WARNING AGAINST COUNTERFEIT PRODUCTS Always purchase from a Horizon Hobby, LLC authorized dealer to ensure authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with regards, but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM or Spektrum technology.
Perform the setup for the AR637T receiver through a compatible Spektrum Transmitter with Forward Programming. The Spektrum PC Programmer can be used for firmware updates. Table of Contents AR637T AS3X and SAFE Telemetry Receiver ..........3 Table of Contents ..................3 Smart Throttle ....................4...
AR637T receiver for Smart Technology features. For Smart to function you must have a Smart ESC paired with a Smart telemetry receiver, and a Spektrum DSMX transmitter with telemetry. An update for your transmitter may be required for Smart features. See www.spektrumrc.
If you want to add altitude and variometer to an AR637TA, an external sensor (SPMA9589) can be connected to the XBus system. The AR637T is not compatible with the Spektrum Temperature Sensor (SPMA9571) See www.spektrumrc.com for more information about telemetry accesories Installing the AR637T Receiver Mount the receiver using double-sided servo tape.
NOTICE: Do not cut, kink, or modify the antennas. Damage to the coaxial portion of an antenna will reduce the performance of the antenna. Shortening or cutting off the 31mm tip will reduce the range. Transmitter and Receiver Binding Programming the AR637T receiver requires a Spektrum DSM2 /DSMX ™...
• All channels have no output until the receiver has linked to the transmitter. Initial Setup Verify your transmitter is updated to the latest Spektrum AirWare™ software to take advantage of Forward Programming. See your transmitter manual for updating instructions.
AR637T Receiver- Basic AS3X Setup To use AS3X technology with the Spektrum AR637T Receiver, the receiver needs to be set up with a compatible Spektrum transmitter. Verify the basic setup and trim is accurate before attempting AS3X setup. Forward Programming Setup: The receiver is directly configured through the Forward Programming menu.
AS3X Reaction Test This test ensures that the AS3X control system is functioning properly. Assemble the aircraft, bind your transmitter to the receiver, and complete the AS3X First Time Setup in the Forward Programming menu before performing this test. Raise the throttle above 25% to activate AS3X, then lower the throttle. Once the AS3X system is active, control surfaces move in respose to aircraft movement.
AR637T Receiver- SAFE Setup Setting up SAFE Technology on the AR637T Receiver takes place in Forward Programming. Complete the AS3X setup and verify operation in flight. Forward Programming Setup: To add SAFE flight stabilization the Flight Modes on the receiver need to be configured. 1.
Advanced Tuning Basic gain tuning can be as simple as using a slider, but to fine tune the AS3X system there are many setup and tuning options. AS3X Gain tuning options In your transmitter’s menu select Forward Programming -> Gyro Settings -> AS3X Settings •...
Page 12
When you add Flight Modes within Forward Programming, additional tuning options are added in the AS3X Setting menu. Be sure to change through all the flight modes with your assigned switch and verify values for each feature for every flight mode. Select Forward Programming ->...
Page 13
SAFE Setting menu. The First Time SAFE Setup should be sufficient to fly your airplane, but to fine tune the SAFE system there are many setup and tuning options. Select Forward Programming -> Gyro Settings -> SAFE Settings -> • SAFE Gains can be fine tuned for each axis within each Flight Mode. •...
Other Settings (Forward Programming) System Setup Select Forward Programming -> Other Settings -> • Select Failsafe -> Select each channel and assign it to Preset or Hold Last. When you select a different channel for Output, a new group of settings appears. Capture Failsafe Positions ->...
Differences between Self Leveling/Angle Demand and AS3X modes This section is generally accurate but does not take into account flight speed, battery charge status, and other limiting factors. SAFE Beginner SAFE Intermediate Control stick Aircraft will continue to fly at Aircraft will self level is neutralized its present attitude...
If your system displays a hold, diagnose the cause and resolve the issue before flying again. It is normal to see a hold logged if you power OFF your transmitter and back IMPORTANT: The Spektrum Flight Log (SPM9540) is not compatible with the AR637T receiver.
Range Testing Before each flying session, and especially with a new model, it’s important to perform a range check. All Spektrum aircraft transmitters incorporate a range testing system, which reduces the output power to allow a range check. 1. With the model resting on the ground, stand approximately 100 feet (30 meters) away from the model.
Receiver Power System Requirements Some of the power system components that affect the power supply to the receiver include: • Receiver battery pack (number of cells, capacity, cell type, state of charge). • The ESC’s capability to deliver adequate voltage to the receiver when the servos demand high current •...
12" Aircraft Telemetry Extension SPMA9552 24" Aircraft Telemetry Extension *Only applicable for AR637TA receivers included with BNF models. SPMA9589 functions are already integrated in the SPMAR637T. **For use with electric power system batteries that are separate from the receiver battery(s).
Troubleshooting Guide AS3X Problem Possible Cause Solution Damaged propeller or Replace propellereller or spinner spinner Imbalanced propel- Balance the propellereller lereller Replace parts or correctly align Motor vibration propellereller or other parts and tighten fasteners as needed Align and secure receiver in Loose receiver fuselage Tighten or otherwise secure parts...
Troubleshooting Guide Problem Possible Cause Solution Throttle not at idle Reset controls with throttle and/or throttle trim stick and throttle trim at lowest too high setting Throttle servo travel is Make sure throttle servo travel Aircraft will not lower than 100% is 100% or greater respond to throttle but responds to...
Page 22
Problem Possible Cause Solution Move powered transmitter a few Transmitter too near feet from aircraft, disconnect aircraft during connecting and reconnect flight battery to process aircraft Aircraft or transmitter is Move aircraft and transmitter too close to large metal to another location and attempt object, wireless source or connecting again another transmitter...
1-YEAR LIMITED WARRANTY What this Warranty Covers - Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased (the “Product”) will be free from defects in materials and workmanship for a period of 1 year from the date of purchase. What is Not Covered - This warranty is not transferable and does not cover (i) cosmetic damage, (ii) damage due to acts of God, accident, misuse, abuse, negligence, commercial use, or due to improper use, installation, operation or...
Page 24
https://www.horizonhobby.com/content/service-center-render-service-center or call the toll free telephone number referenced in the Warranty and Service Contact Information section to speak with a Product Support representative. Inspection or Services - If this Product needs to be inspected or serviced and is compliant in the country you live and use the Product in, please use the Horizon Online Service Request submission process found on our website or call Horizon to obtain a Return Merchandise Authorization (RMA) number.
Supplier’s Declaration of Conformity Spektrum AR637T AS3X and SAFE 6 CH Receiver (SPMAR637T) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Compliance Information for the European Union EU Compliance Statement: Spektrum AR637T AS3X and SAFE 6 CH Receiver (SPMAR637T); Hereby, Horizon Hobby, LLC declares that the device is in compliance with the following: EU Radio Equipment Directive 2014/53/EU;...
