2.1.1 Initial inspection
Inspect the shipping carton immediately upon receipt for evidence of damage during
transport. If the shipping carton is severely damaged or water stained, request that the
carrier's agent be present when opening the carton. Save the carton packing material for
future use.
After unpacking the system, inspect it thoroughly for hidden damage and loose
components or fittings. If the contents are incomplete, if there is mechanical damage or
defect, or if the system does not work properly, notify your dealer.

2.2 Installing the VHF radio

2.2.1 General requirements
The SAILOR 7222 VHF DSC radio consists of two units:
• SAILOR 7224 Control Unit, which controls the system and contains the user interface. It
also connects to other units and systems (handsets, GNSS, BAM etc.).
• SAILOR 7226 VHF Transceiver Unit, which connects to the antenna(s) and via Ethernet
to the Control Unit.
Control Unit: You can mount the SAILOR 7224 Control Unit as a desktop, overhead or
flush-mounted unit integrated in the instrument panel.
• Provide space enough to access the front panel connectors and for installing a cradle for
the speaking device.
• Provide at least 120 mm space at the back of the SAILOR 7222 VHF DSC radio to
allow free air circulation and for cable access.
Transceiver Unit: You can mount the SAILOR 7226 VHF Transceiver Unit integrated in a
SAILOR GMDSS Console or on a bulkhead using the screw kit included in the delivery.
Cable requirements
All cables attached to the SAILOR 7222 VHF DSC must be shielded. Every shield should
have a low impedance connection to an electrical ground.
Before using the SAILOR 7222 VHF DSC for the first time, check that all cables are correctly
wired and fastened.
For details on the individual cable requirements, see Cable requirements on page C-17.
98-171833-A
WARNING! To avoid electric shock, do not apply
power to the system if there is any sign
of shipping damage to any part of the
front or rear panel or the outer cover.
Read the safety summary at the front of
this manual before installing or operating
the system.
Chapter 2: Installation
Installing the VHF radio
2-2
