9BL Aquverse Water Cooler Troubleshooting Instructions Supplement
**Warning do not plug water cooler in until water bottle is in place and dispensing water through the faucets**

Parts Extraction:

1. To Remove Faucet Covers and Faucets

A. Grip faucet cover in hand and turn left or right to unlock. Pull down once unlocked. See figure A and B below.
B. Remove front panel cover ( 3 screws hold the panel in place. 2 screws internally and 1 screw near faucets)
C. Grip faucet in hand and unscrew faucet counter clockwise. See figure C below.
Figure A

2. To Remove Lid

A. Turn the cooler around so you are facing the back (wire caged portion).
B. Locate the 2 screws holding the lid in place (on the left and right side of the lid) See figure D below.
C. Locate the tab securing the lid in place and gently push towards the front. See figure E below.
Figure E
Figure D

3. To Remove UV Float

A. Follow the steps in how to remove the lid from above.
B. Once lid is removed you will be looking at the cold tank and float system.
C. Locate the UV float lip and pull up until UV float separates from the cold tank.
D. See images below.
b. Grip baffle from two opposite sides a
Figure B Figure C
pwards out of the c dy (see figure I below)
General Information Helpful To Trouble Shooting
1. This unit is designed to be used with a bottle that has a cap or a bottle without a cap. The bottle probe
will puncture and seal a cap bottle with a cap or simply slide on to a bottle without a cap. Please see figure
below.
2.
If cooler is not functioning make sure you are using a working outlet by testing it with a lamp

What To Do If:

1. Cooler Is Not Dispensing Water

A. Make sure water bottle is full
B. Make sure the water bottle is being properly pierced by the bottle probe kit
C. Make sure you have removed the bottle probe kit cover (little black cap on the end)
D. Confirm that cooler is not frozen by:
-Removing the 9BL lid, removing the 9BL float, and checking the cold water tank (see figures F below)
E. Check water bottle to determine if cap is jammed and not dispensing water (see figure G below)
Figure F
F. Check faucets to determine if water is able to flow through when in on position (see figure H and I below)
Figure H
Figure G
Figure I
