Aquverse B11A Troubleshooting Instructions Supplement

B11A (3H) Aquverse Water Cooler Troubleshooting Instructions Supplement
****Warning do not plug water cooler in until water bottle is in place and dispensing water through the faucets****
Parts Extraction:
1. To Remove Baffle From Top of the Water Cooler
a. Turn the Baffle counter clockwise till the open arrow meets the corresponding arrow on the top of the cooler body (see
figure A and B below)
b. Grip baffle from two opposite sides and pull upwards out of the cooler body (see figure C below)
2. To Remove Faucets
a. Grip faucet in hand and unscrew faucet counter clockwise (see figure D below)
General Information Helpful To Trouble Shooting
1. Note that your cooler is built with a no spill kit (see figure E below). This unit is designed to be used with a bottle that has a
cap made to be punctured by our probe (see figure F below). The bottle cap (see figure G below) can be taken off if you also
remove the no spill kit completely (see figure H below)
Figure A Figure B
Figure C
Figure D
Figure E Figure F
2.
If cooler is not functioning make sure you are using a working outlet by testing it with a lamp
What To Do If:
1. Cooler Is Not Dispensing Water
a. Make sure water bottle is full
b. Make sure the water bottle is being properly pierced by the probe in the baffle
c. Confirm that cooler is not frozen by:
1. Removing baffle (see above instructions under Parts Removal section 3),
d. Check water bottle to determine if cap is jammed and not dispensing water (see figure I below)
e. Check faucets to determine if water is able to flow through when in on position (see figure J and K below)
2. Cooler Is Not Dispensing Chilled Water
a. Check that cold water thermostat is not turned to the off position (see figure L below)
b. Determine whether the compressor is working by putting your ear close to the top of the cooler with the bottle off (if
you hear silence, the compressor is not working, if you hear a humming noise the compressor is working)
Figure G Figure H
Figure I
Figure J Figure K
Figure L
