LG RC8003C Use And Care Manual

Condensing dryer
Hide thumbs


Quick Links

Use and Care manual
Condensing Dryer
Please read this manual carefully prior to use.
Keep it for future reference.
Write down model name and serial number of your product.
Have all these details ready when you call for service.



  Summary of Contents for LG RC8003C

  • Page 1 Use and Care manual Condensing Dryer RC8003A RC8003B RC8003C RC8003D Please read this manual carefully prior to use. Keep it for future reference. Write down model name and serial number of your product. Have all these details ready when you call for service.
  • Page 2: Table Of Contents

    Energy save ontents Ultra big Capacity Drum LG Dryer has 8.0kg capacity which is the ultra big capacity. Lower Energy Consumption Energy is saved by cutting-edge engineering design of drying system and by optimized heating control. It’s a real money saving.
  • Page 3: Safety Instructions

    afety instructions To help reduce any risk of electric shock, fire, or other personal or property injury when using your dryer, please follow basic safety instructions. WARNING Serious injury or death may occur when not observing the following rules. Not allowed actions. •...
  • Page 4 afety instructions • Do not use damaged power cord, plug and socket. It may cause a fire or an electric shock. • Do not install or store the dryer where it will be exposed to the weather. It may cause an electric shock, a fire, malfunction or deformation.
  • Page 5 afety instructions • Young children should be supervised to ensure that they do not play with the appliance. Children may fall off. Pets or children may be wounded by rotating parts or suffocated inside drum. • If this appliance is supplied from a cord extension set or an electrical connector, portable outlet device must be positioned so that it is not subject to splashing or ingress of moisture.
  • Page 6: Installation Instructions

    Stacking installation instructions The LG Dryer can be placed on the top of a front loading washing machine. They are sure to be fixed with stacking kit (See the next page). This installation must be conducted by an experienced installer in order to secure robust installation of both washer and dryer.
  • Page 7: Grounding Instruction

    The dryer can drain water without delivering to water container. Water is directly pumped out of the dryer. Stacking Kit In order to stack this dryer on a LG washing machine, LG stacking kit is needed. Washer top plate size 550 mm...
  • Page 8: Level The Dryer

    nstallation Instructions Level the Dryer Adjustable feet Raise Adjustable feet Adjustable feet 1. Leveling the dryer is to prevent undesirable noise and vibration. When placing your dryer in an solid and level area where water is not dripping and freezing, flammable materials are not stored.
  • Page 9: Appearance & Design

    ppearance & design Water container Door Condenser Cover Air ventilation grill Control Panel Program selector Start/Pause Control panel LED Display • Time Display • Indicator lamps Additional function buttons • Gentle • Buzzer Off • Anti-Crease • More Time • Less Time •...
  • Page 10: Operating Your Dryer

    perating your dryer Cycle Selection Table Electronic Auto Dry Cycles Mixed-Fabric cycles (Note) press the "Gentle" button for heat-sensitive items Bed linen and table linen, tracksuits, anorak, blankets Shirts, blouses and sportswear Trousers, dressers, skirts, blouses Cotton (Whites and coloreds) (Note) press the "Gentle"...
  • Page 11 perating your dryer Before first use of the dryer Before you use the dryer for the first time, there are some points that you have to check. After removing package, you will check the product has no problem and is properly installed. 1.
  • Page 12 perating your dryer 5. Close the Door. Before you close the door, make sure fabrics are well placed inside and that foreign objects, especially flammable ones, are not caught around door. CAUTION - Be careful not to trap laundry in between the loading door and rubbber seal.
  • Page 13: Rack Dry

    perating your dryer Rack Dry The dryer Rack is placed inside the dryer like the picture. Remove and discard packing material before use, The Rack Dry is designed for use with items that you do not want to tumble dry including sweaters and delicate fabrics.
  • Page 14: Additional Functions

    dditional Functions Gentle This is used to lengthen the cycle time by decreasing temperature. Buzzer Off This is about buzzer sound on/off. After power is on and you select cycle, buzzer will sound when you press a certain button on the panel.
  • Page 15: Caring For Your Dryer

    aring for Your Dryer How important care and cleaning is~ It’s not very difficult to care for your dryer. All you have to do is to follow the information below. Clean Lint Filter Clean lint filter after each use and check it before each use.
  • Page 16 aring for your dryer Condenser Condenser is also a very important part for efficient drying performance result so it needs a special care from you. It is recommended that condenser be cleaned three or four times a year. 1. Open condensing cover by using a coin or flat blade screwdriver.
  • Page 17: Moisture Sensor

    aring for your dryer Front Ventilation Grille Vacuum the front ventilation grill 3~4 time a year to make sure there must be no build-up of lints or dirts which cause improper intake air flow. Condensed Water Drain-out Normally, condensed water is pumped up to water container where water is collected until emptied.
  • Page 18: Reverse The Door

    aring for your dryer Reverse the door The door can be reversed to fit to your own installation conditions. From the factory, the door hinge is located on the right side. CAUTION 1. This work may cause the injury of your hands so you must be careful to handle some sharp devices like tork screwdriver or slotted screwdriver.
  • Page 19: Additional Tips For Smart Use

    dditional Tips for smart use Drying Guide Capacity for laundry type Cotton 8 kg 4 kg Mixed Wool 1.5 kg Delicate 1.5 kg Woolen Article Dry woolens in "wool" cycle. Be sure to follow fabric care label "symbols", first. Wool is not completely dried from the program so don't repeat drying.
  • Page 20: Spare Parts

    - fig : Washer top plate size 550 - fig : Washer top plate size 600 If stacking is needed, you must stack the dryer upon LG washing machine. In order to do this, stacking kit must be purchased separately.
  • Page 21: Troubleshooting Guidelines

    roubleshooting Guidelines Troubleshooting Tips To save you time and money, the following page will help answer your questions before service call. Questions Dryer doesn't work 1. Check dryer is plugged in. 2. Check "Start" button is pressed. 3. Check door is properly closed. 4.
  • Page 22: Error Mode

    roubleshooting Guidelines Error Mode • : LED displays “ ” in case of the door open. The door must be closed and start Button must be pressed for re-operation. High temperature and high humidity of air continues to remain at the contained dryer by drying object during drying if the dryer suddenly stops due to power failure or other different causes while drying is in progress.
  • Page 23: Technical Data

    echnical Data Electrical Requirements Volts Hertz Watts U.K. 230 V 50 Hz Singapore Kuwait 240 V 50 Hz Australia 240 V 50 Hz You are sure to check the rating plate on the dryer to make sure the dryer has right rating. Alcove or Under Counter Sides 0 mm...
  • Page 24: Warranty

    arranty Disposal of your old appliance 1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC. 2. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.
  • Page 25 5. The warranty is nullified if any person intervenes in the apparatus that are not authorised by LG Electronics, if the apparatus is used for commercial purposes. attributed 6. Alaways keep the original packaging, so that if the apparatus requires servicing, it can be transported without damanging it.
  • Page 28 For U.K. Customer CUSTOMER SERVICE Tel : 0870 - 873 - LGLG(5454) Fax. : 0870 -872 -7337 LGEUK SERVICE WEB-SITE : http://uk.lge.com P/No.: MFL32312516...
