For any needed assistance please call 1-866-872-5722
****Warning do not plug water cooler in until water line is in place and dispensing water through the faucets****
Installation can be completed easily even without much knowledge of basic hardware and plumbing.
Phillips head screw driver
Very sharp pair of scissors or a very sharp knife to cut tubing
Zip Ties (provided in water line kit)
Poly Tubing (provided in water line kit)
Water filter
First Steps
Determine where your cooler is going to be located and place it close to the determined area
DO NOT PLUG IN
A professional licensed plumber can perform the install or you can obtain the following items at your local hardware store:
Attaching Filter
Remove the drip tray by pulling towards you
Remove the screw located at the bottom of the cabinet on the front of the cooler
Push the cabinet cover in at the top and pull down then towards you
Attach filter to filter head by pushing in, and turning to the right until it stops
Locate Water Source
If you do not own the property where the unit will be installed, you need to contact the owner and obtain
approval before you install your cooler. If you are not comfortable with the installation procedure it is
WARNING: This product is intended for indoor use only. Outside temperatures can cause damage to all systems. Please use only inside your home or office.
Items You Need
Cooler Set Up
Aquverse Water Cooler Installation and Troubleshooting Instructions
WARNING: YOU MUST OBSERVE ALL LOCAL GOVERNING CODES AND ORDINANCES
recommended to have a professional licensed plumber complete the install for you.
Angle stop fitting (size depends on your water source, adaptable fitting provided in water line kit)
Quick connect (2 sided coupler for poly line, provided in water line kit)
Safety Glasses (Wear these at all times during installation)
This drinking water system must be maintained in accordance with the manufacture's instructions
Place the bottom of the cabinet cover over the plastic L-shaped clips at the bottom of the cooler and press
Push the top of the cabinet cover into place and let slide up naturally and click into position
Insert the previously removed screw into the bottom of the cabinet cover
WARNING: YOU MUST OBSERVE ALL LOCAL GOVERNING CODES AND ORDINANCES
Adjustable crescent wrench
Drill with a 3/8 bit
Filter Specifications
(see instructions that are provided with filter)
Maximum PSI = 10-125 psi/Capacity = 1500 gallons/Temperature = 35-100 F
Re-attaching Front Cabinet
down gently
Re-attach the drip tray by pushing in
Advertisement
Table of Contents
Related Manuals for Aquverse 5ph
Summary of Contents for Aquverse 5ph
- Page 1 Aquverse Water Cooler Installation and Troubleshooting Instructions WARNING: YOU MUST OBSERVE ALL LOCAL GOVERNING CODES AND ORDINANCES For any needed assistance please call 1-866-872-5722 If you do not own the property where the unit will be installed, you need to contact the owner and obtain approval before you install your cooler.
- Page 2 WARNING: YOU MUST OBSERVE ALL LOCAL GOVERNING CODES AND ORDINANCES A water source looks like this. It can be typically found underneath the closest sink to were you would like to place your cooler Locate the cold water source Make sure that the water source you will work with is connected to the cold faucet on you sink by a water line To confirm you are using the cold water please shut off the water source valve and turn on your cold water hose.
- Page 3 Wait a minimum of 30 minutes after you turn on the water source before plugging in filter Flushing the Filter You must flush water through the filter to wash excess carbon out before drinking (this is commonly referred There is no danger in drinking the water with the carbon residue discoloring the liquid, however for the to as priming the filter, and is required) freshest tasting and looking water it is beneficial to flush the system.
- Page 4 Check the back of the cooler, and make sure the hot tank switch is in the on position Turn the cooler around so you are facing the back (wire caged portion) of the cooler If hot tank switch is on then you will need to reset the hot tank (this can be tripped to the off position much Locate the hot tank through the back cage, and then locate the hot tank reset button on the right side of like a circuit breaker, if the cooler is plugged in before water is filled into the tank) the hot tank...
- Page 5 Remove the baffle from the cooler and clean with a clean dish towel, and water (do not use bleach or any Install the to cover of cooler back in its original position cleaners, you may use a small amount of soap if desired) Clean the cold tank with a clean dish towel, and water (do not use bleach or any cleaners, you may use a small amount of soap if desired) Replacing Your Water Filter...
