  • Page 23: Child Lock

    Damp Dry Beep Child Lock With this option, the appliance will beep when Use this option to disable the controls. This the load is ready for ironing. feature can prevent children from changing This allows you to remove faster-drying cycles or operating the appliance. lightweight items or items that you would like to iron or hang while still slightly damp.
  • Page 24: Rack Dry (Optional)

    Rack Dry (Optional) Close the door. The dryer rack is placed inside the appliance, as in the picture below. Remove and discard Turn power on and select Rack Dry. packing material before use. The Rack Dry is designed for use with laundry Press the Start/Pause button.
  • Page 25: Smart Functions

    • For appliances with the logo manual. Check the distance between the appliance • LG SmartThinQ is not responsible for any and the wireless router (Wi-Fi network). network connection problems or any faults, • If the distance between the appliance and...
  • Page 26 NOTE Smart Diagnosis™ • Once the Remote Start mode is enabled, you can start a cycle from the LG SmartThinQ This function provides useful information for smartphone application. If the cycle is not diagnosing and solving issues with the started, the machine will wait to start the cycle appliance based on the pattern of use.
  • Page 27 Wireless function S/W version : V 1.0 LG Electronics will also provide open source For consideration of the user, this device should code to you on CD-ROM for a charge covering...
  • Page 28: Using Smart Diagnosis

    Use this function if you need an accurate • If the call centre agent is not able to get diagnosis by an LG Electronics customer an accurate recording of the data, you information centre when the appliance may be asked to try again.
  • Page 29: Maintenance

    MAINTENANCE WARNING • Open the second lint filter. • Remove the power plug when you clean the appliance. Not removing the plug may result in electric shock. Cleaning the Lint Filter Clean the lint filter before each drying cycle. It should also be cleaned if the icon becomes illuminated and the buzzer sounds while the...
  • Page 30: Emptying The Water Container

    Emptying the Water Container Cleaning the Cool Air Inlet Grill Condensed water is collected in the water container. Vacuum the Cool Air Inlet grill 3 – 4 times a Empty the water container after every use. Not year to make sure there is no build up of lint or doing so will affect the drying performance.
  • Page 31: Troubleshooting

    TROUBLESHOOTING The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the appliance does not function properly or does not function at all, check the following before you call for service: Diagnosing Problems Symptoms Reason...
  • Page 32 Symptoms Reason Solution • Reset circuit breaker or replace fuse. House fuse is blown, circuit Do not increase fuse capacity. If the breaker has tripped, or power problem is a circuit overload, have it outage has occurred. corrected by a qualified electrician. •...
  • Page 33 Symptoms Reason Solution • Over drying a load of laundry can lead Clothes have dried too long to wrinkled clothes. Try a shorter (overdried). drying time. Clothes are wrinkled. Clothes have been left in the appliance for too long after •...
  • Page 34 If water leaks continuously, is caught in the door. contact the LG Electronics Customer Information Centre. • If items are too tightly packed or too sparse the sensor may have trouble reading the dryness level of the load.
  • Page 35: Error Codes

    Error Codes Symptoms Reason Solution • Turn off the appliance and call Error code: tE1 through tE7 Temperature sensor failure. for service. The door has been opened while the appliance is in • Close the door completely. operation or the appliance is •...
  • Page 36: Warranty

    • Costs associated with removal of your Product from your home for repairs. • The removal and reinstallation of the Product if it is installed in an inaccessible location or is not installed in accordance with published installation instructions, including LG’s owner’s and installation manuals.
  • Page 37: Operating Data

    OPERATING DATA Product fiche_commission Delegated Regulation(EU) No 392/2012 Supplier’s name or trade mark LG Electronics Supplier’s model identifier RC7055*H** RC8055*H** Rated capacity in kg of cotton laundry for the standard cotton 7 kg 8 kg programme at full load Condenser Household...
  • Page 38 Memo...
  • Page 39 Memo...
  • Page 40 Memo...
